P. 7

55
          Car Stops

          Protect people and property from drivers in dangerous areas.  Constructed of lightweight
          recycled plastic.  One person installation.  Can be removed for seal coating, snow removal, or
          change of location.  Resists marring by oil, road salt, sunlight, and chemicals.  Resists rotting,
          termite damage, and corrosion.  No costly painting or maintenance.  Asphalt kit includes spikes
          and butyl tape.  The concrete hardware kit includes bolts, anchors, and washers. The glue down   series CS-33  FACILITY MAINTENANCE
          anchor plate kit includes anchor plates, T-nuts, bolts, and washers.  Requires 2-3 ounces of 2-part
          epoxy to the bottom of each anchor plate, which is not included.  Hardware kits sold separately.
          Units feature notched out bottom surface for laying hoses or cords underneath.  Models included
          in the CS-TB96 series are designed for use with trucks and other larger tired vehicles.  model
                                                                                    CS-S24-B
          Model CS-33-BL is made of black, recycled rubber.

               MODEL        OVERALL SIZE                    NUMBER OF   WEIGHT      model
              NUMBER         (W x L x H)      COLOR        MOUNTING HOLES  (POUND)  CS-S24-Y
           CS-33-G�         6" x 72" x 3¼"    GRAY             3          27
           CS-33-Y�         6" x 72" x 3¼"   YELLOW            3          27
           CS-33-B�         6" x 72" x 3¼"    BLUE             3          27
           CS-33-W�         6" x 72" x 3¼"    WHITE            3          27
           CS-33-BL�        5¾" x 71¾" x 4"  BLACK & YELLOW    4          37
           CS-S24-G�        6" x 24" x 3¼"    GRAY             2          10        model
           CS-S24-Y�        6" x 24" x 3¼"   YELLOW            2          10        CS-S48-Y
           CS-S24-B�        6" x 24" x 3¼"    BLUE             2          10
           CS-S24-W�        6" x 24" x 3¼"    WHITE            2          10
           CS-S48-G�        6" x 48" x 4"     GRAY             2          22
           CS-S48-Y�        6" x 48" x 4"    YELLOW            2          22        model
           CS-S48-B�        6" x 48" x 4"     BLUE             2          22        CS-S48-G
           CS-S48-W�        6" x 48" x 4"     WHITE            2          22
           CS-S72-G�        6" x 72" x 4"     GRAY             3          33
           CS-S72-Y�        6" x 72" x 4"    YELLOW            3          33
           CS-S72-B�        6" x 72" x 4"     BLUE             3          33
           CS-S72-W�        6" x 72" x 4"     WHITE            3          33
           CS-TB96-G�       10" x 96" x 7"    GRAY             4         134        model CS-33-BL
           CS-TB96-Y�       10" x 96" x 7"   YELLOW            4         134
           CS-TB96-B�       10" x 96" x 7"    BLUE             4         134
           CS-TB96-W�       10" x 96" x 7"    WHITE            4         134
          For optional reflectors use suffix -RE


           CAR STOP OPTIONS
               MODEL                                    USE WITH ABOVE NO.  WEIGHT
               NUMBER    DESCRIPTION                    OF MOUNTING HOLES  (POUND)  ASPHALT KIT     CONCRETE KIT
                                                                                    model CS-AK     model CS-33-KIT-3
           CS-AK-2�      ASPHALT HARDWARE KIT                 2           3
           CS-HD-AK-2�   HEAVY DUTY ASPHALT HARDWARE KIT      2           2
           CS-33-KIT-2�  CONCRETE HARDWARE KIT                2           2
           CS-GD-2�      GLUE DOWN ANCHOR PLATE               2           2
           CS-AK-3�      ASPHALT HARDWARE KIT                 3           4
           CS-HD-AK-3�   HEAVY DUTY ASPHALT HARDWARE KIT      3           3
           CS-33-KIT-3�  CONCRETE HARDWARE KIT                3           2
           CS-GD-3�      GLUE DOWN ANCHOR PLATE               3           3
           CS-AK-4�      ASPHALT HARDWARE KIT                 4           4
                                                                                           GLUE DOWN KIT
           CS-HD-AK-4�   HEAVY DUTY ASPHALT HARDWARE KIT      4           4                 model CS-GD-2
           CS-33-KIT-4�  CONCRETE HARDWARE KIT                4           2
                                                                                              CA Residents see
           CS-GD-4�      GLUE DOWN ANCHOR PLATE               4           3                  WARNING B, Pg. 459
          Heavy Duty Asphalt Anchors
          Heavy Duty Asphalt Anchors are ideal for attaching items to an asphalt surface. The unit is
          designed of a strong construction that is resilient and long lasting throughout the harshest of
          environments. Once the anchors are in place, they promote safety and well-being by holding
          material in a secure position.

                 MODEL        SHAFT     OVERALL    OVERALL              WEIGHT
                NUMBER       DIAMETER   DIAMETER    LENGTH    QUANTITY  (POUND)               model
           AS-HDA-12�           1"        1 /8"      12"        1         1                 AS-HDA-12-6PK
                                           5
           AS-HDA-12-4PK�       1"        1 /8"      12"        4         4
                                           5
                                           5
           AS-HDA-12-6PK�       1"        1 /8"      12"        6         6
   2   3   4   5   6   7   8   9   10   11   12
