30                      New       Load and unload equipment from trucks using these Heavy-Duty Fiberglass
       LOADING DOCK EQUIPMENT                 Walk Ramps. Reinforced fiberglass construction provides up to 3,000 pounds   ROUGH TEXTURE
                                              Heavy-Duty Fiberglass Walk Ramps



                                              capacity. Abrasive surface provides good traction in wet or dry conditions. 1"
                                              high curb on each side of ramp. Not for use with fork trucks or pallet trucks.
                                                                         OVERALL
                                                                                               MAXIMUM
                                                                                                          WEIGHT
                                                   MODEL
                                                              OVERALL
                                                                                    UNIFORM
                                                                                                          (POUND)
                                                                                   CAPACITY
                                                                                             WORKING HEIGHT
                                                               WIDTH
                                                  NUMBER
                                                                         LENGTH
                                               FWR-3010-50
                                                                30"
                                                                                                           225
                                                                                   3,000 lb.
                                                                          10'
                                                                                                 30"
                                               FWR-3012-50
                                                                                   3,000 lb.
                                                                          12'
                                                                30"
                                                                                                 35"
                                                                                                           260
                                               FWR-3014-50
                                                                                   3,000 lb.
                                                                30"
                                                                          14'
                                                                                                 45"
                                                                                                           260
                                               FWR-3610-50
                                                                                                 30"
                                                                                                           260
                                                                36"
                                                                                   3,000 lb.
                                                                          10'
                                               FWR-3612-50
                                                                36"
                                                                          12'
                                               FWR-3614-50
                                                                                                           300
                                                                                   3,000 lb.
                                                                36"
                                                                                                 45"
                                                                          14'
                                              Fiberglass Autoloader Ramps          3,000 lb.     35"       314
                                              Autoloader Ramps can be separated in half to provide two ramps that may be used to load
                                              automobiles and other vehicles. Each half is 18" wide and handles 2,500 pounds. To separate
                                              simply remove center hinge pins.
                                                  MODEL       OVERALL    OVERALL   UNIFORM     MAXIMUM    WEIGHT
                                                  NUMBER      WIDTH      LENGTH    CAPACITY  WORKING HEIGHT  (POUND)
                                               FAL-3610-50     36"        10'      5,000 lb.     30"       255
                                               FAL-3612-50     36"        12'      5,000 lb.     35"       290
                                               FAL-3614-50     36"        14'      5,000 lb.     45"       330
                                               FAL-3616-50     36"        16'      5,000 lb.     50"       385
                                              Aluminum Vehicle Twin Ramps
                                              Provide a safe means for driving vans, pick-up trucks, and some passenger vehicles from ground
                                              level into and out of high building entrances.  Ramps can be securely fastened to dock with two
                                              (2) 34" chains each  with hook on the end.  To avoid hang-ups, measure under clearance and
                                              wheelbase of vehicle.  The usable width is 14".  Side curbs are 1¼" high.  Welded aluminum
                                              construction.  Sold in pairs.
                                                   MODEL       OVERALL   OVERALL  UNIFORM     MAX to MIN  WEIGHT
                                   model           NUMBER      WIDTH     LENGTH   CAPACITY  WORKING HEIGHT  (POUND)
                                   VTR-5.5-14-10
                                               VTR-7-14-8      17 /16"    96½"    7,000 lb.  17½" to 12½"  226
                                                                 5
                                               VTR-5.5-14-10   17 /16"   120½"    5,500 lb.  22½" to 16"   382
                                                                 5
                                               VTR-7-14-12     17 /16"   144½"    7,000 lb.   27" to 19"   417
                                                                 5
                                               VTR-6-14-14     17 /16"   168½"    6,000 lb.  32" to 22½"   487
                                                                 5
                                               VTR-5.5-14-16   17 /16"   192½"    5,500 lb.  36½" to 25½"  586
                                                                 5
                                               VTR-6-14-18     18 /16"   216½"    6,000 lb.   41" to 29"   801
                                                                 9
                                               VTR-5.5-14-20   18 /16"   240½"    5,500 lb.  46" to 32½"   889
                                                                 9
                                               VTR-5.5-14-24   18 /16"   288½"    5,500 lb.  55½" to 39"   1083
                                                                 9
                                   model
                                   RAMP-5077
                                              Aluminum Pick-Up/Van Ramp
                                              Lightweight aluminum ramp works great for large and small wheeled equipment. When using
                                              small wheeled equipment add ¼" plywood (not included) to ramp surface. Folds up to 16½" wide
                                              for storing between ATV wheels in truck. Includes adjustable safety straps to hook ramp safely to
                                              trailer. Height unfolded is 1½". Folded height is 5½".
                                                  MODEL             UNFOLDED  GROSS UNIFORM  SINGLE WHEEL   WEIGHT
                                                  NUMBER    LENGTH   WIDTH      CAPACITY  UNIFORM CAPACITY  (POUND)
                                               RAMP-5077    78"      50"      1,500 lb.      250 lb.      37
                                              Folding Ramp
                                              Meet ADA requirements with these handy lightweight compact ramps.  Assembly required.
                                              Single fold ramp measures 14 /16"W x 72"L x 3½"H when folded.  It has a 1¼" curb and 2½"
                                                                  3
                                              lip.  The ramp is serrated and has debris slots.
                                                  MODEL       UNFOLDED         FOLDED         UNIFORM     WEIGHT
                                                 NUMBER       (W x L x H)      (W x L x H)    CAPACITY    (POUND)
                                    model
                                                             5
                                                                      9
                                                                             3
                                    RAMP-SF    RAMP-SF    28 /8" x 72" x 2 /16"  14 /16" x 72" x 3½"  500 lb.  37
