31
          Steel Pick-Up/Van Ramps

          These economical serrated ramps provide minimum slippage. Overlapping lip provides smooth
          transition into cargo area. Single piece construction with bolt-on lip.
              MODEL              WIDTH       GROSS        SINGLE WHEEL   WEIGHT
             NUMBER     LENGTH  PER RAMP  UNIFORM CAPACITY  UNIFORM CAPACITY  (POUND)
           RAMP-72      72"      9"        1,000 lb.       500 lb.      43 pr.
           RAMP-96      96"      9"        1,000 lb.       500 lb.      60 pr.                    model RAMP-72   LOADING DOCK EQUIPMENT
          Wooden Ramp Kits

          Kits allow for building wooden ramps using common lumber.  Each kit includes two (2) steel end
          plates and rubber bottom tips.   Installation hardware is included.  Drilling required for installation.
          Lumber/boards are not included.
             MODEL                                       USABLE          WEIGHT                         model RK-8
             NUMBER           DESCRIPTION              LUMBER SIZE       (POUND)
           RK-8          WOODEN RAMP KIT                8" x 2"           10
           RK-12         WOODEN RAMP KIT               12" x 2"           16
          Steel Container Ramps with Flip-Over Bridge
          Heavy duty steel container ramps facilitate easy loading/unloading of shipping containers when
          placed on ground level.  Hinged flip-over bridge allows for easy transportation and compact storage.
          Tapered lip provides smooth transition into container at various heights.  Built-in fork pockets in
          base for convenient fork truck positioning.
             MODEL     OVERALL      OVERALL                   UNIFORM     WEIGHT
            NUMBER      WIDTH       LENGTH       HEIGHT       CAPACITY   (POUND)                        series SCR
           SCR-72       76½"        98 /8"       4 /4"       15,000 lb.    816
                                                  1
                                      1
           SCR-84       88½"        98 /8"       4 /4"       15,000 lb.    924
                                      1
                                                  1
          Steel Container Ramps with Side Rails
          A CRS container ramp is the perfect asset for loading and unloading products over uneven surfaces.
          The steel construction is long lasting and durable throughout harsh working conditions and
          inclement weather. The raised tread plate platform surface enables the user to have sure footing and
          minimize worker injury during use. The beveled edges on both ends allow smooth entry/exit by
          limiting the surface of height difference during transition. Side curbs also play a large role in the
          user safety by helping to maintain a safe alignment of goods as they pass from one area to another.
          Pick-up chains are included for simple transference of unit to different areas around the workplace.
          A range of large capacity designs are available to best suit your specific needs.   series CRS
              MODEL                              RAMP SIZE              WEIGHT
              NUMBER          DESCRIPTION         (W x L)    CAPACITY   (POUND)
           CRS-6060-15  STEEL CONTAINER RAMP     60" x 60"  15,000 lb.   448
           CRS-6060-20  STEEL CONTAINER RAMP     60" x 60"  20,000 lb.   458
           CRS-7272-20  STEEL CONTAINER RAMP     72" x 72"  20,000 lb.   787
           CRS-8472-20  STEEL CONTAINER RAMP     84" x 72"  20,000 lb.   797
          Wheel Chair Ramps

          The Americans with Disabilities Act requires that all buildings must be accessible to disabled persons. Failure to comply may result in monetary
          damages and civil penalties. According to ADA rules and regulations, for every inch of rise you must have a foot of ramp in length.







          A) TELESCOPIC RAMP is constructed of lightweight   B) FOLD-A-WAY RAMP easy, one person storage and   C) GRATE RAMP is a semi-permanent ramp
          aluminum extrusion. Top surface is serrated for   handling. Slip-resistant surface provides extra traction.   that is ideal for high traffic areas. Handrails
          positive traction.                Each ramp comes with 2 handles for easy positioning.  are available.
                      MODEL          DIMENSIONS         UNIFORM        WEIGHT
            TYPE     NUMBER        (WIDTH x LENGTH)     CAPACITY       (POUND)
                                     9
                                           1
             A      D-TR-72         9 /16" x 76 /16"     550 lb.       38 pr.
                                           1
                                     9
             A      D-TR-88         9 /16" x 88 /16"     550 lb.       44 pr.
                                      1
             B      D-FAR-120       12 /16" x 124"       550 lb.       78 pr.
             C      D-AW-88           36" x 88"          500 lb.        182       D) ROLL-O-RAMP provides access over curbs.
             C      D-AW-132         36" x 132"          500 lb.        177       Wheels installed on curb of ramp for
             C      D-AW-168         36" x 168"          500 lb.        227       portability. Beveled edges create smooth
             D      D-ROL-48         50 /16" x 48"       500 lb.        52        transition between ramp and ground.
                                      7
