                               Standard Slope Ladders
       INDUSTRIAL & COMMERCIAL LADDERS
                               Portable Warehouse Ladders for every-day use applications. Heavy-duty uniform weight capacity is 350 lb.
                               Features 58° standard climb angle. Choose either Perforated or Grip-Strut steps. Step depth is 7" with a top step
                               depth of 14". Welded square tubular steel construction with powder coat blue finish. Rubber feet provided for
                               floor protection. Units with 2-5 steps have two (2) all directional spring-loaded swivel casters and two (2) swivel
                               casters with total locks. Units with 6 to 12 steps have bottom step lock casters for safe use when climbing. Ships
            model LAD-PW-26-2-P-NHR  knockdown. Ladders comply with OSHA 1910.29, ANSI A14.7 standards.
                               The ESD-Safe Design features anti-static properties; conductive semi-gloss black baked-in powder-coated toughness,
                               conductive wheels which features gray rubber tread on polyolefin core, and grounding drag chain with resistor,
                               nickle-plated brass construction. Note ladders must be used on conductive floors to comply with ESD properties.
                               Ladders comply with OSHA 1910.29, ANSI A14.7, ANSI S20.20 standards.
                                 NO. OF   TOP STEP     OVERALL      WEIGHT        MODEL              MODEL
                                 STEPS    (W x D)      (W x D x H)  (POUND)      NUMBER             NUMBER
                                NO HANDRAIL                                   GRIP STRUT STEPS   PERFORATED STEPS
                                                     7
                                                          1
                                         13
                                   2    16 /16" x 14"  20 /8" x 25 /16" x 20"  79  LAD-PW-18-2-G-NHR  LAD-PW-18-2-P-NHR
                                                     7
                                         13
                                                          9
                                   3    16 /16" x 14"  20 /8" x 31 /16" x 30"  89  LAD-PW-18-3-G-NHR  LAD-PW-18-3-P-NHR
                                         13
                                                           5
                                   4    16 /16" x 14"  20 /8" x 38 /8" x 40"  102  LAD-PW-18-4-G-NHR  LAD-PW-18-4-P-NHR
                                                     7
                                          9
                                                     5
                                   2    23 /16" x 14"  27 /8" x 25 /16" x 20"  92  LAD-PW-26-2-G-NHR  LAD-PW-26-2-P-NHR
                                                          1
                                   3    23 /16" x 14"  27 /8" x 31 /16" x 30"  101  LAD-PW-26-3-G-NHR  LAD-PW-26-3-P-NHR
                                                     5
                                          9
                                                          9
                                   4    23 /16" x 14"  27 /8" x 38 /8" x 40"  115  LAD-PW-26-4-G-NHR  LAD-PW-26-4-P-NHR
                                          9
                                                           5
                                                     5
                                                     5
                                                           1
                                   2    30¼" x 14"  34 /16" x 25 /16" x 20"  95  LAD-PW-32-2-G-NHR  LAD-PW-32-2-P-NHR
                                                     5
                                                           9
                                   3    30¼" x 14"  34 /16" x 31 /16" x 30"  111  LAD-PW-32-3-G-NHR  LAD-PW-32-3-P-NHR
                                                     5
                                                           5
                                   4    30¼" x 14"  34 /16" x 38 /8" x 40"  128  LAD-PW-32-4-G-NHR  LAD-PW-32-4-P-NHR
                                HANDRAIL INCLUDED                             GRIP STRUT STEPS   PERFORATED STEPS
                                         13
                                                          1
                                                     7
                                   2    16 /16" x 14"  20 /8" x 34 /16" x 50"  95  LAD-PW-18-2-G  LAD-PW-18-2-P
                                         13
                                   3    16 /16" x 14"  20 /8" x 34 /16" x 60"  106  LAD-PW-18-3-G  LAD-PW-18-3-P
                                                     7
                                                          5
                                         13
                                                          7
                                                     7
                                   4    16 /16" x 14"  20 /8" x 40 /16" x 70"  120  LAD-PW-18-4-G  LAD-PW-18-4-P
                                                     7
                                                          5
                                         13
                                   5    16 /16" x 14"  20 /8" x 47 /16" x 80"  150  LAD-PW-18-5-G  LAD-PW-18-5-P
                                                          1
                                                     5
                                          9
                                   2    23 /16" x 14"  27 /8" x 34 /16" x 50"  104  LAD-PW-26-2-G  LAD-PW-26-2-P
                                          9
                                                     5
                                   3    23 /16" x 14"  27 /8" x 34 /16" x 60"  118  LAD-PW-26-3-G  LAD-PW-26-3-P
                                                          5
            model LAD-PW-26-6-G
                                                          7
                                   4    23 /16" x 14"  27 /8" x 40 /16" x 70"  133  LAD-PW-26-4-G  LAD-PW-26-4-P
                                          9
                                                     5
                                   5    23 /16" x 14"  27 /8" x 47 /16" x 80"  150  LAD-PW-26-5-G  LAD-PW-26-5-P
                                          9
                                                     5
                                                          5
                                   2    30¼" x 14"  34 /16" x 34 /16" x 50"  112  LAD-PW-32-2-G  LAD-PW-32-2-P
                                                           1
                                                     5
                                                     5
                                                           5
                                   3    30¼" x 14"  34 /16" x 34 /16" x 60"  128  LAD-PW-32-3-G  LAD-PW-32-3-P
                                                           7
                                                     5
                                   4    30¼" x 14"  34 /16" x 40 /16" x 70"  146  LAD-PW-32-4-G  LAD-PW-32-4-P
                                                           5
                                                     5
                                   5    30¼" x 14"  34 /16" x 47 /16" x 80"  167  LAD-PW-32-5-G  LAD-PW-32-5-P
                                HANDRAIL INCLUDED                             GRIP STRUT STEPS   PERFORATED STEPS
                                                           1
                                         13
                                   6    16 /16" x 14"  23 /16" x 50 /8" x 90"  183  LAD-PW-18-6-G  LAD-PW-18-6-P
                                                     13
                                                    13
                                   7    16 /16" x 14"  23 /16" x 56¼" x 100"  201  LAD-PW-18-7-G  LAD-PW-18-7-P
                                         13
            BOTTOM STEP LOCKS             9               3
            CASTERS FOR SAFE       6    23 /16" x 14"  29¾" x 50 /16" x 90"  220  LAD-PW-26-6-G  LAD-PW-26-6-P
                                          9
                                                          5
            CLIMBING ON UNITS      7    23 /16" x 14"  29¾" x 56 /16" x 100"  237  LAD-PW-26-7-G  LAD-PW-26-7-P
            WITH 6 TO 12 STEPS
                                                          3
                                          9
                                   8    23 /16" x 14"  29¾" x 63 /16" x 110"  255  LAD-PW-26-8-G  LAD-PW-26-8-P
                                                          15
                                          9
                                   9    23 /16" x 14"  29¾" x 68 /16" x 120"  273  LAD-PW-26-9-G  LAD-PW-26-9-P
              CA Residents see            9         9     1                LAD-PW-26-10-G      LAD-PW-26-10-P
            WARNING C, Pg. 459    10    23 /16" x 14"  30 /16" x 75 /8" x 130"  300
                                          9
                                  11    23 /16" x 14"  33 /16" x 81 /8" x 140"  316  LAD-PW-26-11-G  LAD-PW-26-11-P
                                                    9
                                                          3
                                  12    23 /16" x 14"  33 /16" x 87 /8" x 156"  324  LAD-PW-26-12-G  LAD-PW-26-12-P
                                          9
                                                          5
                                                    9
                                   6    30¼" x 14"  38 /16" x 50 /8" x 90"  332  LAD-PW-32-6-G  LAD-PW-32-6-P
                                                           1
                                                     15
                                                    15
                                   7    30¼" x 14"  38 /16" x 56¼" x 100"  340  LAD-PW-32-7-G  LAD-PW-32-7-P
                                                           1
                                                    15
                                   8    30¼" x 14"  38 /16" x 63 /8" x 110"  348  LAD-PW-32-8-G  LAD-PW-32-8-P
                                                    15
                                                           7
                                   9    30¼" x 14"  38 /16" x 68 /8" x 120"  356  LAD-PW-32-9-G  LAD-PW-32-9-P
                                  10    30¼" x 14"  38 /16" x 75 /8" x 130"  362  LAD-PW-32-10-G  LAD-PW-32-10-P
                                                           1
                                                    15
            model LAD-TT-B        11    30¼" x 14"  38 /16" x 81 /8" x 140"  372  LAD-PW-32-11-G  LAD-PW-32-11-P
                                                    15
                                                           3
                                                           5
                                                    15
                                  12    30¼" x 14"  38 /16" x 87 /8" x 156"  394  LAD-PW-32-12-G  LAD-PW-32-12-P
                                ESD - SAFE DESIGN                             GRIP STRUT STEPS   PERFORATED STEPS
                                                           1
                                          9
                                                     3
                                   2    23 /16" x 14"  27 /16" x 34 /16" x 50"  101  LAD-PW-26-2-G-ESD  ---
                                                           7
                                                     3
                                          9
                                   4    23 /16" x 14"  27 /16" x 40 /16" x 70"  110  LAD-PW-26-4-G-ESD  ---
                                          9
                                                          3
                                   6    23 /16" x 14"  29¾" x 50 /16" x 90"  227  LAD-PW-26-6-G-ESD   ---
                                                          3
                                   8    23 /16" x 14"  29¾" x 63 /16" x 110"  261  LAD-PW-26-8-G-ESD  ---
                                          9
                                  10    23 /16" x 14"  33 /16" x 75 /8" x 130"  308  LAD-PW-26-10-G-ESD  ---
                                          9
                                                     9
                                                          1
                                  12    23 /16" x 14"  33 /16" x 87 /8" x 156"  370  LAD-PW-26-12-G-ESD  ---
                                                          5
                                          9
                                                     9
            model ESD-WGW
                                OPTIONS
                                   MODEL NUMBER                             DESCRIPTION
                                LAD-TT-A         LADDER TOOL TRAY FOR PREFIX LAD-PW-18
                                LAD-TT-B         LADDER TOOL TRAY FOR PREFIX LAD-PW-26
                                LAD-TT-C         LADDER TOOL TRAY FOR PREFIX LAD-PW-32
                                LAD-TT-E         LADDER TOOL TRAY FOR PREFIX LAD-PW-ESD
                                ESD-WGW          OPTIONAL USER GROUNDING STRAP, ELASTIC ADJUSTABLE WRIST STRAP
                                ESD-HGW          OPTIONAL USER GROUNDING STRAP, HEEL STRAP
            model ESD-HGW       ESD-GW-15        OPTIONAL LADDER TETHERED GROUNDING STRAP; 15 FT. COIL CORD
