          Self-Dumping Steel Hoppers with Bumper Release

          Hopper automatically dumps when bumper release contacts the front of the dumpster.  Hopper
          returns to an upright and locked position automatically after it dumps.  Also includes a cable that
          may be operated from the seat of the fork truck to manually dump the hopper.  A safety restraint is
          provided to secure the hopper to the fork truck.  Usable fork pockets are 7½"W x 2½"H.  Optional
          leak proof design sold separately.  D-25, D-33, D-50, D-75, and D-100 are stackable if you stack
          the top hopper turned 90° from the bottom. Blue baked-in powder-coated toughness standard with           FORK TRUCK ATTACHMENTS
          exception of models D-300-HD-NA, D-350-HD, D-400-HD & D-500-HD.  Must be attached
          to fork truck when dumping.  Options below and on pages 180 and 181.

              MODEL      VOLUME    UNIFORM      OVERALL SIZE  FORK POCKET  WEIGHT
             NUMBER    CUBIC YARDS  CAPACITY     (W x L x H)   CENTERS   (POUND)
           LIGHT DUTY  • 12 GAUGE STEEL
                                                    7
           D-25-LD�       1/4      2,000 lb.  26" x 51 /8" x 38"  18"     335
                                                    7
           D-33-LD�       1/3      2,000 lb.  26" x 51 /8" x 38"  18"     340
                                               11
           D-50-LD�       1/2      2,000 lb.  33 /16" x 51¾" x 38"  18"   365
                                             11
                                                    1
                                                         11
           D-75-LD�       3/4      2,000 lb.  31 /16" x 61 /8" x 42 /16"  18"  449
                                             11
                                                         11
                                                    1
           D-100-LD�       1       2,000 lb.  41 /16" x 61 /8" x 42 /16"  18"  479
                                                          13
                                             11
                                                    5
           D-150-LD�      1½       2,000 lb.  43 /16" x 68 /16" x 51 /16"  28"  565
                                                          13
                                             11
                                                    5
           D-200-LD�       2       2,000 lb.  56 /16" x 68 /16" x 51 /16"  28"  613
                                                          3
                                              9
                                                    3
           D-250-LD�      2½       2,000 lb.  69 /16" x 68 /8" x 51 /4"  28"  863
                                                   5
                                              3
                                                         13
           D-300-LD�       3       2,000 lb.  81 /4" x 68 /8" x 51 /16"   28"  940
           MEDIUM DUTY  • 10 GAUGE STEEL                                                   BUMPER RELEASE
                                                        1
                                                   7
           D-25-MD�       1/4      4,000 lb.  26" x 51 /8" x 38 /16"  18"  397
                                                   7
                                                        1
           D-33-MD�       1/3      4,000 lb.  26" x 51 /8" x 38 /16"  18"  397
                                                    7
                                                         1
                                              9
           D-50-MD�       1/2      4,000 lb.  33 /16" x 51 /8" x 38 /16"  18"  435
                                              9
                                                          3
                                                    1
           D-75-MD�       3/4      4,000 lb.  31 /16" x 61 /8" x 42 /4"  18"  543
                                                   1
                                                         11
                                              1
           D-100-MD�       1       4,000 lb.  41 /2" x 61 /8" x 42 /16"  18"  534
                                              9
                                                    3
                                                         13
           D-150-MD�      1½       4,000 lb.  43 /16" x 68 /8" x 51 /16"  28"  714
                                                         13
                                                   5
                                              5
           D-200-MD�       2       4,000 lb.  56 /8" x 68 /16" x 51 /16"  28"  701
                                                          3
                                              9
                                                    3
           D-250-MD�      2½       4,000 lb.  69 /16" x 68 /8" x 51 /4"  28"  863
                                                         13
                                                   5
                                              3
           D-300-MD�       3       4,000 lb.  81 /4" x 68 /8" x 51 /16"   28"  940
           HEAVY DUTY  • 8 GAUGE STEEL
                                                   7
                                                        1
           D-25-HD�       1/4      6,000 lb.  26" x 51 /8" x 38 /16"  18"  397
                                                   7
                                                        1
           D-33-HD�       1/3      6,000 lb.  26" x 51 /8" x 38 /16"  18"  397
                                              9
                                                         1
                                                    7
           D-50-HD�       1/2      6,000 lb.  33 /16" x 51 /8" x 38 /16"  18"  435
                                                    1
                                                          3
                                              9
           D-75-HD�       3/4      6,000 lb.  31 /16" x 61 /8" x 42 /4"  18"  543
                                                          3
                                                    1
                                              9
           D-100-HD�       1       6,000 lb.  41 /16" x 61 /8" x 42 /4"  18"  590
                                              9
                                                    3
                                                         13
           D-150-HD�      1½       6,000 lb.  43 /16" x 68 /8" x 51 /16"  28"  714
                                                   5
                                             9
                                                         13
           D-200-HD�       2       6,000 lb.  56 /16" x 68 /16" x 51 /16"  28"  789
                                                    3
                                                          3
                                              9
           D-250-HD�      2½       6,000 lb.  69 /16" x 68 /8" x 51 /4"  28"  863
                                              3
                                                   5
                                                         13
           D-300-HD�       3       6,000 lb.   81 /4" x 68 /8" x 51 /16"   28"  940
                                                          3
                                              5
                                                    3
           D-300-HD-NA     3       6,000 lb.  55 /16" x 79 /8" x 64 /8"  28"  1107
                                                         3
                                                   3
           D-350-HD       3½       6,000 lb.  64" x 79 /8" x 64 /8"  28"  1128
                                                    3
                                                          3
                                              11
           D-400-HD        4       6,000 lb.  72 /16" x 79 /8" x 64 /8"  28"  1128
                                                         3
                                                   3
           D-500-HD        5       6,000 lb.  90" x 79 /8" x 64 /8"  28"  1254                        model D-500-HD
          Options for "D" Style Hoppers
          Sideways Tilt Option, model D-TILT, can be used with D-75-LD and D-100-LD hoppers only.
          User must obtain  written permission from fork truck manufacturer prior to use.  Factory or field
          installed.  May still use hopper like normal.  Adds 3 /16" to height.
                                              5
              MODEL                                                      WEIGHT
             NUMBER                       DESCRIPTION                   (POUND)
           D-TILT      SIDEWAYS TILT OPTION                               130
           LEKP        WELDED LEAK PROOF OPTION FOR "D" STYLE HOPPER      5
           D-DPLG-75*  ¾" THREADED DRAIN PLUG, LOCATED IN LEFT CORNER     2        model D-TILT
           D-DPLG-2*   2" THREADED DRAIN PLUG, LOCATED IN LEFT CORNER     2
           LUG         (4) LIFTING LUGS (WELDED) ONE ON EACH CORNER       23
          *H-DPLG OPTION INCLUDES LEAK PROOF CHUTE WELDS
          Side Extensions, are great addition for material handling and construction facilities.  The extended
          sides are constructed of steel mesh for high strength durability during transference of goods, while
          the yellow painted finish delivers great visibility.
                MODEL             EXTENSION            WORKS WITH       WEIGHT
               NUMBER              HEIGHT             HOPPER SERIES     (POUND)
                                    11
           D-150-EXT-SMY          15 /16"                D-150            37          New
           D-200-EXT-SMY          15 /16"                D-200            40
                                    11
           D-250-EXT-SMY          15 /16"                D-250            45
                                    11
           D-300-EXT-SMY          15 /16"                D-300            50       model D-200-EXT-SMY
                                    11
