S-CB-NM-60

Printer Friendly
Out of Stock - Please Contact Sales
S-CB-NM-60
S-CB-NM-60 S-CB-NM-60 S-CB-NM-60 S-CB-NM-60 S-CB-NM-60 S-CB-NM-60 S-CB-NM-60

Steel Counter Balanced Powered Drive Narrow Mast Stacker 60" Lift 51-9/16"L x 25-9/16"W x 61-13/16"H 600 Lb. Capacity Black / Yellow

Counter balance stacker with a narrow mast design is ideal for die loading, machine feeding, and for loading and unloading trucks in confined areas. An ergonomic handle features easy-to-operate throttle with infinite adjustment of forward and reverse speeds, lift/lower controls, and emergency reverse function. Includes an automatic dead-man feature that activates when the user releases the handle. Also included are batteries, an integral battery charger, and battery level gauge. Easy access battery compartment simplifies battery maintenance.

  • Simple controls for quick movement
  • Walk behind style for ergonomic posture
  • Poly-on-steel steer and load wheels
  • Ability to raise to high levels of workspace
Assembled Wt.(lbs.): 780 Assembled Size: 25.5625"W x 51.1875"L x 61.8125"H

Total Ship Wt.(lbs.): 815 (only 1 package) Package 1 Size: 40"W x 64"D x 67"H Color: Black / Yellow

Uniform Capacity (Lbs.): 600 Raised Lift Height (In.): 60 Lowered Lift Height (In.): 8.5
Battery Voltage: 24V Battery Type: Lead Acid Number Of Batteries: 2 Spillable
Swivel Casters: (1) 10"dia. x 3.125"W Rigid Casters: (2) 6.25"dia. x 2.5"W Caster Type: Red Poly On Steel
Handle Height (In.): 54.125 Handle Diameter (In.): 1.25

Quickship Item?


NOT A Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

1 Year Limited Warranty

Details For Model: S-CB-NM-60
Out of Stock - Please Contact Sales
S-CB-NM-60

Steel Counter Balanced Powered Drive Narrow Mast Stacker 60" Lift 51-9/16"L x 25-9/16"W x 61-13/16"H 600 Lb. Capacity Black / Yellow

Counter balance stacker with a narrow mast design is ideal for die loading, machine feeding, and for loading and unloading trucks in confined areas. An ergonomic handle features easy-to-operate throttle with infinite adjustment of forward and reverse speeds, lift/lower controls, and emergency reverse function. Includes an automatic dead-man feature that activates when the user releases the handle. Also included are batteries, an integral battery charger, and battery level gauge. Easy access battery compartment simplifies battery maintenance.

  • Simple controls for quick movement
  • Walk behind style for ergonomic posture
  • Poly-on-steel steer and load wheels
  • Ability to raise to high levels of workspace
Dimensions: 25.5625"W x 51.1875"L x 61.8125"H Sell UOM: -- Color: Black / Yellow
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 815 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Uniform Capacity (Lbs.): 600 Raised Lift Height (In.): 60 Lowered Lift Height (In.): 8.5
Battery Voltage: 24V Battery Type: Lead Acid Number Of Batteries: 2 Spillable
Swivel Casters: (1) 10"dia. x 3.125"W Rigid Casters: (2) 6.25"dia. x 2.5"W Caster Type: Red Poly On Steel
Handle Height (In.): 54.125 Handle Diameter (In.): 1.25
