Page 35 - Drum Handling Equipment
P. 35
319
Electric Drum Pumps 115V 1-PHASE STANDARD
Reduce time required to dispense or transfer liquids. Electric drum pumps allow you
to move fluid easily and efficiently. Pumps come complete with tube for 2" bung,
hose, and 115V motor.
FHL-PUMP for Flammables & Hazardous Locations
ME I 6 EX motor, Class I Group C&D, Class II Groups F&G (Explosion Proof) with
16 ft. cord, pump tube SS 39" sealless, high volume rotor, 1" SS barrel adaptor, 1" SS
nozzle with swivel, 8' conductive chemical tubing with conductive fittings, ground &
bonding wires, wall hanger. model EDP model FHL-PUMP
ODF-PUMP for Thin-Bodied Oils & Diesel Fuel
B36 motor with 16 ft. cord, pump tube ALU 39" sealless, high head impeller, 316
stainless steel shaft, PP Barrel Adaptor, 1" aluminum nozzle with swivel, 8" PVC hose,
hose clamps, and wall hanger.
ABS-PUMP for Acids & Base Solutions DRUM HANDLING EQUIPMENT & SPECIALTY CONTAINERS
B36 motor with 16 ft cord, pump tube PP 39" sealless, high volume rotor, Hastelloy
C shaft, PP barrel adaptor, 3/4" PP nozzle, 8' PVC hose, hose clamps, and wall hanger.
HCB-PUMP for Highly Corrosive Acids & Base Solutions
B55T-5 motor with 16 ft. cord, pump tube PVDF 39" sealless, high volume rotor,
Hastelloy C shaft, PP barrel adaptor, 1" PVDF nozzle with swivel, 8' chemical hose, model ODF-PUMP model ABS-PUMP
hose clamps, and wall hanger.
MODEL MAXIMUM MAXIMUM MAXIMUM MAXIMUM IMMERSION WEIGHT model HCB-PUMP
NUMBER VISCOSITY CAPACITY HEAD S.G. DEPTH (POUND)
EDP 400 CPS 22.75 GPM 43 FT. 1.3 39" 20
FHL-PUMP 500 CPS 18.5 GPM 33 FT. 1.3 12" 21
ODF-PUMP 500 CPS 15.9 GPM 68 FT. 1.4 12" 21
ABS-PUMP 600 CPS 13.5 GPM 31 FT. 1.4 12" 18
HCB-PUMP 500 CPS 13.5 GPM 26 FT. 1.6 39" 35
Fire Extinguisher Carrier
The Fire Extinguisher Carrier is designed for easily transporting your fire extinguisher up to 8" in
diameter. Includes two (2) heavy duty adjustable rubber straps. Sturdy handle with rubber grip and
poly casters for tilt-n-go portability. Welded steel construction with yellow baked-in powder-coat
toughness. 4" x 2" stabilizing plate keeps unit upright when empty and helps retain extinguisher.
Adjustable EPDM restraining straps keep extinguisher secure and allow for quick access. Wall mount
bracket included to store the extinguisher off the floor.
MODEL OVERALL SIZE WHEEL WHEEL WEIGHT
NUMBER (W x L x H) TYPE SIZE (POUND)
1
3
3
FEC-1 14 /8" x 11 /8" x 41 /8" POLY-ON-POLY 4" x 1¼" 13
model FEC-1
Wall Mounted Cylinder Brackets
Simple design is easy to install. Simply bolt to wall and then secure cylinder with strap. Edges are
protected with rubber guards on the steel units. Choose either steel or molded plastic construction.
Maximum 12" cylinder diameter. Installation hardware is not included.
model CB-W-S model CB-W-2S model CB-W-P model CB-W-3S
MODEL ACCOMMODATES WEIGHT
NUMBER MATERIAL CYLINDERS (POUND)
CB-W-S STEEL 1 2
CB-W-2S STEEL 2 7
CB-W-3S STEEL 3 10
CB-W-P PLASTIC 1 1
CB-W-2P PLASTIC 2 2 model CB-W-2P
