15
          Light Duty Swinging Traffic Doors

          These Light Duty Traffic Doors are assembled with rotationally molded cross-linked
          polyethylene. This extremely durable construction is capable of withstanding the wear and
          tear associated with high volume traffic areas. These doors are known for their long term
          value in supermarkets, retail establishments, and food service operations as they provide a
          visual separation, sound barrier, and thermal separation. The door is designed to comply
          with all USDA sanitation requirements and is NSF approved. The corrosion resistant                       LOADING DOCK EQUIPMENT
          panel is ideal for wash down applications as it has no gaps or joint seams. The total width
          of the light duty traffic doors are 1½" thick.

              MODEL                                   SIZE        WEIGHT
             NUMBER            DESCRIPTION           (W x  H)     (POUND)
           LDSW-37        SINGLE DOOR PANEL          3' x 7'       200
           LDSW-57        DOUBLE PANEL DOOR          5' x 7'       340
           LDSW-58        DOUBLE PANEL DOOR          5' x 8'       350
           LDSW-67        DOUBLE PANEL DOOR          6' x 7'       360
           LDSW-68        DOUBLE PANEL DOOR          6' x 8'       360
           LDSW-88        DOUBLE PANEL DOOR          8' x 8'       400


          Heavy Duty Swinging Traffic Doors
          These multi-purpose lightweight doors are tough enough to take the abuse of personnel,
          stock carts, and motorized pallet jacks.  The door panels are constructed with 1/8” thick
          rotationally molded cross-linked polyethylene outer shell and foamed-in-place Non-CFC
          urethane foam core.  The panels are corrosion resistant, making it ideal for washdown
          applications as it has no gaps or joint seams.   The door comes standard with 24” black
          bumpers on both sides of the door.  Double acting V-cam hinging system operates
          smoothly and is virtually maintenance free with its permanently lubricated needle bearing
          roller assembly.  There is a 1/8” thick polycarbonate window with black aluminum frame
          recessed a minimum of 1/8” from the face of the panel to protect the window’s surface
          from abrasion caused by passing loads.
              MODEL                                   SIZE        WEIGHT
             NUMBER            DESCRIPTION           (W x  H)     (POUND)
           HDSW-37        SINGLE DOOR PANEL          3' x 7'       146
           HDSW-57        DOUBLE PANEL DOOR          5' x 7'       256
           HDSW-58        DOUBLE PANEL DOOR          5' x 8'       280
           HDSW-67        DOUBLE PANEL DOOR          6' x 7'       290
           HDSW-68        DOUBLE PANEL DOOR          6' x 8'       320
           HDSW-88        DOUBLE PANEL DOOR          8' x 8'       400



          Economical Overhead Door Warning Barriers
          Protect overhead doors from fork trucks and other traffic coming and going throughout
          each day. Intended for use as a warning system - not a fork truck stop. Constructed
          with tubular steel uprights and a 4" x 4" wooden beam across the top of the guard. The
          wooden beam can be easily and inexpensively replaced when damaged. Guard will not
          interfere with overhead door. Complete unit is painted high visibility OSHA safety
          yellow. Concrete installation kit available.

              MODEL      USABLE DOOR   USABLE DOOR                WEIGHT
              NUMBER      WIDTH (FT.)  HEIGHT (FT.)    COLOR      (POUND)
           DWB-88            8             8          YELLOW       358
           DWB-810           8            10          YELLOW       475
           DWB-910           9            10          YELLOW       490                          model DWB-88
           DWB-1010         10            10          YELLOW       505
           AS-125�        ANCHOR BOLTS FOR CONCRETE (1) 1/2" x 5"   1
           AS-125-4PK�    ANCHOR BOLTS FOR CONCRETE (4) 1/2" x 5"   4
