Modular Guard System can be ordered to fit almost any application. Designed for quick and easy assembly. Railing sections are installed and secured to each post with a single bolt. Select from different railing lengths to custom fit your application. Railing systems are made from heavy-duty 2-1/2" square steel tubing. Wall mounting posts may be used to secure guard assembly to a wall. Durable safety yellow powder coat finish. Steel construction. All components sold separately.


Fits against walls to protect
drains or piping



Individual Components are
Installed On-Site



SINGLE RAIL STRAIGHT POST
model MG-SP-36-1



DOUBLE RAIL STRAIGHT POST
model MG-SP-36-1



SINGLE RAIL CORNER POST
model MG-CP-36-1



DOUBLE RAIL CORNER POST
model MG-CP-36-2




RAILING SECTION
series MG-R





WALL MOUNT
series MG-WP



Modular Guard System

Model PDF Effective
Length
Overall
Length
Square Tube
(O.D.)
Wt.
(lbs)
MG-R-4 Warranty PDF 48" 56" 2-1/2" 29
MG-R-6 Warranty PDF 72" 80" 2-1/2" 38
MG-R-8 Warranty PDF 98" 102" 2-1/2" 49
MG-R-10 Warranty PDF 120" 128" 2-1/2" 60
MG-R-12 Warranty PDF 144" 152" 2-1/2" 71
Mounting Posts
Model PDF Description Style Overall
Height
Wt.
(lbs)
MG-CP-36-1 Warranty PDF Corner Post Single Rail 36" 37
MG-CP-36-2 Warranty PDF Corner Post Double Rail 36" 54
MG-SP-36-1 Warranty PDF Straight Post Single Rail 36" 37
MG-SP-36-2 Warranty PDF Straight Post Double Rail 36" 68
Mounting Options
Model Description Wt.
(lbs)
MG-WP-A Warranty PDF Wall Mounting Post - Post (2-1/2 x 2-1/2 square tubing, inner fitting) 7
MG-WP-B Warranty PDF Wall Mounting Post - Railing (3 x 3 square tubing, outer fitting) 8
AS-344   Anchor Bolts For Concrete (1) 3/4"x4" 1
AS-344-4PK   Anchor Bolts For Concrete (4) 3/4"x4" 4

Freight Quote
