58                         Work Station Fans      115V 1-PHASE STANDARD
       FACILITY MAINTENANCE FACILITIES MAINTENANCE  model WSF-12  with one bolt or lag screw to walls, ceilings, work benches, machines or any surface. Pull chain switch


                                       Three speed, 115V, 1 phase, totally enclosed, permanently lubricated motor Work Station Fan. Mount
                                       on a 10 foot long SJT type 3 conductor cord. Meets OSHA standards and is ETL C/US listed.


                                                                                                          WEIGHT
                                                                                          CFM
                                                                                                   CFM
                                                            MOUNTING
                                                                      AMPS
                                                    BLADE
                                                                                CFM
                                          MODEL
                                                                                HIGH
                                                                                          MED
                                                                      HIGH
                                                   DIAMETER
                                                                                                          (POUND)
                                         NUMBER
                                                             STYLE
                                                                                                   LOW
                                        WSF-12
                                                                       1.1
                                                                                                   1120
                                                             WALL
                                                     12"
                                                                                                            17
                                                                                1650
                                                                                          1420
                                        WSF-18
                                                     18"
                                                                                          4200
                                                                                                            26
                                                                                4600
                                                                       2.2
                                                                                                   3200
                                                             WALL
                            model WSF-18-F
                                        WSF-18-F
                                                            FLOOR
                                                                       1.5
                                                     18"
                                       High Performance Circulator Fans         4600      4200     3200     23
                                                                                115V 1-PHASE STANDARD
                                       Two speed, 115V, 1 phase, ball bearing, totally enclosed, and permanently lubricated Industrial Duty
                                       Circulator Fan. Pull chain switch with a 12 foot long SJT type 3 conductor cord. Meets OSHA standards
                                       and is ETL C/US listed. ⅓ HP electric motor.
                                           MODEL      BLADE     MOUNTING    AMPS       CFM        CFM     WEIGHT
                                          NUMBER     DIAMETER    STYLE      HIGH       HIGH       LOW     (POUND)
                                        HPCR-30-P      30"     PEDESTAL      3.4       8200       6200      75
            model                       HPCR-30-W      30"       WALL        3.4       8200       6200      48
            HPCR-30-I
                   model       model    HPCR-30-I      30"      I-BEAM       3.4       8200       6200      51
                   HPCR-30-W   HPCR-30-C  HPCR-30-C    30"      CEILING      3.4       8200       6200      48
                                       Portable Work Station Fan       115V 1-PHASE STANDARD
                                       The three (3) speed, ball bearing, Portable Work Station Fan is totally enclosed and permanently
                                       lubricated. This fan has a rotary switch, 360° tilting head, 10 foot long SJT type 2 conductor cord, and
                                       coated steel guard. Steel hub/spider aluminum paddle blades and meets OSHA standards. Overall size is
                                       25"W x 27"L x 53"H. ETL C/US listed.
            model
            PWSF-18H-TE                     MODEL       BLADE     MOUNTING    CFM       CFM      CFM      WEIGHT
                                           NUMBER      DIAMETER    STYLE      HIGH     MEDIUM    LOW     (POUND)
                                        PWSF-18H-TE     18"      PEDESTAL     4600      4200     3200      35
                                       Shutter Mounted Exhaust Fans         115V 1-PHASE STANDARD
                                       Inside-building installation only with vents outside. Eliminate need for external framing and shutter.
                                       Ideally suited for thin wall buildings. Units are 115V, 1 phase totally enclosed and permanently
                                       lubricated. Pull chain switch. No cord. Junction box provided for direct wiring. Meets OSHA standards.
                                          MODEL      BLADE     MOTOR    AMPS     CFM       CFM     CFM    WEIGHT
                                          NUMBER    DIAMETER    HP       HIGH    HIGH     MED      LOW    (POUND)
                                        SME-12       12"       1/12      1.1     825      710      560      16
                                        SME-18       18"        1/8      2.2     2300     2100     1850     25
                                        SME-24       24"        1/4      2.5     3400      ---     2770     41
                                        SME-30       30"        1/4      2.7     3950      ---     3080     50
                         series SME
                                       Direct Drive Portable Blower       115V 1-PHASE STANDARD

                                       The two speed, 115V, 1 phase, ball bearing, Portable Blower has a totally enclosed motor.  The fan also
                                       features 3 paddle style steel blades and 8" rubber wheels.  It has a rocker switch with a 15'  SJT type 3
                                       conductor power cord.  Meets OSHA standards. ETL C/US listed.

            model
            DDB-36                        MODEL       BLADE       RPM      AMP       CFM        CFM       WEIGHT
                                         NUMBER      DIAMETER    HIGH      HIGH      HIGH       LOW       (POUND)
                                       DDB-36          36"       1100       5.5     12500       9000       110
