Unique performance, convenience and safety features are built into every Lift Master Boom.  Fabricated from structural steel with welding to meet AWS creates a rugged and durable boom that will provide long term service.  Telescopic units come with an infinitely adjustable locking screw (except orbit booms which features a locking detent).  Fork pockets for 3,000 and 4,000 pound capacity models measure 7"W x 2"H usable.  Usable fork pockets are 7"W x 2"H for 6,000 and 8,000 pound uniform capacity models.  A 36" safety restraint secures the boom to the fork truck for safe operation.  Each unit includes two lifting hooks.





model LM-HRT-4-24


model LM-HRNT-4-24



LM-OBT-8-24



model LMS-EBNT-40-4

Short boom length is ideal for tight areas. Choose either telescoping or non-telescoping design. Includes built-in fork pockets, safety restraint and two lifting hooks. Overall width is 32". Steel construction.


model LMS-EBT-46-8



model LM-1T-8-24

Lift Master Booms
Model PDF's Description Fork Pocket Center Overall Extended Length   Height Uniform Capacity (lbs) Wt.
(lbs)

 Telescoping Style

LM-1T-3-24 Warranty PDFCompliance Certificate Lift Master Boom 24" 151-1/4" 25-7/8" 3,000 434
LM-OBT-3-24 Warranty PDFCompliance Certificate Orbit Boom 24" 146-5/8" 27-11/16" 3,000 433
LM-1T-4-11 Warranty PDFCompliance Certificate  Lift Master Boom 11" 151-1/4" 25-7/8" 4,000 444
LM-1T-4-30 Warranty PDFCompliance Certificate Lift Master Boom 30" 151-1/4" 25-7/8" 4,000 461
LM-1T-4-36 Warranty PDFCompliance Certificate Lift Master Boom 36" 151-1/4" 25-7/8" 4,000 517
LM-1T-4-24 Warranty PDFCompliance Certificate Lift Master Boom 24" 151-1/4" 25-7/8" 4,000 424
LM-OBT-4-30 Warranty PDFCompliance Certificate Orbit  Boom 30" 146-5/8" 27-11/16" 4,000 468
LM-OBT-4-36 Warranty PDFCompliance Certificate Orbit  Boom 36" 146-5/8" 27-11/16" 4,000 467
LM-OBT-4-24 Warranty PDFCompliance Certificate Orbit  Boom 24" 146-5/8" 27-11/16" 4,000 433
LM-HRT-4-24 Warranty PDFCompliance Certificate High-Rise Boom 24" 92-5/8" 79-13/16" 4,000 707
LM-HRT-4-30 Warranty PDFCompliance Certificate High-Rise Boom 30" 92-5/8" 79-13/16" 4,000 905
LM-HRT-4-36 Warranty PDFCompliance Certificate High-Rise Boom 36" 92-5/8" 79-13/16" 4,000 935
LM-EBT-4-11 Warranty PDFCompliance Certificate  Economy Boom 11" 151-1/2" 13-7/8" 4,000 333
LM-EBT-4-30 Warranty PDFCompliance Certificate  Economy Boom 30" 151-1/2" 13-3/16" 4,000 375
LM-EBT-4-36 Warranty PDFCompliance Certificate  Economy Boom 36" 151-1/2" 13-3/16" 4,000 381
LM-EBT-4-24 Warranty PDFCompliance Certificate  Economy Boom 24" 151-1/2" 13-1/2" 4,000 333
LM-F15-4-24 Warranty PDFCompliance Certificate Fixed 15 Degrees 24" 147" 33" 4,000 370
LM-1T-6-11 Warranty PDFCompliance Certificate Lift Master Boom 11 151-1/4" 25-7/8" 6,000 479
LM-1T-6-30 Warranty PDFCompliance Certificate Lift Master Boom 30 151-1/4" 25-7/8" 6,000 543
LM-1T-6-36 Warranty PDFCompliance Certificate Lift Master Boom 36 151-1/4" 25-7/8" 6,000 509
LM-1T-6-24 Warranty PDFCompliance Certificate Lift Master Boom 24 151-1/4" 25-7/8" 6,000 480
LM-OBT-6-30 Warranty PDFCompliance Certificate Orbit Boom 30" 146-5/8" 27-11/16" 6,000 499
LM-OBT-6-36 Warranty PDFCompliance Certificate Orbit Boom 36" 146-5/8" 27-11/16" 6,000 514
LM-OBT-6-24 Warranty PDFCompliance Certificate Orbit Boom 24" 146-5/8" 27-11/16" 6,000 476
LM-HRT-6-30 Warranty PDFCompliance Certificate High-Rise Boom 30" 92-5/8" 79-13/16" 6,000 979
LM-HRT-6-36 Warranty PDFCompliance Certificate High-Rise Boom 36" 92-5/8" 79-13/16" 6,000 1009
LM-HRT-6-24 Warranty PDFCompliance Certificate High-Rise Boom 24" 92-5/8" 79-13/16" 6,000 833
LM-EBT-6-11 Warranty PDFCompliance Certificate  Economy Boom 11" 153-1/2" 13-7/8" 6,000 439
LM-EBT-6-30 Warranty PDFCompliance Certificate  Economy Boom 30" 153-1/2" 13-3/16" 6,000 409
LM-EBT-6-36 Warranty PDFCompliance Certificate  Economy Boom 36" 151-1/2" 13-3/16" 6,000 448
LM-EBT-6-24 Warranty PDFCompliance Certificate  Economy Boom 24" 153-1/2" 13-3/16" 6,000 377
LM-1T-8-24 Warranty PDFCompliance Certificate Lift Master Boom 24" 149-1/8" 26-9/16" 8,000 647
LM-1T-8-30 Warranty PDFCompliance Certificate Lift Master Boom 30" 149-1/8" 26-9/16" 8,000 673
LM-1T-8-36 Warranty PDFCompliance Certificate Lift Master Boom 36" 149-1/8" 26-9/16" 8,000 686
LM-OBT-8-24 Warranty PDFCompliance Certificate Orbit  Boom 24" 145-1/4" 28-7/8" 8,000 622
LM-OBT-8-30 Warranty PDFCompliance Certificate Orbit  Boom 30" 145-1/4" 28-7/8" 8,000 755
LM-OBT-8-36 Warranty PDFCompliance Certificate Orbit  Boom 36" 145-1/4" 28-7/8" 8,000 689
LM-EBT-8-30 Warranty PDFCompliance Certificate Economy Boom 30" 149-3/8" 15" 8,000 602
LM-EBT-8-36 Warranty PDFCompliance Certificate Economy Boom 36" 149-3/8" 15" 8,000 638
LM-EBT-8-24 Warranty PDFCompliance Certificate  Economy Boom 24" 149-3/8" 15" 8,000 577
Non-Telescoping Style
Model PDF's Description Fork Pocket Center Overall Extended Length   Height Uniform Capacity (lbs) Wt.
(lbs)
LM-1NT-4-11 Warranty PDFCompliance Certificate Lift Master Boom 11" 81-1/2" 24-13/16" 4,000 391
LM-1NT-4-24 Warranty PDFCompliance Certificate  Lift Master Boom 24" 81-1/2" 24-13/16" 4,000 333
LM-1NT-4-30 Warranty PDFCompliance Certificate Lift Master Boom 30" 81-1/2" 24-13/16" 4,000 421
LM-1NT-4-36 Warranty PDFCompliance Certificate Lift Master Boom 36" 81-1/2" 24-13/16" 4,000 445
LM-OBNT-4-24 Warranty PDFCompliance Certificate Orbit Boom 24" 80-7/8" 26-5/8" 4,000 337
LM-OBNT-4-30 Warranty PDFCompliance Certificate Orbit Boom 30" 80-7/8" 26-5/8" 4,000 458
LM-OBNT-4-36 Warranty PDFCompliance Certificate Orbit Boom 36" 80-7/8" 26-5/8" 4,000 467
LM-HRNT-4-24 Warranty PDFCompliance Certificate High-Rise Boom 24" 50-3/8" 78-9/16" 4,000 810
LM-HRNT-4-30 Warranty PDFCompliance Certificate High-Rise Boom 30" 50-3/8" 78-9/16" 4,000 644
LM-HRNT-4-36 Warranty PDFCompliance Certificate High-Rise Boom 36" 50-3/8" 78-9/16" 4,000 661
LM-EBNT-4-11 Warranty PDFCompliance Certificate  Economy Boom 11" 81-3/4" 13-5/16" 4,000 369
LM-EBNT-4-24 Warranty PDFCompliance Certificate  Economy Boom 24" 81-5/8" 13-5/16" 4,000 258
LM-EBNT-4-30 Warranty PDFCompliance Certificate  Economy Boom 30" 81-3/4" 13-5/16" 4,000 269
LM-EBNT-4-36 Warranty PDFCompliance Certificate  Economy Boom 36" 81-3/4" 13-5/16" 4,000 274
LM-1NT-6-11 Warranty PDFCompliance Certificate Lift Master Boom 11" 81-1/2" 24-13/16" 6,000 461
LM-1NT-6-24 Warranty PDFCompliance Certificate Lift Master Boom 24" 81-1/2" 24-13/16" 6,000 478
LM-1NT-6-30 Warranty PDFCompliance Certificate Lift Master Boom 30" 81-1/2" 24-13/16" 6,000 511
LM-1NT-6-36 Warranty PDFCompliance Certificate Lift Master Boom 36" 81-1/2" 24-13/16" 6,000 544
LM-OBNT-6-24 Warranty PDFCompliance Certificate Orbit  Boom 24" 80-7/8" 26-5/8" 6,000 391
LM-OBNT-6-30 Warranty PDFCompliance Certificate Orbit  Boom 30" 80-7/8" 26-5/8" 6,000 635
LM-OBNT-6-36 Warranty PDFCompliance Certificate Orbit  Boom 36" 80-7/8" 26-5/8" 6,000 677
LM-HRNT-6-24 Warranty PDFCompliance Certificate High-Rise Boom 24" 50-3/8" 78-9/16" 6,000 697
LM-HRNT-6-30 Warranty PDFCompliance Certificate High-Rise Boom 30" 50-3/8" 78-9/16" 6,000 722
LM-HRNT-6-36 Warranty PDFCompliance Certificate High-Rise Boom 36" 50-3/8" 78-9/16" 6,000 755
LM-EBNT-6-11 Warranty PDFCompliance Certificate Economy Boom 11" 81-3/4" 13-5/16" 6,000 285
LM-EBNT-6-24 Warranty PDFCompliance Certificate  Economy Boom 24" 81-5/8" 13-5/16" 6,000 291
LM-EBNT-6-30 Warranty PDFCompliance Certificate Economy Boom 30" 81-3/4" 13-5/16" 6,000 312
LM-EBNT-6-36 Warranty PDFCompliance Certificate Economy Boom 36" 81-3/4" 13-5/16" 6,000 341
LM-1NT-8-24 Warranty PDFCompliance Certificate  Lift Master Boom 24" 80-1/8" 23-1/2" 8,000 615
LM-1NT-8-30 Warranty PDFCompliance Certificate Lift Master Boom 30" 80-1/8" 23-1/2" 8,000 604
LM-1NT-8-36 Warranty PDFCompliance Certificate Lift Master Boom 36" 80-1/8" 23-1/2" 8,000 622
LM-OBNT-8-24 Warranty PDFCompliance Certificate Orbit Boom 24" 79-1/2" 25-1/8" 8,000 792
LM-OBNT-8-30 Warranty PDFCompliance Certificate Orbit Boom 30" 79-1/2" 25-1/8" 8,000 804
LM-OBNT-8-36 Warranty PDFCompliance Certificate Orbit Boom 36" 79-1/2" 25-1/8" 8,000 814
LM-EBNT-8-24 Warranty PDFCompliance Certificate Economy Boom 24" 80-3/8" 11-1/2" 8,000 418
LM-EBNT-8-30 Warranty PDFCompliance Certificate Economy Boom 30" 80-3/8" 11-1/2" 8,000 634
LM-EBNT-8-36 Warranty PDFCompliance Certificate Economy Boom 36" 80-3/8" 11-1/2" 8,000 658
Lift Master Booms Options
Model Description Wt.
(lbs)
LM-FP Larger Fork Pockets 8-1/4"W x 4-1/4"H (Inside Dimension) 0
LM-FP-37 Larger Fork Pockets 7"W x 3"H (Inside Dimension) 0
LM-FP-37 Larger Fork Pockets 9"W x 3"H (Inside Dimension) 0
Shorty Lift Master Booms
Model PDF Description Overall
Length
Capacity
(lbs)
Wt.
(lbs)
LMS-EBT-46-4 Warranty PDFCompliance Certificate Telescoping 55-1/4" to 93" 4,000 248
LMS-EBT-46-6 Warranty PDFCompliance Certificate Telescoping 55-1/4" to 93" 6,000 296
LMS-EBT-46-8 Warranty PDFCompliance Certificate Telescoping 53-7/8" to 90-7/8" 8,000 430
LMS-EBNT-40-4 Warranty PDFCompliance Certificate Non-Telescoping 50-3/4" 4,000 214
LMS-EBNT-40-6 Warranty PDFCompliance Certificate Non-Telescoping 50-3/4" 6,000 244
LMS-EBNT-40-8 Warranty PDFCompliance Certificate Non-Telescoping 49-3/8" 8,000 320
