Convertible Hand Trucks

model CSHT-500

model DSHT-500-PN

The Aluminum & Steel Convertible Hand Trucks are versatile wonders. These hand trucks can work in both the vertical and horizontal positions. The task of transporting smaller crates or long narrow boxes is now simplified. These carts roll smoothly on 10" x 3" rigid pneumatic and 4" x 1" swivel solid rubber casters, (except CSHT-500 on 10 x 2-1/2 and 5 x 1) . Ships knockdown, assembly required.

model CAHT-500

Convertible Hand Trucks
Model PDF Description Nose Plate
Capacity (lbs) Overall Size
CAHT-500 Warranty PDFPhoto GalleryCompliance Certificate Aluminum 18"x7-1/4" 500 20-1/2"x18-7/8"x51-1/2" 42
650 20-1/2" x 46-1/2" x 40-1/2"
DSHT-500-PN Warranty PDFPhoto GalleryCompliance Certificate Steel 14"x7" 500 20"x17"x48" 31
500 22"x42"x36"
CSHT-500 Warranty PDFPhoto GalleryCompliance Certificate Steel 10-1/4"x7-1/2" 500 19-1/2"x 20"x 58-1/4" 76
750 13-1/2"x 44"x 36"

= Approval Drawing Warranty PDF = Warranty Photo Gallery = Photo Gallery Compliance Certificate = Testing Certificate

Freight Quote

Back to Hand Trucks >>
