104                            Multi-Purpose Tote Dumpers          12V DC STD, OPTIONS ON PG. 108
       ERGONOMIC SOLUTIONS                 for schools, hospitals, commercial, and industrial applications. One person can easily and safely


                                           Collect, transport, and dump materials while saving time and reducing work related injuries. Ideal
                                           empty loads weighing up to 600 pounds. To use, roll the tote into dumper, secure tote in place,
                                           and depress the 24V hand control. The tote will rotate over 135° to dump contents. Dump time is
                                           approximately 25 seconds. Standard features: Two (2) 8" x 2" glass filled nylon front wheels, Two (2)
                                           8" x 3" phenolic rear casters, floor lock, 12V DC power, hand pendant control on 8 foot coil cord,
                                           and one (1) MPT-1 polyethylene tote.  To operate under full capacity, purchase model MPT-2.
                                                                                           OVERALL SIZE
                                                                                                          WEIGHT
                                               MODEL
                                                           DUMP
                                                                               CAPACITY
                                                                                              (W x L)
                                              NUMBER
                                                                     HEIGHT
                                            JMD-1000-48
                                                                     105¾"
                                                                                                          1061
                                                           48"
                                                                                600 lb.
                                                                                                  1
                                            JMD-1000-60
                                                                                           57¼" x 65 /8"
                                                                                                          1075
                                                                     117¾"
                                                                                                  1
                                                           60"
                                                                                600 lb.
                                            JMD-1000-72   HEIGHT     ROTATED   UNIFORM     57¼" x 65 /8"  (POUND)
                                                                                                  1
                                                                     129¾"
                                                                                                          1099
                                                           72"
                                                                                600 lb.
                                                                                           57¼" x 65 /8"
                                                        ADDITIONAL ½ CUBIC YARD POLYETHYLENE TOTE
                                            MPT-1�                                                         128
                                                        CAPACITY 200 LB. - OVERALL SIZE: 52½"W x 30¾"D x 41 13 / 16 "H
                                                        ½ CUBIC YARD POLYETHYLENE TOTE
                                            MPT-2�                                                         200
                                                        CAPACITY 600 LB. - OVERALL SIZE: 52½"W x 30¾"D x 42 5 / 16 "H
                                           Tilt Master & Tilt Master Straddle
                                           Lift and position filled tote boxes or baskets without the need of a fork truck or lift table using the
                                  SKID ONLY
                                           newly designed heavy-duty Tilt Master.  These 90° tilters will function as transporters by moving
                                           completed products from work station to work station without waiting for a fork truck.
            TILT MASTER           NO PALLET  A folding ergonomic handle comes standard for quick and easy maneuverability.  Unit has a thin
            Only 10½" of Reach!            profile to allow the user to get as close to the load as possible.  Units roll easily on 8" x 3" phenolic
                                           steering wheels.  Floor lock standard.  Series TM is designed to be used with open bottom pallets
                                           or skids only. The Tilt Master Straddle units, series TMS, can be used with virtually any kind of
                                           container or pallet.  Units come standard with a hand pendant control on an 8 foot coil cord.
                                    SKID   Three power options to choose from.
                                           Suffix -AC is 115V, 1 phase power with a push-button hand control.
                                           Suffix -DC includes one (1) 12V battery, push-button hand control, on-board charger and battery
                                   PALLET  charge indicator gauge.
                                           Suffix -AIR features reciprocating air/oil power with a heel/toe foot treadle control.
            TILT MASTER STRADDLE
            Only 13½" of Reach!
                                            TILT MASTER & TILT MASTER STRADDLE OPTIONS
                                               MODEL                                                      WEIGHT
                                              NUMBER                       DESCRIPTION                   (POUND)
                                            TM-CHUTE    RETROFIT CHUTE OPTION                              18
                                            TM-PTDS*    POWER TRACTION DRIVE SYSTEM, (2) 12V BATTERIES     206
                                series TMS with  FC-2   FOOT CONTROL (AC & DC only)                        6
                                model TM-PTDS
                MODEL                UNIFORM      FORK     OPERATOR  FORK  ROTATED LOWERED  OVERALL SIZE   WEIGHT
               NUMBER     DESCRIPTION  CAPACITY     ADJUSTMENT  REACH  WIDTH  HEIGHT  HEIGHT  (W x L x H)  (POUND)
             TILT MASTER
             TM-20-AC     115V / 1PH  2,000 lb.  Fixed @ 26" (OD)  7¼"  6"  33"   3 /8"   41" x 75 /16" x 28 /16"  646
                                                                                  5
                                                                                                      5
                                                                                                9
             TM-20-DC      12V DC   2,000 lb.  Fixed @ 26" (OD)  7¼"  6"   33"    3 /8"   41" x 75 /16" x 28 /16"  767
                                                                                                9
                                                                                  5
                                                                                                      5
             TM-20-AIR     AIR/OIL  2,000 lb.  Fixed @ 26" (OD)  7¼"  6"   33"    3 /8"   41" x 75 /16" x 28 /16"  621
                                                                                  5
                                                                                                      5
                                                                                                9
             TM-40-AC     115V / 1PH  4,000 lb.  Fixed @ 26" (OD)  7¼"  6"  33"   3 /8"   41" x 75 /16" x 28 /16"  707
                                                                                                      5
                                                                                                9
                                                                                  5
             TM-40-DC      12V DC   4,000 lb.  Fixed @ 26" (OD)  7¼"  6"   33"    3 /8"   41" x 75 /16" x 28 /16"  781
                                                                                  5
                                                                                                9
                                                                                                      5
             TM-40-AIR     AIR/OIL  4,000 lb.  Fixed @ 26" (OD)  7¼"  6"   33"    3 /8"   41" x 75 /16" x 28 /16"  631
                                                                                                9
                                                                                                      5
                                                                                  5
             TM-60-AC     115V / 1PH  6,000 lb.  Fixed @ 27" (OD)  7¼"  6"*  33"  3 /8"   41" x 75 /16" x 28 /16"  739
                                                                                  5
                                                                                                9
                                                                                                      5
             TM-60-DC      12V DC   6,000 lb.  Fixed @ 27" (OD)  7¼"  6"*  33"    3 /8"   41" x 75 /16" x 28 /16"  777
                                                                                                      5
                                                                                  5
                                                                                                9
             TM-60-AIR     AIR/OIL  6,000 lb.  Fixed @ 27" (OD)  7¼"  6"*  33"    3 /8"   41" x 75 /16" x 28 /16"  851
                                                                                                      5
                                                                                  5
                                                                                                9
             TILT MASTER STRADDLE
             TMS-20-AC    115V / 1PH  2,000 lb.  ½" to 28½" (ID)  13½"  4"  37"   3"     57¼" x 72 /16" x 29 /4"  989
                                                                                                13
                                                                                                       1
             TMS-20-DC     12V DC   2,000 lb.  ½" to 28½" (ID)  13½"  4"   37"    3"     57¼" x 72 /16" x 29 /4"  1017
                                                                                                       1
                                                                                                13
             TMS-20-AIR    AIR/OIL  2,000 lb.  ½" to 28½" (ID)  13½"  4"   37"    3"     57¼" x 72 /16" x 29 /4"  886
                                                                                                       1
                                                                                                13
             TMS-40-AC    115V / 1PH  4,000 lb.  ½" to 28½" (ID)  13½"  4"  37"   3"     57¼" x 72 /16" x 29 /4"  953
                                                                                                13
                                                                                                       1
             TMS-40-DC     12V DC   4,000 lb.  ½" to 28½" (ID)  13½"  4"   37"    3"     57¼" x 72 /16" x 29 /4"  1046
                                                                                                13
                                                                                                       1
             TMS-40-AIR    AIR/OIL  4,000 lb.  ½" to 28½" (ID)  13½"  4"   37"    3"     57¼" x 72 /16" x 29 /4"  893
                                                                                                       1
                                                                                                13
             TMS-60-AC    115V / 1PH  6,000 lb.  ½" to 28½" (ID)  13½"  4"  37"   3"     57¼" x 72 /16" x 29 /4"  978
                                                                                                       1
                                                                                                13
             TMS-60-DC     12V DC   6,000 lb.  ½" to 28½" (ID)  13½"  4"   37"    3"     57¼" x 72 /16" x 29 /4"  1067
                                                                                                       1
                                                                                                13
             TMS-60-AIR    AIR/OIL  6,000 lb.  ½" to 28½" (ID)  13½"  4"   37"    3"     57¼" x 72 /16" x 29 /4"  967
                                                                                                13
                                                                                                       1
            *6½" WITH STIFFENER
