          Speed Bumps

          Help control drivers in dangerous, areas while protecting people and property.  One person
          installation.  Can be removed for seal coating, snow removal, or change of location.  Resists marring
          by oil, road salt, sunlight, and chemicals.  Feature dual 1"W x ¾"H cable channels and includes
          hardware.  Constructed of lightweight recycled plastic. Compression strength is 3,200 pounds per
          square inch.  The concrete hardware kit includes bolts, anchors, and washers. Asphalt kit includes       FACILITY MAINTENANCE
          spikes and butyl tape.  The HD asphalt kit includes anchors and bolts. The HD anchor should be
          epoxied (epoxy not included) into the ground and then the speed bump is secured to that anchor
          with a bolt. The glue down anchor plate kit includes anchor plates, T-nuts, bolts, and washers.
          Requires 2-3 ounces of either 2-part epoxy or heavy duty construction adhesive to the bottom of
          each anchor plate, which is not included.

               MODEL       OVERALL SIZE   TYPE OF HARDWARE  NUMBER OF     WEIGHT
              NUMBER        (W x L x H)     KIT INCLUDED  MOUNTING HOLES  (POUND)
           SB-48�          10" x 48" x 2"  CONCRETE            3           17
           SBA-48�         10" x 48" x 2"   ASPHALT            3           19
           SBHA-48�        10" x 48" x 2"  HD ASPHALT          3           19
           SBG-48�         10" x 48" x 2"  GLUE-DOWN           3           17
           SBD-48*�        12" x 48" x 2¼"  CONCRETE           3           26                     Features dual 1" x ¾"
           SBDA-48*�       12" x 48" x 2¼"  ASPHALT            3           29                       cable channels
           SBDHA-48*�      12" x 48" x 2¼"  HD ASPHALT         3           29
           SBDG-48*�       12" x 48" x 2¼"  GLUE-DOWN          3           26
           SB-36�          10" x 72" x 2"  CONCRETE            4           26
           SBA-36�         10" x 72" x 2"   ASPHALT            4           29
           SBHA-36�        10" x 72" x 2"  HD ASPHALT          4           28
           SBG-36�         10" x 72" x 2"  GLUE-DOWN           4           26
           SBD-72�         12" x 72" x 2¼"  CONCRETE           4           40
           SBDA-72�        12" x 72" x 2¼"  ASPHALT            4           43                      SBD-48, SBDA-48,
                                                                                                  SBDHA-48, & SBDG-48
           SBDHA-72�       12" x 72" x 2¼"  HD ASPHALT         4           43                      do not have cable
           SBDG-72�        12" x 72" x 2¼"  GLUE-DOWN          4           40                         channels.
           SB-108�         10" x 106" x 2"  CONCRETE           5           39
           SBA-108�        10" x 106" x 2"  ASPHALT            5           45
           SBHA-108�       10" x 106" x 2"  HD ASPHALT         5           45
           SBG-108�        10" x 106" x 2"  GLUE-DOWN          5           39          REFLECTIVE
           SBS-1012�               REFLECTIVE SPEED BUMP SIGN               2        SPEED BUMP SIGN   CA Residents see
           SBE-12**            END CAPS FOR STANDARD SPEED BUMPS            9         model SBS-1012  WARNING B, Pg. 459
          *Models do not have cable channels.                                    .
          **End caps only work with 10" W x 2" H sized speed bumps
          See additional anchor kits below.


          Speed Bump Anchor Kits

          Speed Bump Anchor Kits are a great addition to the facility maintenance department. The kit supplies
          a solution to securing speed bumps to a surface. The unit is designed of a strong construction that is
          resilient and long lasting throughout the harshest environments. Once the anchoring is in place, the
          speed bumps are ready for use. The kit is available in both glue down and asphalt anchor style.

                                                                                            model SB-72-AK
           SPEED BUMP OPTIONS
               MODEL                                           USE WITH   WEIGHT
               NUMBER               DESCRIPTION               # OF HOLES  (POUND)
           SB-48-AK�       ASPHALT KIT FOR 48 MODELS              3         4
           SB-36-AK�       ASPHALT KIT FOR 36 MODELS              4         5
           SB-108-AK�      ASPHALT KIT FOR 108 MODELS             5         6
           SB-HD-AK-3�     HEAVY DUTY ASPHALT HARDWARE KIT        3         7
           SB-HD-AK-4�     HEAVY DUTY ASPHALT HARDWARE KIT        4         9
           SB-HD-AK-5�     HEAVY DUTY ASPHALT HARDWARE KIT        5        10
           SB-48-GDK�      GLUE DOWN KIT FOR 48 MODELS            3         2               model SB-48-GDK
           SB-36-GDK�      GLUE DOWN KIT FOR 36 MODELS            4         3
           SB-108-GDK�     GLUE DOWN KIT FOR 108 MODELS           5         3
