P. 20

112                         High Lift Trucks
       ERGONOMIC SOLUTIONS  model       a very steady working platform, minimizing rocking and movement in all directions.  Stabilizers  425

                                        Ideal for skids, baskets, and work applications.  Electric pump has chrome plated piston.  Features
                                        positioned at the rear improved balance, making work easier when lifting and working with heavy
                                        loads.  DC powered with 12V battery and a bench top charger.  Individual fork width is 6½".
                                                          OVERALL FORK
                                                           SIZE (W x L)
                                                           21" x 45"
                                                                                               (1) 12V
                                                                                   2,200 lb.
                                                           27" x 45"
                                                                                   2,200 lb.
                                                                                               (1) 12V
                                        High Tote Lifter    12V DC STANDARD
                                        A High Tote Lifter is a perfect asset for any food handling atmosphere.  The stainless steel
                                        construction is easily cleaned due to its smooth finish.  An open fork design allows for simple
                                        inspection for overall complete hygiene.  Products can be raised or lowered by utilizing the 12V
                                        DC powered hand pump.  When the unit has been raised, it minimizes the amount of bending and
                                        twisting that can occur when products are placed in the improper height location.  The wheeled
                           model        scissor base creates a steady base when in position to load or unload merchandise.  The overall
                                        compact design is easily stored when not in use.
                                               MODEL                      FORK SIZE  SERVICE   UNIFORM    WEIGHT
                                              NUMBER         OPERATION     (W x L)   RANGE     CAPACITY   (POUND)
                                         ULM-HTL-2149-20      12V DC      21" x 45"  3¾" to 31½"  2,000 lb.  427
                                        Designed to lift open bottom skids, boxes, and baskets. The manually operated lift is easy to operate.
                                        The foot pump operated lift travels approximately ½" per stroke. To lower unit simply squeeze the
                                        bicycle style grip located on the white push bar. The battery operated lift is ideal for positioning
                                        products at workstation heights for increased productivity. The up/down lever control is conveniently
                                        located on the power unit. DC powered units include one (1) 12V battery, an on-board charger and a
                           FOOT PUMP
                           model TAL-260-HD  battery charge indicator gauge. Polyurethane swivel casters with brake are standard on all units.
                                             MODEL                    FORK SIZE    UNIFORM      SERVICE   WEIGHT
                                             NUMBER     DESCRIPTION    (W x L)     CAPACITY     RANGE     (POUND)
                                         TAL-220-HD�    FOOT PUMP    21" x 43½"   2,200 lb.   3½" to 33"   356
                                         TAL-260-HD�    FOOT PUMP     27" x 43"   2,200 lb.   3½" to 33"   385
                                         TAL-220-DC�      12V DC      21" x 43"   2,200 lb.   3½" to 33"   471
                                         TAL-260-DC�      12V DC      27" x 43"   2,200 lb.   3½" to 33"   474
                           12V DC POWERED  TOTE-A-LOAD OPTIONS
                           model TAL-260-DC
                                             MODEL                                                        WEIGHT
                                             NUMBER                        DESCRIPTION                    (POUND)
                                         TAL-PLATE-21�      21¼" WIDE SOLID PLATFORM TO FIT OVER FORKS      36
                                         TAL-PLATE-27�      27¾" WIDE SOLID PLATFORM TO FIT OVER FORKS      38
                                        Basket & Skid Stackers
                SKID ONLY  NO PALLET
            APPLIES TO ABOVE PRODUCTS ON THIS PAGE  Transport open bottom pallets, skids, baskets, and crates with ease. Features an 18" horizontal load
                                        center and overall fork width of 26".  Units roll smoothly on 8" x 3" swivel phenolic rear casters.
                                        Handle height is 40".  DC powered units include one (1) 12V battery and an on-board charger.
                                        Optional reciprocating air/oil power with foot treadle control available, contact factory.
                                        Reduce worker fatigue and injury with our factory installed Power Traction Drive option. An alternative
                                        to costly fork trucks, the PMSS-PTDS-E includes combination throttle / direction and auto reverse
                                        emergency "belly" switch. This state of the art option allows a single operator to safely and easily move
                            SKID ONLY   products. Maximum speed is 2.5 m.p.h. 24V DC system
                                             MODEL        UNIFORM                  FORK SIZE    SERVICE   WEIGHT
                                             NUMBER      CAPACITY     OPERATION     (W x L)     RANGE     (POUND)
                            NO PALLET    PMSS-50-DC      4,000 lb.    12V DC       4" x 36"    3½" to 50"  989
                                         PMSS-50-AC      4,000 lb.    115V AC      4" x 36"    3½" to 50"  989
                                         PMSS-60-DC      4,000 lb.    12V DC       4" x 36"    3½" to 60"  959
                                         PMSS-60-AC      4,000 lb.    115V AC      4" x 36"    3½" to 60"  1032
                                         PMSS-PTDS-E              POWER TRACTION DRIVE SYSTEM              600
