       INDUSTRIAL/COMMERCIAL CARTS & DOLLIES
                                                Heavy Duty Aluminum Treadplate Platform Trucks

                                                Heavy duty, extra strong, corrosion resistant platform trucks are ideal for handling all
                                                types of materials.  Non-slip 5 bar aluminum tread plate. Box style frame is made of high
                                                strength welded aluminum channel.  Removable aluminum handle can be placed on
                                                both or either end of the platform truck.  Single or double aluminum handles available.
                                 5 BAR TREAD
                                                Ergonomically designed to reduce the chance of injury, fatigue and muscle strain.  Fitted
                                                with non-marking rubber buffer strip to protect walls and door frames during transit.  Two
                                         model
                                      ATP-C-2448  (2) swivel and two (2) rigid 6" x 1⅝" poly-on-poly casters.  Ideal for supermarkets, food
                                                industry, schools, and warehouses.
                                                      MODEL     USABLE DECK  DECK  UNIFORM                WEIGHT
                                                     NUMBER       (W x L)  HEIGHT  CAPACITY  CASTER TYPE  (POUND)
                                                 SINGLE HANDLE
                                                 ATP-C-2436     24" x 36"  10¼"  3,600 lb.  POLY-ON-POLY  55
                                                 ATP-C-2448     24" x 48"  10¼"  3,600 lb.  POLY-ON-POLY  62
                                                 ATP-C-2460     24" x 60"  10¼"  3,600 lb.  POLY-ON-POLY  88
                                                 ATP-C-3048     30" x 48"  10¼"  3,600 lb.  POLY-ON-POLY  66
                                                 ATP-C-3060     30" x 60"  10¼"  3,600 lb.  POLY-ON-POLY  112
                                                 ATP-C-3672     36" x 72"  10¼"  3,600 lb.  POLY-ON-POLY  124
                                                 ATP-C-HDL                 ADDITIONAL HANDLE               5
                                                 DUAL HANDLE
                                                 ATP-C-2436-2HDL  24" x 33"  10¼"  3,600 lb.  POLY-ON-POLY  60
                                                 ATP-C-2448-2HDL  24" x 45"  10¼"  3,600 lb.  POLY-ON-POLY  73
                                         model
                                   ATP-C-3048-2HDL  ATP-C-2460-2HDL  24" x 57"  10¼"  3,600 lb.  POLY-ON-POLY  92
                                                 ATP-C-3048-2HDL  30" x 45"  10¼"  3,600 lb.  POLY-ON-POLY  70
                                                 ATP-C-3060-2HDL  30" x 57"  10¼"  3,600 lb.  POLY-ON-POLY  119
                                                 ATP-C-3672-2HDL  36" x 69"  10¼"  3,600 lb.  POLY-ON-POLY  129




                                                Heavy-Duty Extruded Aluminum Platform Trucks

                                                These all welded aluminum trucks are built to handle your heaviest loads. Includes one
                                         model
                                      EFHD-3048  removable high polished steel handle, additional handle available. Rolls smoothly on two
                                                (2) rigid and two (2) swivel 8" x 2" casters. Ideal for industrial and warehouse areas.
                                                   MODEL      DECK SIZE   DECK    UNIFORM STATIC   CASTER  WEIGHT
                                                   NUMBER      (W x L)   HEIGHT     CAPACITY     TYPE     (POUND)
                                                 EFHD-2448    24" x 48"   13 /8"    4,800 lb.    GFN*      145
                                                                           3
                                                 EFHD-3048    30" x 48"   13 /8"    4,800 lb.    GFN*      152
                                                                           3
                                                 EFHD-3060    30" x 60"   13 /8"    4,800 lb.    GFN*      176
                                                                           3
                                                 EFHD-3672    36" x 72"   13 /4"    4,800 lb.    GFN*      190
                                                                           1
                                                HANDLE DESIGN MAY VARY FROM WHAT IS SHOWN
                                                *GLASS-FILLED NYLON


                                                Aluminum Folding Handle Platform Trucks
                                                For safe transportation of stacks of paper, small parts, and other lightweight products. Ideal
                                                for maintenance rooms, offices, schools, hospitals, etc. Plastic corner protectors enhance
                                                durability and protect surroundings. Rugged aluminum construction with single folding
                                                handle design.  Units roll smoothly on non-marking polyurethane casters.

                                                    MODEL     HANDLE     DECK SIZE  UNIFORM STATIC   CASTER  WEIGHT
                                                   NUMBER      TYPE      (W x L x H)  CAPACITY   QTY./SIZE  (POUND)
                                                 AFT-30-NM  SINGLE   18½" x 30" x 6 /16""  400 lb.  4 / 4"   26
                                                                                5
                                                                                3
                                   model AFT-48-NM  AFT-36-NM  SINGLE  24" x 36" x 8 /8"  600 lb.  4 / 5"  36
                                                                                3
                                                 AFT-48-NM  SINGLE    24" x 48" x 8 /8"  600 lb.  4 / 5"   38

             CASTERS MAY NOT BE
                ATTACHED FOR
              SHIPPING PURPOSES
