          Round or Triangular Fork Extensions

          Ideal for moving around large rolls of material. Available in round or triangular style. Baked-in powder-
          coated toughness. To install, insert loop at the tip of the fork and slide it up at a 45° angle. Then, lay it
          down over the fork. OSHA regulations require that extensions do not exceed the length of the existing fork
          length by more than 150% (e.g. 48" existing forks, the fork extension should not exceed 72").
                                                                                                      ROUND STYLE
                                                                                                          Suffix R
              MODEL     ACCOMMODATES  FORK EXTENSION              MAX. FORK   WEIGHT                               FORK TRUCK ATTACHMENTS
             NUMBER      FORK WIDTH   INSIDE WIDTH   LENGTH       THICKNESS  PAIR (LB.)
           ROUND EXTENSIONS
           FE-4-54-R        4"           4½"           54"           2"         82                        BOTTOM
           FE-4-63-R        4"           4½"           63"           2"         96                          VIEW
           FE-5-54-R        5"           5½"           54"           2"         96
           FE-5-63-R        5"           5½"           63"           2"        110
           TRIANGULAR EXTENSIONS
           FE-4-54-T        4"           4½"           54"           2"         84
           FE-4-63-T        4"           4½"           63"           2"         98
           FE-5-54-T        5"           5½"           54"           2"         96
           FE-5-63-T        5"           5½"           63"           2"        110
          Fork Rear Spacers                                                                        TRIANGULAR STYLE
                                                                                                          Suffix T
          Insert the loop at the tip of the fork and slide it up at a 45° angle.  Then, lay it down over the existing forks.
          Practical for pushing pallets two or three deep into a trailer conveniently and easily.
               MODEL       ACCOMMODATES        SPACER         MAXIMUM FORK   WEIGHT
              NUMBER        FORK WIDTH         LENGTH          THICKNESS     PAIR (LB.)
           FRS-4-12             4"              12"               2"           36
           FRS-5-12             5"              12"               2"           41
           FRS-6-12             6"              12"               2"           44
          Roller Forks

          Mechanical forks designed to reduce costs through pallet-less handling. Ideal for FIBC bags, (large bulk
          sacks), slip-sheeted goods, and corrugated bundles as well as regular pallets.  Use with standard lift truck
          forks providing greater operational versatility.  The unique series of dual-roller cartridges allow the forks to
          place and retrieve heavy loads quickly and easily.  See website for additional sizes.
             MODEL                            HEAL     MOUNTING    UNIFORM    WEIGHT
             NUMBER     WIDTH      LENGTH   THICKNESS    CLASS     CAPACITY   (POUND)
           RF-20-42      7.5"      43.3"      1.9"        II       2,200 lb.   286
           RF-20-48      7.5"      47.2"      1.9"        II       2,200 lb.   297
           RF-30-42      6.3"      43.3"      1.9"       II/III    3,300 lb.   272
           RF-30-48      6.3"      47.2"      1.9"       II/III    3,300 lb.   255
           RF-40-42     8.25"      43.3"      2.3"        II       4,400 lb.   326
           RF-40-48     8.25"      47.2"      2.3"        II       4,400 lb.   341
           RF-50-42     8.25"      43.3"      2.3"       II/III    5,300 lb.   335
           RF-50-48     8.25"      47.2"      2.3"       II/III    5,300 lb.   353
           RF-60-42     12.2"      43.3"      2.3"       II/III    6,600 lb.   562
           RF-60-48     12.2"      47.2"      2.3"       II/III    6,600 lb.   595
          Fork Lift Loading Attachment

          The Dock-Pro™ can increase company productivity and reduce injury.  The unit is easy to use, involves
          low maintenance, and comes with a 96" long conveyor and safety lock.  It is adjustable to 30½" below
          dock height and is adaptable to most fork lifts with custom designs available.  The Dock-Pro™ is a fork
          lift attachment designed to help load and carry material from loading dock fork lift to pickup truck.  It is
          designed to be safe, productive, and cost effective. Safety restraint is included to secure unit to fork truck.
              MODEL         OVERALL SIZE      FORK POCKET       UNIFORM       WEIGHT
              NUMBER         (W x L x H)       SIZE (W x L)     CAPACITY     (POUND)
           DP-3896-15     39½" x 143" x 40"    5½" x 2½"       1,500 lb.      1090
          Fork Lifter                                                                          New

          Designed to quickly and easily attach or remove forged steel forks from a carriage.  The lifter
          features six different hook points to balance a variety of fork lengths.  Two tightening knobs are
          included to secure the fork to the lifter when being moved.  Steel construction with tough-baked
          in powder-coated yellow finish.
             MODEL         OVERALL SIZE       FORK POCKET       UNIFORM       WEIGHT
             NUMBER         (W x L x H)         (W x H)         CAPACITY     (POUND)
           FORK-P        6" x 18½" x 14"       5½" x 3"          400 lb.       30
