          Urethane Hose & Cable Crossovers

          Protect hoses and cables from everyday foot traffic. Handles loads up to 100 PSI (2,400 pounds) with
          less than 10% deflection. Constructed of durable urethane material. Designed with traction cleats on
          top surface to prevent slippage (for light traffic and slow applications only).

              MODEL        OVERALL SIZE    USABLE SPAN      UNIFORM       WEIGHT
              NUMBER         (W x L)         (W x H)        CAPACITY      (POUND)
           URTH-24        23¼" x 23½"       3" x 3"        2,400 lb.       18                                     LOADING DOCK EQUIPMENT
           URTH-36        23¼" x 35½"       3" x 3"        2,400 lb.       35
           URTH-48        23¼" x 47½"       3" x 3"        2,400 lb.       39

          Multi-Channel Cable Protectors
          The fast and easy way to guard and protect valuable electrical cables and hose lines from damage and
          abuse while providing a method of safe crossing for vehicle and pedestrian traffic. Five (5) channel
          design is ideal for construction sites, sporting events, and warehouses. Constructed of synthetic rubber
          with a yellow plastic lid. Ends include interlocking tabs for creating longer assemblies.  Left and right
          sections ends are at 22½ degree.  Four (4) left or four (4) right sections joined together form a 90
          degree turn. Maximum weight loading capacity is 20,000 lb.                model MCHC-5R
              MODEL                           CHANNEL SIZE   OVERALL SIZE   WEIGHT
             NUMBER   DESCRIPTION               (W x H)       (W x L x H)  (POUND)
                                                                      1
                                                    3
           MCHC-5L   5-Channel LEFT Section   1½" x 1 /8"*  19¼" x 13¾" x 2 /8"  28
                                                    3
                                                                      1
           MCHC-5R   5-Channel RIGHT Section  1½" x 1 /8"*  19¼" x 13¾" x 2 /8"  28
          *OUTSIDE CHANNELS 1-3/8"W x 1-3/8"H
          Molded Rubber Hose & Cable Crossovers
          Designed to protect cables and hoses from pedestrian and rolling traffic. The top surface of each
          crossover includes serrations for extra traction. Optional connectors may be used to interlock
          individual units together to form wider crossovers. Simply lock together as many units as required.  model MRBR-24
          Model MRBR-24 has carrying handles molded into the ramp.
          Fits over cables to protect hoses from punctures and kinks.
          Series RHCB is ideal for people who are always switching out cables, but do not
          want to move the ramp. The model RHCB-A features an aluminum tread plate
          insert to protect hoses and cables (for light traffic and slow applications only).  CONNECTORS  model RHCB-12

               MODEL       OVERALL SIZE     USABLE SPAN       UNIFORM      WEIGHT
              NUMBER         (W x L)          (W x H)         CAPACITY     (POUND)
           MRBR-24        24" x 23¼"        3" x 1½"        2,400 lb.      48
           MRBR-CON                   CONNECTOR PER PAIR                    3
                                 5
           RHCB-12        12" x 32 /8"     3½" x 2 /8"      2,400 lb.      33      model RHCB-12A
                                                  7
           RHCB-12A        12" x 32 /8"      3" x 2 /8       2,400 lb.      38
                                 5
                                                 7
           RHCB-CON                   CONNECTOR PER PAIR                    2
          Multi-Purpose Ramps

          High impact ramps are perfect for a variety of work environments: postal routes, schools, hospitals,
          warehouses, and delivery routes. These ramps make it simple to move loads onto a curb or over hoses   PLASTIC
                                                                                    model MPR-2310-G
          and cables. The textured non-skid surface allows for sure footing on the incline and decline. The
          lightweight and completely portable unit handles hand trucks and other wheeled equipment with ease.
                MODEL                                            UNIFORM   WEIGHT
               NUMBER      MATERIAL   WIDTH   LENGTH    HEIGHT   CAPACITY  (POUND)
                                                         11
           MPR-2310-G     PLASTIC    23¼"     10½"     3 /16"   5,000 lb.   6                       BRIDGE KIT
           MPR-2313-G     PLASTIC    23¼"     13¼"      5½"     5,000 lb.   8
                                                         7
                                                 5
                                       13
           MPR-2410       PLASTIC    23 /16"  10 /8"    3 /8"   5,000 lb.   7
           MRR-2310       RUBBER     23¼"     10¼"     3 /16"   5,000 lb.   21     PLASTIC
                                                         9
           MPR-10-KIT     OPTIONAL BRIDGE KIT FOR MPR-2310-G, MPR-2410 or MRR-2310  6  model MPR-2410
           MPR-13-KIT     OPTIONAL BRIDGE KIT FOR MPR-2313-G                6

                                                                                    SOLID RUBBER, model MRR-2310
