          Lift Master Booms

          Unique performance, convenience, and safety features are built
          into every Lift Master Boom. Fabricated from structural steel with
          welding to meet AWS creates a rugged and durable boom that will
          provide long term service. Telescopic units come with an infinitely                      LIFT MASTER BOOM
                                                                                                     model LM-1T-4-36
          adjustable locking screw (except orbit booms which feature a
          locking detent). Fork pockets for 4,000 pound uniform capacity                                           FORK TRUCK ATTACHMENTS
          models measure 7½"W x 2½"H usable on 24" centers. Usable fork
          pockets are 7¼"W x 2¼"H for 6,000 and 8,000 pound uniform
          capacity models. Optional fork pocket centers available, contact
          factory.  A safety restraint secures the boom to the fork truck for
          safe operation. Each unit includes two lifting hooks.
                                                            ORBITING BOOM
                                                            model LM-OBT-4-24                        ECONOMY BOOM
                                                                                                    model LM-EBT-4-24
               MODEL                        OVERALL     OVERALL     UNIFORM   WEIGHT
              NUMBER          DESCRIPTION   HEIGHT   EXTENDED LENGTH  CAPACITY  (POUND)
           TELESCOPING STYLE
                                              7
                                                          1
           LM-1T-4-24�    LIFT MASTER BOOM   25 /8"     151 /4"     4,000 lb.  425
                                              11
                                                           5
           LM-OBT-4-24�   ORBIT BOOM        27 /16"     146 /8"     4,000 lb.  433                   FIXED 15° BOOM
                                                          5
                                              13
           LM-HRT-4-24    HIGH-RISE BOOM    79 /16"     92 /8"      4,000 lb.  950                  model LM-F15-4-24
                                                          1
           LM-EBT-4-24�   ECONOMY BOOM       13½"       151 /2"     4,000 lb.  333
           LM-F15-4-24    FIXED 15 DEGREES   33"         147"       4,000 lb.  370
                                                          1
                                              7
           LM-1T-6-24�    LIFT MASTER BOOM   25 /8"     151 /4"     6,000 lb.  480
                                              11
                                                           5
           LM-OBT-6-24�   ORBIT BOOM        27 /16"     146 /8"     6,000 lb.  476
                                              13
                                                          5
           LM-HRT-6-24    HIGH-RISE BOOM    79 /16"     92 /8"      6,000 lb.  950
                                                          1
           LM-EBT-6-24�   ECONOMY BOOM       13½"       151 /2"     6,000 lb.  377
                                                           1
                                              9
           LM-1T-8-24     LIFT MASTER BOOM  26 /16"     149 /8"     8,000 lb.  647
           LM-OBT-8-24    ORBIT BOOM         28 /8"     148 /2"     8,000 lb.  622
                                              7
                                                           1
           LM-EBT-8-24    ECONOMY BOOM       15"        149 /8"     8,000 lb.  577
                                                           3
           NON-TELESCOPING STYLE
           LM-1NT-4-24    LIFT MASTER BOOM  24 /16"     81 /2"      4,000 lb.  333
                                                          1
                                              13
           LM-OBNT-4-24   ORBIT BOOM         26 /8"     80 /8"      4,000 lb.  337
                                                          7
                                              5
           LM-HRNT-4-24   HIGH-RISE BOOM    78 /16"     50 /8"      4,000 lb.  810                   HIGH-RISE BOOM
                                              9
                                                          3
                                                          5
                                              5
           LM-EBNT-4-24   ECONOMY BOOM      13 /16"     81 /8"      4,000 lb.  258                 model LM-HRNT-4-24
           LM-1NT-6-24    LIFT MASTER BOOM  24 /16"     81 /2"      6,000 lb.  489
                                                          1
                                              13
                                              5
                                                          7
           LM-OBNT-6-24   ORBIT BOOM         26 /8"     80 /8"      6,000 lb.  391
                                                          3
                                              9
           LM-HRNT-6-24   HIGH-RISE BOOM    78 /16"     50 /8"      6,000 lb.  697
                                              15
                                                          5
           LM-EBNT-6-24   ECONOMY BOOM      13 /16"     81 /8"      6,000 lb.  291
           LM-1NT-8-24    LIFT MASTER BOOM   23½"       80 /8"      8,000 lb.  476
                                                          1
           LM-OBNT-8-24   ORBIT BOOM         25 /8"     79 /2"      8,000 lb.  792
                                                          1
                                              1
                                              1
                                                          3
           LM-EBNT-8-24   ECONOMY BOOM       11 /2"     80 /8"      8,000 lb.  418                 LIFT MASTER BOOM
          LARGER FORK POCKETS 7"W x 3"H (inside dimensions), model LM-FP-37                          model LM-1T-8-24
          LARGER FORK POCKETS 9"W x 3"H (inside dimensions), model LM-FP-39
          Shorty Lift Master Booms
                                                                                        NON-TELESCOPING ECONOMY BOOM
          Short boom length is ideal for tight areas.  Choose either telescoping or non-telescoping design.   model LM-EBNT-4-24
          Includes built-in fork pockets, safety restraint, and two lifting hooks.  Overall width is 32".
          Steel construction.
               MODEL                         OVERALL     OVERALL     UNIFORM  WEIGHT
               NUMBER         DESCRIPTION     HEIGHT     LENGTH      CAPACITY  (POUND)
                                                         1
           LMS-EBT-46-4�    TELESCOPING       13½"     55 /4" to 93"  4,000 lb.  248                  SHORTY BOOM
                                                         1
           LMS-EBT-46-6�    TELESCOPING       13½"     55 /4" to 93"  6,000 lb.  296               model LMS-EBT-46-8
           LMS-EBT-46-8     TELESCOPING        15"     53 /8" to 90 /8"  8,000 lb.  430
                                                              7
                                                        7
                                                5
                                                           3
           LMS-EBNT-40-4   NON-TELESCOPING    13 /16"     50 /4"    4,000 lb.  214
                                                5
                                                           3
           LMS-EBNT-40-6   NON-TELESCOPING    13 /16"     50 /4"    6,000 lb.  244
                                                           3
           LMS-EBNT-40-8  NON-TELESCOPING     11½"        49 /8"    8,000 lb.  320
                                                                                                   NON-TELESCOPING
                                                                                                      SHORTY BOOM
                                                                                                  model LMS-EBNT-40-4
