406                         Hydraulic Foot Pump Roll Handler
       STAINLESS STEEL & BRONZE  model ULM-HRH-850  the food handling service industries.  The design is sleek, smooth, and easily washable for before and

                                        A 304L Stainless Steel Hydraulic Foot Pump Roll Handler is great for an assortment of areas including
                                        after use in hygienic areas.  The raising and lowering of the platform to the precise position is made
                                        easy by the hydraulic foot pump design, which diminishes needless bending when loading/unloading
                                        material. The 304L stainless steel construction, including hydraulic cylinders as well as the piston,
                                        provides a strong structure for transferring heavy loads between work areas. A rounded handle style
                                        allows for a proper two handed grip when maneuvering around work areas.  The open cradle platform
                                        lets the user load material from three sides. Cradle adjusts in 1" increments up to 16" wide.  The
                                        handler rolls smoothly on four (4) swivel casters with two (2) attached rear brakes for safe functionality
                                        when in a resting position.

                                                             (W x L)
                                                                                                 850 lb.
                                                            16" x 16"
                                        Pallet Trucks      CRADLE SIZE  ROLL DIAMETER  5 /8" to 23"  CAPACITY  (POUND)
                                        304L Stainless Steel Hydraulic Hand Pump Pallet Trucks are a superb addition to the food handling
                                        and other hygienic environments.  The 304L stainless steel construction, including hydraulic
                    model               cylinders as well as the piston, is not only strong, but also simple to clean with its open fork design
                 ULM-PM-2745-30         for thoroughly detailing the unit before/after transferring products.  The height of the ergonomically
                                        friendly handle diminishes slouching and can be rotated for simple maneuvering of products down
                                        narrow corridors and pathways.  All bearings are sealed for waterproof protection during both use
                                        and cleaning.
                                               MODEL          UNIFORM      OVERALL FORK     SERVICE      WEIGHT
                                              NUMBER          CAPACITY      SIZE (W  x L)    RANGE       (POUND)
                                         ULM-PM-2745-30       3,300 lb.    26¾" x 45¼"     3 /8" to 8"    170
                                         ULM-PM-2745-40       4,500 lb.    26¾" x 45¼"     3 /8" to 8"    170
                                        Specialized Pallet Trucks (with nylon wheels)  Ships with the Handle Detached Standard
                                        Stainless Steel and Stainless Steel Frame & Forks:  Ideal for sanitary, pharmaceutical, medical, food,
                                        corrosive, and wet environments. Choose type 304 stainless steel frame and forks only or 100% type
                                        304 stainless steel pallet truck for long life in the most harsh environments. 5,500 lbs. uniform capacity.
                                        Galvanized and Zinc Coated:  Ideal for corrosive environments.  Full-featured pallet trucks were
                          model         designed for chemical, pharmaceutical, and wash-down applications.  5,500 pounds uniform capacity.
                                              MODEL                            OVERALL FORK    FORK       WEIGHT
                                             NUMBER           DESCRIPTION      DIMENSIONS   SERVICE RANGE  (POUND)
                                         PM5-2048-SS      STAINLESS STEEL    21½"W x 45"L   2 /8" to 7¾"  232
                                         PM5-2748-SS      STAINLESS STEEL     27"W x 48"L   2 /8" to 7¾"  225
                                         PM5-2748-SFF    SS FRAME & FORKS     27"W x 48"L   2 /8" to 7¾"  194
                                         PM5-2048-S-G       GALVANIZED         20" x 48"    2 /8" to 7¾"  182
                            CA Residents see  PM5-2748-S-G   GALVANIZED         27" x 48"    2 /8" to 7¾"  197
                           WARNING A, Pg. 459
                                         PM5-2748-S-Z        ZINC COATED        27" x 48"    2 /8" to 7¾"  211
                                        Pallet Trucks with Digital Scale
                                        304 Stainless Steel Pallet Trucks with Digital Scale allows you to weigh your load on the spot for
                                        maximum efficiency.  This model is very user friendly and is suitable for low height lifting. The
                                        built-in scale allows you to weigh your load as you are handling it. The scale is selectable in a variety
                                        of increments to adjust to the size of your load. It has keyboard calibration and functional setup
                                        with automatic zero capabilities. Digital filtering is used to help compensate for vibration and
                          PM-2045-SCL-LP-SS  motion to make the Stainless Steel Pallet Truck with Digital Scales smooth and accurate. Forks are
                                        7" wide each. Factory calibrated for shipping destination. Scale is powered with four (4) C batteries.
                                        AC adaptor included. NTEP approval  also available. Units may not be suitable for wash down
                                        applications. Please contact factory.

                                                MODEL            UNIFORM     OVERALL FORK      FORK       WEIGHT
                                                NUMBER           CAPACITY     DIMENSIONS    SERVICE RANGE  (POUND)
                                         PM-2045-SCL-LP-SS     5,000 lb.  21 /8"W x 45 /16"L  3 /8" to 8"  309
                                         PM-2745-SCL-LP-SS     5,000 lb.  27½"W x 45 /16"L   3 /8" to 8"  375
