202                      Adjustable Steel Gantry Cranes
       GANTRY AND JIB CRANES         easy mobility from one area to another with four (4) 8" swivel casters with four-position locks.  2K-4K


                                     Adjustable Steel Gantry Cranes are designed for positioning materials along the beam's length.  Facilitate
                                     models have glass filled nylon casters, 6K-8K models have phenolic casters, and 10K model has steel casters.
                                     Ratchet for easy one person height adjustment.  Height is adjustable in 6" increments.  Do not move units
                                     while loaded.  Painted blue finish.  Designed for semi-permanent or permanent applications.  Requires
                                     assistance from fork truck to set-up.  Hoist and trolley can be ordered separately, see pages 210-214.

                                                               OVERALL I-BEAM
                                                      UNIFORM
                                                                                      UNDER I-BEAM
                                          MODEL
                                                                             I-BEAM
                                                                                                   BASE
                                                                                                          WEIGHT
                                                                                                          (POUND)
                                                                                                  WIDTH
                                          NUMBER
                                                      CAPACITY
                                                               LENGTH / HEIGHT FLANGE WIDTH
                                                                                     USABLE HEIGHT
                                                                                       7'6" to 12'
                                                                                                    1
                                      AHS-2-10-12�
                                                                                                   88 /2"
                                                                                       8'6" to 14'
                                                      2,000 lb.
                                                                  10' / 6"
                                                                                                           898
                                                                              4"
                                                                                                    1
                                      AHS-2-10-14�
                   ADJUSTABLE HEIGHT
                                                      2,000 lb.
                                                                  10' / 6"
                                                                                                           930
                                                                                                   88 /2"
                                                                              4"
                                                                                                    1
                                      AHS-2-10-16�
                   GANTRY CRANES
                   series AHS
                                                                                        5' to 7'
                                                                              4"
                                                                                                   46 /8"
                                      AHS-2-15-7
                                                                  15' / 6"
                                                                                                    3
                                                                                                           716
                                                      2,000 lb.
                                                                                                   58 /8"
                                                                                                           774
                                                      2,000 lb.
                                                                                        6' to 9'
                                                                  15' / 6"
                                                                              4"
                                                                                                    3
                                      AHS-2-15-9�     2,000 lb.   10' / 6"    4"      10'6" to 16'  76 /8"  828
                                                                                                    1
                                      AHS-2-15-10�    2,000 lb.   15' / 6"    4"       6'6" to 10'  64 /4"  778
                           New        AHS-2-15-12�    2,000 lb.   15' / 6"    4"       7'6" to 12'  76 /8"  875
                                                                                                    1
                                                                                                    1
                                      AHS-2-15-14�    2,000 lb.   15' / 6"    4"       8'6" to 14'  88 /2"  954
                                                                                                    1
                                      AHS-2-15-16�    2,000 lb.   15' / 6"    4"      10'6" to 16'  88 /2"  1020
                                                                                                    1
                                                                      1
                                      AHS-2-20-12�    2,000 lb.  20' / 10 /8"  4"      7'6" to 12'  76 /8"  1074
                                                                                                    1
                                                                      1
                                      AHS-2-20-14�    2,000 lb.  20' / 10 /8"  4"      8'6" to 14'  88 /2"  1163
                                                                      1
                                                                                                    1
                                      AHS-2-20-16�    2,000 lb.  20' / 10 /8"  4"     10'6" to 16'  88 /2"  1194
                                                                                                    1
                                                                     1
                                      AHS-4-10-12�    4,000 lb.  10' / 8 /8"  4"       7'6" to 12'  76 /8"  860
                                                                     1
                                                                                                    1
                                      AHS-4-10-14�    4,000 lb.  10' / 8 /8"  4"       8'6" to 14'  88 /2"  925
                                                                     1
                                                                                                    1
                                      AHS-4-10-16�    4,000 lb.  10' / 8 /8"  4"      10'6" to 16'  88 /2"  962
                                                                     1
                                      AHS-4-15-7      4,000 lb.  15' / 8 /8"  4"        5' to 7'   46 /8"  739
                                                                                                    3
                                                                                                    3
                                                                     1
                                      AHS-4-15-9�     4,000 lb.  15' / 8 /8"  4"        6' to 9'   58 /8"  816
                                                                     1
            Steel Gantry   4-POSITION 8"   AHS-4-15-10�  4,000 lb.  15' / 8 /8"  4"    6'6" to 10'  64 /4"  846
                                                                                                    1
            Cranes are   SWIVEL CASTERS                              1                              1
            adjustable left/right   (standard)  AHS-4-15-12�  4,000 lb.  15' / 8 /8"  4"  7'6" to 12'  76 /8"  930
                                                                     1
            and up/down.              AHS-4-15-14�    4,000 lb.  15' / 8 /8"  4"       8'6" to 14'  88 /2"  1055
                                                                                                    1
                                                                                                    1
                                                                     1
                                      AHS-4-15-16�    4,000 lb.  15' / 8 /8"  4"      10'6" to 16'  88 /2"  1068
                                                                                                    1
                                                                     3
                                      AHS-4-20-12�    4,000 lb.  20' / 12 /16"  4"     7'6" to 12'  76 /8"  1076
                                                                                                    1
                                                                     3
                                      AHS-4-20-14�    4,000 lb.  20' / 12 /16"  4"     8'6" to 14'  88 /2"  1155
                                                                                                    1
                                                                     3
                                      AHS-4-20-16�    4,000 lb.  20' / 12 /16"  4"    10'6" to 16'  88 /2"  1204
                                                                     1
                                                                                                    3
                                      AHS-6-10-12�    6,000 lb.  10' / 8 /8"  4"      7'7" to 12'1"  77 /8"  927
                                                                     1
                                                                                                    3
                                      AHS-6-10-14�    6,000 lb.  10' / 8 /8"  4"      8'7" to 14'1"  89 /4"  1045
                                                                                                    3
                                                                     1
                                      AHS-6-10-16�    6,000 lb.  10' / 8 /8"  4"     10'7" to 16'1"  89 /4"  1022
                                      AHS-6-15-7      6,000 lb.  15' / 10 /8"  4"     5'1" to 7'1"  47 /8"  810
                                                                                                    5
                                                                      1
                                      AHS-6-15-9      6,000 lb.  15' / 10 /8"  4"     6'1" to 9'1"  59 /8"  894
                                                                      1
                                                                                                    5
                                                                      1
                                                                                                    1
           OPTIONAL                   AHS-6-15-10�    6,000 lb.  15' / 10 /8"  4"     6'7" to 10'1"  65 /2"  932
           TOTAL LOCKING CASTERS      AHS-6-15-12�    6,000 lb.  15' / 10 /8"  4"     7'7" to 12'1"  77 /8"  1017
                                                                                                    3
                                                                      1
           model AHS-2/4-TLC          AHS-6-15-14�    6,000 lb.  15' / 10 /8"  4"     8'7" to 14'1"  89 /4"  1108
                                                                      1
                                                                                                    3
           (FOR 2,000 AND 4,000 LB. CAPACITY
                                                                                                    3
                                                                      1
           CRANES ONLY)               AHS-6-15-16�    6,000 lb.  15' / 10 /8"  4"    10'7" to 16'1"  89 /4"  1168
           model AHS-6/8-TLC          AHS-6-20-12�    6,000 lb.  20' / 12 /16"  6½"   7'7" to 12'1"  77 /8"  1413
                                                                     5
                                                                                                    3
           (FOR 6,000 AND 8,000 LB. CAPACITY
                                                                     5
                                                                                                    3
           CRANES ONLY)               AHS-6-20-14�    6,000 lb.  20' / 12 /16"  6½"   8'7" to 14'1"  89 /4"  1513
                                                                     5
                                                                                                    3
                                      AHS-6-20-16�    6,000 lb.  20' / 12 /16"  6½"  10'7" to 16'1"  89 /4"  1532
                                                                                                    1
                                                                     1
                                      AHS-8-10-12�    8,000 lb.  10' / 8 /8"  4"      7'7" to 12'1"  76 /2"  933
                                                                                                    1
                                                                     1
                       OPTIONAL       AHS-8-10-14�    8,000 lb.  10' / 8 /8"  4"       8'6" to 14'  88 /4"  1050
                       V-GROOVE CASTERS  AHS-8-10-16�  8,000 lb.  10' / 8 /8"  4"     10'6" to 16'  88 /4"  1121
                                                                     1
                                                                                                    1
                       model AHS-2/4-V                                1                             3
                       (FOR 2,000 AND 4,000 LB.  AHS-8-15-7  8,000 lb.  15' / 10 /8"  4"  5' to 7'  45 /4"  804
                       CAPACITY CRANES ONLY)  AHS-8-15-9  8,000 lb.  15' / 10 /8"  4"   6' to 9'   57 /4"  905
                                                                      1
                                                                                                    3
                                                                                                    3
                                                                      1
                                      AHS-8-15-10�    8,000 lb.  15' / 10 /8"  4"      6'6" to 10'  63 /4"  960
                                                                                                    1
                                                                      1
                                      AHS-8-15-12�    8,000 lb.  15' / 10 /8"  4"     7'7" to 12'1"  76 /2"  1044
                                                                      1
                                                                                                    1
                                      AHS-8-15-14�    8,000 lb.  15' / 10 /8"  4"      8'6" to 14'  88 /4"  1132
                                                                                                    1
                                                                      1
                       OPTIONAL       AHS-8-15-16�    8,000 lb.  15' / 10 /8"  4"     10'6" to 16'  88 /4"  1194
                       V-GROOVE CASTERS               8,000 lb.  20' / 12 /16"  6½"   7'7" to 12'1"  76 /2"  1406
                                                                                                    1
                                                                     5
                       model AHS-6/8-V  AHS-8-20-12�
                                                                                                    5
                                                                     5
                       (FOR 6,000 AND 8,000 LB.  AHS-8-20-14�  8,000 lb.  20' / 12 /16"  6½"  8'6" to 14'  88 /16"  1514
                       CAPACITY CRANES ONLY)                         5                              1
                                      AHS-8-20-16�    8,000 lb.  20' / 12 /16"  6½"   10'6" to 16'  88 /4"  1582
                                      AHS-10-15-10   10,000 lb.  15' / 12 /8"  4"      6'6" to 10'  64 /2"  1352
                                                                      1
                                                                                                    1
                                      ADJUSTABLE STEEL GANTRY CRANE OPTIONS (WHEN PURCHASED WITH GANTRY CRANE)
                                      AHS-2/4-TLC    TOTAL LOCKING CASTERS (2,000 & 4,000 LB. CAPACITY CRANES ONLY) (SET OF 4)
                                      AHS-6/8-TLC    TOTAL LOCKING CASTERS (6,000 & 8,000 LB. CAPACITY CRANES ONLY) (SET OF 4)
              Note: All products should be   AHS-2/4-V
             inspected frequently to insure   AHS-6/8-V  8" x 2" V-GROOVE CASTERS FOR 2,000 & 4,000 LB. UNITS (SET OF 4)
                                                     8" x 3" V-GROOVE CASTERS FOR 6,000 & 8,000 LB. UNITS (SET OF 4)
              safe operation. Final testing   AHS-KIT
             and inspection is left to end user   AHS-STLO  (2) COME-A-LONG (2) CABLES FOR HEIGHT ADJUSTMENT (NOT FOR LIFTING)
              after final assembly has been          STATIONARY LEG OPTION, set of (4) four (factory installed)
             completed. For further details   AHS-STLO-RF  STATIONARY LEG OPTION, set of (4) four (field installed)
                 see ASME B30.17.    USABLE DISTANCE BETWEEN UPRIGHTS IS OVERALL BEAM LENGTH MINUS 12"
                                     USABLE TROLLEY TRAVEL LENGTH IS OVERALL BEAM LENGTH MINUS 30"
