204                        Fixed Steel Gantry Cranes
       GANTRY AND JIB CRANES           construction will provide years of service.  Facilitate easy mobility from one area to another with four (4)


                                       Industrial Steel Gantry Cranes are designed for positioning materials along the beam's length.  Solid steel
                                       8" swivel casters with four-position locks. 2K-4K models have glass filled nylon casters, 6K-8K models
                                       have phenolic casters, and 10K model has steel casters.  More economical and flexible than permanent
                                       cranes.  Features quick setup design.  Designed for semi-permanent or permanent applications. Requires
                                       assistance from fork truck to set-up.  Do not move units while loaded. Painted blue finish. Caster options
                                       are located on the bottom of page 202.  Hoist and trolley can be ordered separately, see pages 210-214.
                                           MODEL
                                                                                                    BASE
                                                      UNIFORM
                                                                                                           WEIGHT
                                                               OVERALL I-BEAM
                                                                              I-BEAM
                                                                                       UNDER I-BEAM
                                           NUMBER
                                                                                        TO GROUND
                                                                                                   WIDTH
                                                                             FLANGE WIDTH
                                                      CAPACITY
                                                               LENGTH / HEIGHT
                                                                                                          (POUND)
                                                                  8' / 6"
                                                       500 lb.
                                                                                           10'
                                                                  10' / 6"
                                                                                4"
                                                                                                   64½"
                                                                                                            739
                                        FHS-2-10�
                                                                  15' / 6"
                                                                                           10'
                                                                                                   64½"
                                                      2,000 lb.
                                                                                                            801
                                                                                4"
                                        FHS-2-15�
                                                                                           10'
                                                      2,000 lb.
                                                                      1
                                                                                                            994
                                                                                4"
                                                                                                   64½"
                                        FHS-2-20�
            FIXED HEIGHT STEEL   New    FHS-50        2,000 lb.  20' / 10 /8"   4"        5'9"     46½"     512
                                                                     1
            GANTRY CRANES               FHS-4-10�     4,000 lb.  10' / 8 /8"    4"         10'     64½"     771
            series FHS                  FHS-4-15�     4,000 lb.  15' / 8 /8     4"         10'     64½"     846
                                                                      1
                                                                      3
                                        FHS-4-20�     4,000 lb.  20' / 12 /16"  4"         10'     64½"    1006
                                                                     1
                                        FHS-6-10      6,000 lb.  10' / 8 /8"    4"        10'1"    65½"     775
              Note: All products should be   FHS-6-15  6,000 lb.  15' / 10 /8"  4"        10'1"    65½"     963
                                                                      1
             inspected frequently to insure   FHS-6-20  6,000 lb.  20' / 12 /16"  6½"     10'1"    65½"    1355
                                                                      5
              safe operation. Final testing   FHS-8-10  8,000 lb.  10' / 8 /8"  4"        10'1"    64¼"     855
                                                                     1
             and inspection is left to end user   FHS-8-15  8,000 lb.  15' / 10 /8"  4"   10'1"    64¼"     956
                                                                      1
              after final assembly has been   FHS-8-20  8,000 lb.  20' / 12 /16"  6½"     10'1"    64¼"    1385
                                                                      5
             completed. For further details   FHS-10-10  10,000 lb.  10' / 10 /8"  4"      10'     64½"    1093
                                                                      1
                 see ASME B30.17.       FHS-10-15    10,000 lb.  15' / 12 /16"  4"         10'     64½"    1428
                                                                      3
                                        FIXED STEEL GANTRY CRANE OPTIONS (WHEN PURCHASED WITH GANTRY CRANE)
                                        FHS-STLO     STATIONARY LEG OPTION, set of (4) four (factory installed)
                                        FHS-STLO-RF  STATIONARY LEG OPTION, set of (4) four (field installed)
                                       Fixed Height Steel Gantry Cranes - Knockdown
                                       Fixed Height Knockdown Industrial Steel Gantry Cranes are uniquely designed to be disassembled
                                       when not in use for compact storage and easier transportation / shipping from one job site to another.
                                       Facilitate easy mobility from one area to another with four (4) 8" swivel casters with four-position locks.
                                       2K-4K models have glass filled nylon casters, 6K-8K models have phenolic casters, and 10K model has
                                       steel casters.  Features quick setup design. Do not move units while loaded. Painted blue finish. Designed
                                       for semi-permanent or permanent applications. Requires assistance from fork truck to set-up. Hoist and
                                       trolley can be ordered separately, see pages 210-214.
                                           MODEL     UNIFORM   OVERALL I-BEAM   I-BEAM  UNDER I-BEAM  BASE  WEIGHT
                                          NUMBER     CAPACITY  LENGTH / HEIGHT  FLANGE WIDTH  TO GROUND  WIDTH  (POUND)
            FIXED HEIGHT STEEL GANTRY CRANES -   FHSN-50  500 lb.  8' / 6"     4"         5'9"     46½"    612
            KNOCKDOWN
            series FHSN                 FHSN-2-10   2,000 lb.    10' / 6"      4"         10'      64½"    797
                                        FHSN-2-15   2,000 lb.    15' / 6"      4"         10'      64½"    856
                            New         FHSN-2-20   2,000 lb.    20' / 10"     4"         10'      64½"    1045
                                        FHSN-4-10   4,000 lb.    10' / 8"      4"         10'      64½"    829
                                        FHSN-4-15   4,000 lb.    15' / 8"      4"         10'      64½"    905
                                        FHSN-4-20   4,000 lb.    20' / 12"     4"         10'      64½"    1058
                                        FHSN-6-10   6,000 lb.    10' / 8"      4"         10'      64½"    897
                                        FHSN-6-15   6,000 lb.    15' / 10"     4"         10'      64½"    980
                                        FHSN-6-20   6,000 lb.    20' / 12"     6½"        10'      64½"    1367
                                        FHSN-8-10   8,000 lb.    10' / 8"       4"        10'      64½"    897
                                        FHSN-8-15   8,000 lb.    15' / 10"      4"        10'      64½"    979
                                        FHSN-8-20   8,000 lb.    20' / 12"     6½"        10'      64½"    1366
                                        FHSN-10-10  10,000 lb.   10' / 10"      4"        10'      64½"    1107
            KNOCKDOWN DESIGN            FHSN-10-15  10,000 lb.   15' / 12"      4"        10'      64½"    1275
            ALLOWS FOR COMPLETE
            CRANE DISASSEMBLY           FIXED STEEL GANTRY CRANE - KNOCKDOWN OPTIONS
            FOR LOWER FREIGHT AND       FHS-STLO    STATIONARY LEG OPTION, set of (4) four (factory installed)
            TRANSPORTATION COSTS
                                        FHS-STLO-RF  STATIONARY LEG OPTION, set of (4) four (field installed)
                                       Steel Gantry Crane Power Traction Drive Options
                                       Power Traction Drive Options for a gantry cranes are ideal for industrial manufacturing environments.
                                       The power traction drive allows the gantry crane to be moved to a desired position without need of extra
                                       personnel.  The unit is maneuvered by a three (3) button push button control for precise movements,
                                       while being driven by 460V, 3 phase power.  Do not move units while loaded.
                                          MODEL
                                         NUMBER                              DESCRIPTION
                                        GPTD-2    2,000 TO 4,000 LB. UNIFORM CAPACITY/STD. WITH 3 BUTTON HAND CONTROL
                                        GPTD-4    6,000 TO 8,000 LB. UNIFORM CAPACITY/STD. WITH 3 BUTTON HAND CONTROL
            FACTORY INSTALLED           V-TRACK   10 FOOT SECTION OF V-GROOVE TRACK (ONE SIDE ONLY)
            OPTION ONLY                ADDITIONAL BUTTONS ON HAND CONTROL FOR HOIST & TROLLEY AVAILABLE, CONTACT FACTORY
