INDUSTRIAL STORAGE SOLUTIONS
Cantilever Rack Kits
Cantilever Racks are ideal for eliminating storage problems. The steel constructed design allows for
quick and efficient handling by forklift or by hand. The rack includes pre-drilled holes, adjustable
arms for access to variable heights, and front lipped arms to prevent items from falling. Available
in both single sided and double sided units with the option of standard, medium, or heavy duty
construction. Baked-in powder-coated toughness. *Capacity is per level.
MODEL *UNIFORM WEIGHT
NUMBER PACKAGE CONTENTS CAPACITY (POUND)
STANDARD-DUTY CANTILEVER RACK KITS
(2) SU-C-6-24 6' High Single-Sided Uprights,
SU-C-6-24-SET (1) SB-C-6-48 Brace Set, (4) SSA-C-24 24" Arms 800 lb. 382
(2) SU-C-8-24 8' High Single-Sided Uprights,
SU-C-8-24-SET (1) SB-C-8-48 Brace Set, (4) SSA-C-24 24" Arms 800 lb. 422
(2) SDU-C-6-24 6' High Double-Sided Uprights,
SDU-C-6-24-SET 1,600 lb. 516
(1) SB-C-6-48 Brace Set, (8) SSA-C-24 24" Arms
(2) SDU-C-6-36 6' High Double-Sided Uprights,
model SDU-C-6-36-SET 800 lb. 556
SU-C-6-24-SET (1) SB-C-6-48 Brace Set, (8) SSA-C-36 36" Arms
(shown assembled) MEDIUM-DUTY CANTILEVER RACK KITS
(2) MU-C-6-24 6' High Single-Sided Uprights,
MU-C-6-24-SET 1,200 lb. 482
(1) MB-C-6-48 Brace Set, (4) MSA-C-24 24" Arms
(2) MU-C-8-24 8' High Single-Sided Uprights,
MU-C-8-24-SET 1,200 lb. 522
(1) MB-C-8-48 Brace Set, (4) MSA-C-24 24" Arms
(2) MDU-C-6-24 6' High Double-Sided Uprights,
MDU-C-6-24-SET 2,400 lb. 618
(1) MB-C-6-48 Brace Set, (8) MSA-C-24 24" Arms
(2) MDU-C-6-36 6' High Double-Sided Uprights,
MDU-C-6-36-SET 1,600 lb. 810
(1) MB-C-6-48 Brace Set, (8) MSA-C-36 36" Arms
HEAVY-DUTY CANTILEVER RACK KITS
(2) HU-C-8-36 8' High Single-Sided Uprights,
HU-C-8-36-SET 2,400 lb. 810
(1) HB-C-8-6 Brace Set, (4) HSA-C-36 36" Arms
(2) HDU-C-8-24 8' High Double-Sided Uprights,
HDU-C-8-24-SET 8,000 lb. 890
(1) HB-C-8-6 Brace Set, (8) HSA-C-24 24" Arms
(2) HDU-C-8-36 8' High Double-Sided Uprights,
HDU-C-8-36-SET 4,800 lb. 1016
(1) HB-C-8-6 Brace Set, (8) HSA-C-36 36" Arms
Galvanized Cantilever Rack Kits
Galvanized Cantilever Rack systems are ideal for distributing and industrial settings. The galvanized
model steel design minimizes rust while providing a strong construction. The adjustable rack arms can
HDU-C-8-36-SET be adapted to a customized position allowing the unit to fit the needs of individual circumstances.
(shown assembled)
*Capacity is per level.
MODEL *UNIFORM WEIGHT
NUMBER PACKAGE CONTENTS CAPACITY (POUND)
STANDARD-DUTY GALVANIZED CANTILEVER RACK KITS
(2) SU-C-6-24-G 6' High Single-Sided Uprights,
SU-C-6-24-G-SET 800 lb. 382
(1) SB-C-6-48-G Brace Set, (4) SSA-C-24-G 24" Arms
(2) SU-C-8-24-G 8' High Single-Sided Uprights,
SU-C-8-24-G-SET 800 lb. 422
(1) SB-C-8-48-G Brace Set, (4) SSA-C-24-G 24" Arms
(2) SDU-C-6-24-G 6' High Double-Sided Uprights,
SDU-C-6-24-G-SET 1,600 lb. 516
(1) SB-C-6-48-G Brace Set, (8) SSA-C-24-G 24" Arms
(2) SDU-C-6-36-G 6' High Double-Sided Uprights,
SDU-C-6-36-G-SET 800 lb. 556
(1) SB-C-6-48-G Brace Set, (8) SSA-C-36-G 36" Arms
MEDIUM-DUTY GALVANIZED CANTILEVER RACK KITS
(2) MU-C-6-24-G 6' High Single-Sided Uprights,
MU-C-6-24-G-SET 1,200 lb. 482
(1) MB-C-6-48-G Brace Set, (4) MSA-C-24-G 24" Arms
(2) MU-C-8-24-G 8' High Single-Sided Uprights,
MU-C-8-24-G-SET 1,200 lb. 522
(1) MB-C-8-48-G Brace Set, (4) MSA-C-24-G 24" Arms
(2) MDU-C-6-24-G 6' High Double-Sided Uprights,
MDU-C-6-24-G-SET 2,400 lb. 618
(1) MB-C-6-48-G Brace Set, (8) MSA-C-24-G 24" Arms
(2) MDU-C-6-36-G 6' High Double-Sided Uprights,
model MDU-C-6-36-G-SET (1) MB-C-6-48-G Brace Set, (8) MSA-C-36-G 36" Arms 1,600 lb. 810
HDU-C-8-24-G-SET
(shown assembled) HEAVY-DUTY GALVANIZED CANTILEVER RACK KITS
(2) HU-C-8-36-G 8' High Single-Sided Uprights,
HU-C-8-36-G-SET 2,400 lb. 810
(1) HB-C-8-6-G Brace Set, (4) HSA-C-36-G 36" Arms
CA Residents see (2) HDU-C-8-24-G 8' High Double-Sided Uprights,
WARNING A, Pg. 459 HDU-C-8-24-G-SET 8,000 lb. 890
(1) HB-C-8-6-G Brace Set, (8) HSA-C-24-G 24" Arms
(2) HDU-C-8-36-G 8' High Double-Sided Uprights,
HDU-C-8-36-G-SET 4,800 lb. 1016
(1) HB-C-8-6-G Brace Set, (8) HSA-C-36-G 36" Arms
