72                            Deluxe Spring Driven Low Pressure Hose Reels
       FACILITIES MAINTENANCE FACILITY MAINTENANCE  TYPE A  hazards and damaged hoses. For use with air and water only. Solid steel construction with heavy-duty


                                          Keep air hoses off the floor and out of the way. Minimize labor, save storage space, protect against trip
                                          brackets to resist hose pull. All reels have a full shaft and swivel to assure maximum product delivery.
                                          Maximum temperature is 150° F. Maximum pressure is 300 psi / 21 bar. Includes self retracting hose.

                                                                                               LENGTH
                                                                  OVERALL SIZE
                                                     MODEL
                                                                                INSIDE HOSE
                                                                                                          WEIGHT
                                                                                 DIAMETER
                                                                   (W x D x H)
                                                    NUMBER
                                            TYPE
                                                                                                          (POUND)
                                                                                               OF HOSE
                                             A
                                                                 6¼" x 15" x 15"
                                                 VHR-20-44�
                                                                                                            19
                                                                                              20 FOOT
                                                                                   1/4"
                                             A
                                                                 5½" x 12½" x 13"
                                                 VHR-35-44�
                                                                                                            31
                                                                                   1/4"
                                                                                              35 FOOT
                                             A
                                                                 6" x 15" x 15½"
                 TYPE B
                                             A
                                                                                   3/8"
                                                                                                            26
                                                                                              25 FOOT
                                                 VHR-25-46�
                                             A
                                                                                              50 FOOT
                                                                 7½" x 19½" x 20"
                                                                                   3/8"
                                                 VHR-50-56�
                                                                                                            43
                                             B
                                                                  8" x 9¼" x 18"
                                                                                                            43
                                                                                              35 FOOT
                                                                                   1/2"
                                                 VHR-35-58�
                                             B   VHR-17-46�     6½" x 14¾" x 15½"  3/8"       17 FOOT       31
                                                                8¼" x 21" x 19¾"
                                                                                                            55
                                                                                              50 FOOT
                                                                                   1/2"
                                                 VHR-50-78�
                                          Standard Spring Driven Low Pressure Hose Reels
                                          Keep air hoses off the floor and out of the way. Minimize labor, save storage space, protect against
                                          trip hazards and damaged hoses. Maximum pressure is 300 psi / 20 bar. Includes self retracting hose.
                                          Model SHR-P-38-50 is constructed of durable, high quality impact resistant polypropylene. A
            model                         positive latching mechanism automatically locks hose at a desired length. A safety lock prevents the
            SHR-P-38-50                   hose from moving in either direction. An integral wall/overhead swivel bracket and 36" lead hose are
                                          included. Maximum temperature is 140° F.
                                               MODEL                   OVERALL SIZE  INSIDE HOSE  LENGTH  WEIGHT
                                              NUMBER     DESCRIPTION    (W x D x H)   DIAMETER   OF HOSE  (POUND)
                                           SHR-P-38-50�   PLASTIC   8¾" x 17½" x 17¼"   3 /8"   50 FOOT     23
                                          Air Hose Reel
                                          Help eliminate twists and tangles of hoses, save storage space, protect against trip hazards and
                                          damaged hoses with Air Hose Reels.  This arm style reel is constructed of all steel.  Quick and simple
                                          manual hand crank and spring loaded axle helps reel in up to 100 feet of 3/8" hose or 50 feet of
                                          1/2" hose.  Valve assembly is rated at 100 psi and 25 cfm.  Unit can be mounted both vertically or
                                          horizontally.  The wall bracket measures 7"W x 3"H.  Hose is not included.
            model                             MODEL                             OVERALL SIZE    USABLE    WEIGHT
            REEL-16L                          NUMBER         DESCRIPTION         (W x D x H)    SPACE    (POUND)
                                           REEL-16L�        ARM STYLE         14" x 17¾" x 18"   5"        14
                                          Electric Cord Reels     115V 1-PHASE STANDARD
                                          Help eliminate the danger of tangled electrical cords with these Electric Cord Reels. The compact design
                                          is spring retractable and engineered for industrial use. Complete with 4 foot pigtail and three prong
                                          plug. 115V, 60 Hz single phase. Ideal for indoor non-weather tight applications only. UL listed and CSA
                                          certified.
                   model                  Model ECR-45-S comes with a 15 AMP 3 wire single receptacle with clamp type strain relief.
                   ECR-45-S               Model ECR-45-D features a duplex outlet box and ground fault circuit interrupter.
                                          Comes with a 20 AMP 3 wire double receptacle.
                                          Model ECR-50 has an incandescent lamp and single receptacle. Head has tool tap, push through
                                          winch and metal grounded guard. 75 watt bulb maximum. Bulb not included.
                                              MODEL                                                      WEIGHT
                               model          NUMBER          DESCRIPTION        CORD LENGTH  WIRE GAUGE  (POUND)
                               ECR-45-D    ECR-45-S    SINGLE RECEPTACLE          45 FEET        12        24
                                           ECR-45-D    DOUBLE RECEPTACLE          45 FEET        12        31
                                           ECR-50      LAMP WITH RECEPTACLE       50 FEET        16        25
                          model
                          ECR-50
