The Trailer Jack adjustable lift range provides easy hitching and unhitching of a loaded trailer.  Use for a wide variety of lifting, leveling, and adjustment applications.  Ideal for industrial, utility, construction, or agricultural equipment trailers. Heavy-duty construction. Available with a side or top crank position.  Mounting bracket attaches in a variety of ways in order to meet your application needs.  Scissor jacks provide stability and leveling to unattached trailers and equipment.

model FJ-K2

model CT-02

model SJ-7523

model NJ-BP

model NJ-CR

model SJ-7529
Trailer Jacks
Model PDF's Mount Crank Position Capacity (lbs) Lift
Wt. (lbs)
TJ-06 Warranty PDFPhoto Gallery Side Swivel/Wheel Side 800 10" 15
TJ-F3 Warranty PDFPhoto Gallery Tube Ring Top 2,000 15" 15
TJ-F1 Warranty PDFPhoto Gallery Tube Ring Top 1,000 10" 13
TJ-AF Warranty PDFPhoto Gallery A-Frame Top 2,000 10" 14
FJ-K2 Warranty PDFPhoto Gallery A-Frame Side 2,000 15" 14
CT-02 Warranty PDFPhoto Gallery Crank Jack Top 2,000 14" 11
NJ-BP Warranty PDFPhoto Gallery Nose Jack Base Pad   3
NJ-CR Warranty PDFPhoto Gallery Nose Jack Caster   2
SJ-7523 Warranty PDFPhoto Gallery Scissor Jack -- 7,500 23" 17
SJ-7529 Warranty PDFPhoto Gallery Scissor Jack -- 7,500 29" 19
SJ-HDL Warranty PDF Jack Crank Handle (for SJ-7523, and 7529) -- -- -- 1

= Approval Drawing Warranty PDF = Warranty Photo Gallery = Photo Gallery Compliance Certificate = Testing Certificate
