Page 45 - Ergonomic Solutions

137
Pallet Trucks with Digital Scale

The Pallet Truck with Digital Scale allows you to weigh your load on the spot for
maximum efficiency. The frame uses heavy-duty steel construction for maximum
strength and durability. This model is very user friendly and is suitable for Best suited for use with
low height lifting. The built-in scale allows you to weigh your load as you are open bottom skids
handling it. The scale is selectable in a variety of increments to adjust to the size ERGONOMIC SOLUTIONS
of your load. It has keyboard calibration and functional setup with automatic
zero capabilities. Digital filtering is used to help compensate for vibration
and motion to make the Pallet Truck with Digital Scale smooth and accurate.
Scale accuracy is +/-0.1% of the applied load. Forks are 7" wide each. Factory
calibrated for shipping destination. AC adaptor included. Six (6) Alkaline AA model
PM-2748-SCL-LP-PT
non-rechargeable batteries are included.
SCALE HEAD SHOWN
NTEP Pallet Trucks are approved legal for trade, certified for commercial WITH OPTIONAL PRINTER
transactions, and are supplied with certificate of compliance. New
MODEL UNIFORM OVERALL FORK SERVICE WEIGHT
NUMBER CAPACITY SIZE (W x L) RANGE (POUND)
3
PM-2048-SCL-LP� 5,000 lb. 22 /8" x 48" 3" to 7½" 335
PM-2748-SCL-LP� 5,000 lb. 27½" x 48" 3" to 7½" 335
3
PM-2048-SCL-LP-PT*� 5,000 lb. 22 /8" x 48" 3" to 7½" 335
PM-2748-SCL-LP-PT*� 5,000 lb. 27½" x 48" 3" to 7½" 340 model
PM-2748-NTEP-SCL-LP
304 STAINLESS STEEL PALLET TRUCK WITH SCALE
3
11
7
PM-2045-SCL-LP-SS� 5,000 lb. 21 /8" x 45 /16" 3 /8" to 8" 309
11
3
PM-2745-SCL-LP-SS� 5,000 lb. 27½" x 45 /16" 3 /8" to 8" 375 model
LEGAL FOR TRADE PALLET TRUCKS (NTEP APPROVED) PM-2045-SCL-LP-SS
3
7
PM-2748-NTEP-SCL-LP 5,000 lb. 27 /8" x 48" 3 /8" to 8" 342
3
7
PM-2748-N-SCL-LP-PT* 5,000 lb. 27 /8" x 48" 3 /8" to 8" 350
*PALLET TRUCK WITH SCALE AND PRINTER
Turnabout Pallet Truck Ships with the Handle Detached Standard
Unique Turnabout Pallet Truck allows for turning on a dime! Special center wheels allow empty
pallet truck to spin within operating space. Spring-loaded actuation does not interfere with normal
operation. Individual fork width is 7". Offers greatly improved product maneuverability.
MODEL UNIFORM OVERALL FORK SERVICE WEIGHT
NUMBER CAPACITY SIZE (W x L) RANGE (POUND)
PM5-2748-TURN� 5,500 lb. 27" x 48" 3½" to 7¾" 195

Wheel Nose Pallet Trucks Ships with the Handle Detached Standard

The Wheel Nose Pallet Trucks are designed to position pallets or skids closely together. The fork end
is set back from the front rollers allowing for one pallet pick up at a time. The unit has a rubber grip
Standard
handle with a three position lever for easy operation and maneuvering. Units include two articulating Wheel Nose Pallet Truck
Pallet Truck
steering wheels and two front load rollers. Spring loaded loop handle automatically returns to vertical
position when not in use. 6½"W x 38"L forks are used for maneuvering in tight spaces.
MODEL UNIFORM OVERALL FORK SERVICE WEIGHT
NUMBER DESCRIPTION CAPACITY SIZE (W x L) RANGE (POUND)
PM5-2038-WN� WHEEL NOSE 5,000 lb. 20" x 38" 3½" to 8" 240
PM5-2738-WN� WHEEL NOSE 5,000 lb. 27" x 38" 3½" to 8" 258

Moves FORWARD,
Side Winder Pallet Truck Ships with the Handle Detached Standard BACKWARD,
LEFT, and RIGHT
Transport long loads down narrow aisles with this heavy-duty Side Winder Pallet Truck. This
versatile Pallet Truck retains all the quality workmanship of a standard pallet truck in addition to
providing lateral movement. Simply place the forks into the pallet, then elevate to approximately
seven inches, rotate handle, and lock detent into place. The second set of rollers, right/left, are
actuated. Now push the Side Winder perpendicular to the traditional direction.
MODEL UNIFORM OVERALL FORK SERVICE WEIGHT Nose Wheel
NUMBER DESCRIPTION CAPACITY SIZE (W x L) RANGE (POUND)
SW-PJ� SIDE WINDER 3,000 lb. 27" x 48" 3½" to 8" 219
Right/Left Wheels
Forward/Back Wheel
