          Steel Pallets with Hot-Dipped Galvanized Finish

          Heavy-duty non-reversible welded steel pallets.  Usable fork openings are 3⅞" high.  Model
          SPL-3636 has 4-way entry allowing access for both fork and pallet trucks. Models SPL-4048,
          SPL-4248 and SPL-4848 have 2-way entry and allow access for fork trucks only.  Hot-dipped
          galvanized finish offers rust resistance.                                                                PACKAGING EQUIPMENT

                                          UNIFORM SUPPORTED WEIGHT CAPACITY
              MODEL      OVERALL SIZE   FLOOR      FORK     UNSUPPORTED  WEIGHT
             NUMBER       (W x D x H)  (STATIC)  (DYNAMIC)  PALLET RACK  (POUND)
           SPL-3636�   36" x 36" x 4¾"  8,000 lb.  4,000 lb.  2,200 lb.  80                        model SPL-3636
           SPL-4048�   40" x 48" x 4¾"  8,000 lb.  4,000 lb.  2,200 lb.  100
           SPL-4248�   42" x 48" x 4¾"  8,000 lb.  4,000 lb.  2,200 lb.  103
           SPL-4848�   48" x 48" x 4¾"  8,000 lb.  4,000 lb.  2,200 lb.  114




          Heavy Duty Solid Deck Steel Pallet
          The heavy-duty non-reversible welded steel Solid Deck Pallet are ideal to transport and store
          products within your facility and/or to transport them between facilities. Galvanized finish for
          rust resistance. Usable fork pockets are 8½"W x 2½"H.  Open end usable size is 35"W x 3¾"H.

                                         UNIFORM SUPPORTED WEIGHT CAPACITY
              MODEL      OVERALL SIZE   FLOOR      FORK    UNSUPPORTED  WEIGHT        model
              NUMBER      (W x D x H)  (STATIC)  (DYNAMIC)  PALLET RACK  (POUND)  SDSP-4048
           SDSP-4048�  47" x 39½" x 6½"  4,000 lb.  3,500 lb.  2,500 lb.  118
                                                                                               CA Residents see
                                                                                              WARNING A, Pg. 459

          Galvanized Welded Wire Pallets
          Galvanized Welded Wire Pallets will stand up to heavy-duty use.  Design allows for stacking.
          Four-way access with pallet truck, and fork trucks.  Open decking features 2" x 4" grid pattern.
          Usable height on open end is 3".  Usable height on stringer end is 2¾".  Understructure
          supports are made from 12 gauge steel.  Decking is made from welded steel wire.  Welded steel
          construction with galvanized finish.
                                                                                model
                                        UNIFORM SUPPORTED WEIGHT CAPACITY       WMP-4048
              MODEL     OVERALL SIZE   FLOOR       FORK     UNSUPPORTED  WEIGHT
             NUMBER      (W x D x H)  (STATIC)   (DYNAMIC)  PALLET RACK  (POUND)
           WMP-4048�   40" x 48" x 4"  4,000 lb.  2,500 lb.  NOT RATED   84
                                                                                               CA Residents see
           WMP-4848�   48" x 48" x 4"  4,000 lb.  2,500 lb.  NOT RATED   98                   WARNING A, Pg. 459

          Aluminum Pallets

          This is the pallet the food and chemical industries have always wanted.  Easy to clean with a
          power washer.  Stands up to high-power steam, brushes, or pads.  Features a non-skid surface
          for easy transportation of all products.  Top boards are 4¾" wide.  Available in two-way and
          four-way entry for pallet and fork truck use.  Durable and re-usable.  Heavy-duty welded
          aluminum construction.

                                           UNIFORM SUPPORTED WEIGHT CAPACITY    model
                                                                                AP-4248
              MODEL       OVERALL SIZE   FLOOR       FORK    UNSUPPORTED  WEIGHT
              NUMBER       (W x D x H)   (STATIC)  (DYNAMIC)  PALLET RACK  (POUND)
           2-WAY ENTRY
           AP-4048       40⅛" x 48" x 6"  6,000 lb.  4,000 lb.  6,000 lb.  84
           AP-4248       42⅛" x 48" x 6"  6,000 lb.  4,000 lb.  6,000 lb.  86
           AP-4848       48⅛" x 48" x 6"  6,000 lb.  4,000 lb.  6,000 lb.  89
           4-WAY ENTRY
           AP-4048-4W   40" x 47⅞" x 5 /16"  6,000 lb.  4,000 lb.  4,000 lb.  85
                                  1
                                  1
           AP-4248-4W   42" x 47⅞" x 5 /16"  6,000 lb.  4,000 lb.  4,000 lb.  87
                                   1
           AP-4848-4W  47⅞" x 47⅞" x 5 /16"  6,000 lb.  4,000 lb.  4,000 lb.  90
           SKID BOTTOM
                                  1
           AP-4048-SB   40" x 47⅞" x 5 /16"  6,000 lb.  4,000 lb.  4,000 lb.  85
                                  1
           AP-4248-SB   42" x 47⅞" x 5 /16"  6,000 lb.  4,000 lb.  4,000 lb.  87
                                   1
           AP-4848-SB  47⅞" x 47⅞" x 5 /16"  6,000 lb.  4,000 lb.  4,000 lb.  90
