Page 7 - Stainless Steel & Bronze Products
P. 7


          Linear Actuated Elevating Cart (partially stainless steel)  12V DC STANDARD
          Transport materials from workstation to workstation with ease.  Platform is raised and lowered with an
          electric linear actuator for precise positioning.  Linear actuator will not allow platform to drift down - a
          common problem with hydraulic carts.  This linear actuated cart is powered with a 12V DC battery and
          features an on-board charger.  Emergency stop button standard on hand control. Includes two (2) rigid
          and two (2) swivel casters.  Platform, handle, base frame, caster brackets and hardware are all stainless
          steel.  Air pump, hydraulic cylinder, scissor legs and foot pedal are zinc plated.  Battery pack, charger, and   STAINLESS STEEL & BRONZE
          hand control are plastic.  Linear actuator is plastic with a chrome-plated piston. Wheels are poly-on-poly.
                  MODEL         PLATFORM   UNIFORM    LOWERED    RAISED    WEIGHT                          model
                 NUMBER         SIZE (W x L)  CAPACITY  HEIGHT   HEIGHT    (POUND)                  CART-500-LA-PSS
           CART-500-LA-PSS    19½" x 32"   500 lb.     15"        33"      248
          Lift & Tilt Cart with Sequence Select (partially stainless steel)
          Lift & Tilt Cart with Sequence Select has a unique design which allows the user to RAISE and TILT
          materials to an ergonomic position for better posture and operator comfort. The manual hydraulic foot
          pump controls the platform lift, lower, and tilt. A manual selector valve is used to control the lift/lower
          sequence independently from the tilt sequence. The platform includes a 7" high retaining lip. Rolls on
          two (2) rigid and two (2) swivel 5" poly casters.
                 MODEL          PLATFORM     UNIFORM   MAX.     SERVICE     WEIGHT
                 NUMBER         SIZE (W x L)  CAPACITY  TILT    RANGE**    (POUND)
           CART-1000-LT-PSS*  22" x 33 /8"  1,000 lb.  40°    17½" to 35"   323                           model
          **SERVICE RANGE FIGURED WITH PLATFORM LEVEL                                               CART-1000-LT-PSS
          Low Profile Electric Lift Table       115 V 1-PHASE STANDARD
          The open center on the "U" Type Electric Lift Tables, enable a pallet truck to place a load on the
          platform.  Units feature an external power pack equipped with a pressure relief valve that
          prevents overloading and a flow control valve that controls the lowering speed.  Remote
          power pack comes complete with a cover to protect the motor from dust and debris.  Raise
          and lower the unit using the UP and DOWN push buttons on the 24V control box.  Safety
          features include electric toe guards, safety velocity fuse in cylinders, safety maintenance
          props, and an emergency stop button on the control box.  Inside width is 29¾" by 44¼"
          long.  Power supply is 115V single phase with pedestal mounted push buttons.  Unit is 304 stainless
          steel.  All the components are stainless steel except electrical connections, control box and power unit.  model EHU-12-SS
              MODEL       PLATFORM     UNIFORM     LOWERED      RAISED     WEIGHT
              NUMBER     SIZE (W x L)  CAPACITY     HEIGHT      HEIGHT     (POUND)
           EHU-12-SS      50" x 59"   1,200 lb.      3 /8"       33½"       592
          Spring Scissor Tables (partially stainless steel)
          Spring Scissor Tables are ideal for distributing and shipping facilities. These units allow the user to   SST-45-PSS-ST
          transfer products from work space to work space, while holding an ergonomically friendly position.
          The frame is designed of steel construction, which allows for strength and durability.  The scissor
          mechanism raises the unit to the desired height, while the internal spring provides support when unit
          is being loaded and unloaded. The round top can be manually rotated 360° for improved packaging
          and handling capabilities. Fork pockets measure 6¾"W x 1½"H. Constructed of partially stainless steel
          base, frame, springs, and legs.  Model SST-45-PSS-ST has a solid top.
               MODEL      PLATFORM     UNIFORM       SERVICE     BASE SIZE  WEIGHT  SST-45-PSS
               NUMBER     DIAMETER     CAPACITY       RANGE       (W x L)   (POUND)
           SST-45-PSS       43 /8"   400 to 4,500 lb.  9" to 27¾"  36" x 36¾"  432
           SST-45-PSS-ST    43 /8"   400 to 4,500 lb.  9" to 27¾"  36" x 36¾"  452
          Air Corner Tilter    FACTORY AIR POWERED
          A Stainless Steel Air Corner Tilter provides ergonomic loading and unloading of bulk containers,
          gaylords, or crates. Pallet truck and fork truck accessible. Tilts up to 45°. Activated by a hand operated
          control lever.  The air bag inflates tilting the container automatically as it is unloaded. As the container
          becomes lighter, it automatically tilts and the material shifts to the corner of the container where it can
          be easily removed by manual or mechanical means. The regulator is factory preset to begin rotating the
          container when the weight reaches approximately 900 pounds.

              MODEL                                PLATFORM     UNIFORM    WEIGHT
              NUMBER            DESCRIPTION        SIZE (W x L)  CAPACITY  (POUND)  model AIR-THL-SS
           AIR-THL-SS     HAND LEVER OPERATION     44" x 44"   1,500 lb.    550
