INDUSTRIAL STORAGE SOLUTIONS
Internestable Stackable Racks

Space saving storage is what this rack is all about. The 3¼" underclearance allows for easy fork
truck accessibility. Units can stack up to 20 feet high. Sturdy, welded construction gives these
(A)
units an abundance of strength and stability. (A) Special redundant stacking systems allow units
to be internested for space saving storage when not in use. (B) Flared posts, pintle, and target,
make it easy to line up units for stacking. (C) Optional fold down post available upon request.

(B) MODEL USABLE OVERALL UNIFORM WEIGHT
NUMBER (W x D x H) (W x D x H) CAPACITY (POUND)
NEST-106 49" x 42" x 48" 56½" x 47" x 58" 4,000 lb. 336
NEST-210 49" x 48⅜" x 48" 56½" x 53" x 58" 4,000 lb. 306
NEST-215 61" x 42" x 48" 68½" x 47" x 58" 4,000 lb. 355
(C) NEST-230 61" x 48⅜" x 48" 68½" x 53" x 58" 4,000 lb. 375

Long Bar Pigeon Hole Rack

Ideal for mixed storage of long items. Five-hole high and three-hole wide frame allows
for easy identification and retrieval of materials. Frames are held in place by separator
and bracing bars. 7,700 pound uniform capacity per frame. Extension bay kit, model
LBPH-EXT, consists of one frame and one set of cross braces for joining to the starter set.
Uniform capacity is 2,000 pounds per level or 7,700 pounds per frame. Steel construction.
Baked-in powder-coated toughness.

MODEL OVERALL SIZE NUMBER WEIGHT
model LBPH-77 NUMBER DESCRIPTION (W x D x H) OF BAYS (POUND)
LBPH-77� STARTER UNIT 48½" x 48" x 60" 15 232
LBPH-EXT� EXTENSION BAY KIT 48½" x 48" x 60" 15 176

Economical Material Racks
Model SR-WM is a wall mounted unit with dual 60" high supports. They come with three (3)
18" arms and four (4) 15" arms. The 18" arms have 9" height clearance and the 15" arms have
model SR-WM 7¼" clearance. Uniform load capacity is 1,000 pounds. The bright zinc plating provides a long
term, attractive appearance. Shipped knocked down with convenient and quick assembly.
Model SR-SS is a self-supporting 66" high A-frame with 7 storage levels. Arms extend up
to 12" beyond A-frame. Base dimensions are 60" by 36". Shipped knocked down with
convenient and quick assembly. Bright zinc plated finish.
Model SR-V is a floor-mounted vertical material rack. Features three storage bays.
Shipped knocked down with convenient and quick assembly. Bright zinc plated finish.

MODEL UNIFORM WEIGHT
NUMBER DESCRIPTION HEIGHT CAPACITY (POUND)
model SR-SS
SR-WM� WALL MOUNT 60" 1,000 lb. 24
SR-SS� SELF SUPPORTING 66" 2,000 lb. 61
model SR-V SR-V� FLOOR MOUNTED 72" 2,000 lb. 77

Stackable Bar Cradles
These sturdy, welded steel racks are strong enough to handle heavy loads, yet light enough
to be set up by one person. Stackable up to five (5) units high. Allows for custom design by
choosing length, depth, and height of individual storage systems. Welded steel construction
with blue painted surface. Units are sold each.

MODEL OVERALL SIZE INSIDE SIZE UNIFORM UNIFORM WEIGHT
NUMBER (W x D x H) (W x D x H) CAPACITY/EACH CAPACITY/PAIR (POUND)
model CRAD-25-44
5
shown two possible CRAD-25� 12" x 16" x 14" 8" x 12" x 10 /8" 1,250 lb. 2,500 lb. 31
configurations. CRAD-25-30� 12" x 30" x 14" 8" x 12" x 10 /8" 1,250 lb. 2,500 lb. 78
5
5
CRAD-25-44� 12" x 44" x 14" 8" x 12" x 10 /8" 1,250 lb. 2,500 lb. 107
5
CRAD-25-58� 12" x 58" x 14" 8" x 12" x 10 /8" 1,250 lb. 2,500 lb. 127
5
CRAD-25-72� 12" x 72" x 14" 8" x 12" x 10 /8" 1,250 lb. 2,500 lb. 146
5
CRAD-37� 14" x 19" x 18" 10" x 15" x 14 /8" 1,850 lb. 3,700 lb. 37
5
CRAD-56� 15" x 22" x 21" 11" x 18" x 17 /8" 2,800 lb. 5,600 lb. 43
CRAD-75� 16" x 26" x 24" 12" x 22" x 20½" 3,750 lb. 7,500 lb. 46
