184                             Steel Self-Dumping Hoppers
       FORK TRUCK ATTACHMENTS               dump with a forklift or make the unit mobile with the optional casters.  Self dumping hoppers


                                            All welded Self-Dumping Hoppers handle bulk materials and scrap easily.  Must transport and
                                            are engineered to dump when the safety latch is tripped and to return to an upright locked
                                            position when empty.  All units come with safety retaining chain and a trip rope assembly.
                                            The ¼ to 2 cubic yard hoppers have a formed stackable base (8 gauge 1 - 2½ LD to MD and
                                            ¼ - 2½ HD is .220 gauge), the 3 to 5 cubic yard hoppers have structural bases (¼" base) with
                                            reinforced rockers for heavy use.  Options include: casters, lids (1 to 2½ cubic yard), 3-way
                                            entry, lifting lugs, and paint colors.  Paint finish is vista green.  Must be attached to fork
                                            truck when dumping.


                                             STACKABLE STEEL SELF-DUMPING HOPPERS
                                                            VOLUME
                                                                       UNIFORM
                                                                                     OVERALL SIZE
                                                 MODEL
                                                                                                    GAUGE
                                                                                                           WEIGHT
                                                                       CAPACITY
                                                                                      (W x L x H)
                                                NUMBER
                                                              1
                                                                                                            445
                                                                                                     12
                                             HOP-100-LD    CUBIC YARDS  2,000 lb.  41½" x 62" x 37"  OF STEEL  (POUND)
                                             HOP-150-LD      1-1/2     2,000 lb.   59½" x 62" x 37"  12     540
                                             HOP-200-LD       2        2,000 lb.   59½" x 64" x 46"  12     600
                                             HOP-250-LD      2-1/2     2,000 lb.   59½" x 64" x 51"  12     620
                                             HOP-100-MD       1        4,000 lb.   41½" x 62" x 37"  10     495
                                             HOP-150-MD      1-1/2     4,000 lb.   59½" x 62" x 37"  10     630
                                             HOP-200-MD       2        4,000 lb.   59½" x 64" x 46"  10     705
                                             HOP-250-MD      2-1/2     4,000 lb.   59½" x 64" x 51"  10     730
                    Steel Lid Style A        HOP-25-HD        1/4      4,000 lb.   30¾" x 49" x 26½"  7     375
                Single hinge in the center   HOP-33-HD        1/3      4,000 lb.  30¾" x 48½" x 31½"  7     405
                of the hopper with the back   HOP-50-HD       1/2      4,000 lb.  41½" x 48½" x 31½"  7     470
                half welded closed           HOP-75-HD        3/4      5,000 lb.  41½" x 56¾" x 35½"  7     575
                                             HOP-100-HD       1        6,000 lb.   41½" x 62" x 37"  7      625
                                             HOP-150-HD      1-1/2     6,000 lb.   59½" x 62" x 37"  7      785
                                             HOP-200-HD       2        6,000 lb.   59½" x 64" x 46"  7      880
                                             HOP-250-HD      2-1/2     6,000 lb.   59½" x 64" x 51"  7      905
                                             HOP-300-HD*      3        6,000 lb.  65½" x 71½" x 59½"  7    1250
                                             HOP-400-HD*      4        6,000 lb.  85½" x 71½" x 59½"  7    1385
                                             HOP-500-HD*      5        6,000 lb.  105½" x 71½" x 59½"  7   1560
                                             *CASTER BASE FOR CASTER OPTION, MODEL HOP-CASTER-BASE
                                              SPECIALTY STEEL LIDS FOR HOPPERS (SERIES HOP only) (color is green / welded on)
                     Steel Lid Style C           MODEL            HOPPER                                WEIGHT
                 Single hinge in the center,     NUMBER          CUBIC YARDS            STYLE           (POUND)
                 but both front and back lids   LID-100-A           1                     A               65
                 can be opened.
                                              LID-150-A            1-1/2                  A               92
                                              LID-200-A             2                     A              106
                                              LID-250-A            2-1/2                  A              106
                                              LID-100-C             1                     C               65
                                              LID-150-C            1-1/2                  C               92
                                              LID-200-C             2                     C              106
                                              LID-250-C            2-1/2                  C              106

                                            Chip & Waste Trucks

                                            • Heavy-Duty Reinforced Steel Construction
                                            • Use Inside and Outside
                                            • Ideal for Clean Up & Other Material Handling Jobs
                                            Sturdy Chip and Waste Trucks are ideal for collecting and
                                            transporting bulk materials or trash.  Tapered ends allow easy
                                            loading and dumping.  Hopper is balanced to maneuver and
                                            dump with less effort.  All welded 14 gauge steel construction.
                                            Options, including leak proof chute welds, model LEKP, 3/4"
                                            drainage plug, model H-DPLG-75, and 2" drain plug model
                                            H-DPLG-2, leak proof chute welds included with drainage plugs.
                                            Blue baked-in powder-coated toughness.
                                                MODEL     VOLUME     UNIFORM      OVERALL SIZE   CASTER   WEIGHT
                                               NUMBER    CUBIC FEET  CAPACITY      (W x L x H)    SIZE    (POUND)
                                                                               1
                                                                                           7
                                             CHIP-17.5     17.5      1,500 lb.  26 /8" x 66 /16" x 37 /16"  8" x 2"  146
                                                                                     11
                                             CHIP-22.2     22.2      2,000 lb.  32 /8" x 66 /16" x 37 /16"  8" x 2"  155
                                                                               1
                                                                                           7
                                                                                     11
                                             CHIP-26.7     26.7      2,000 lb.  38 /8" x 66 /16" x 37 /16"  8" x 2"  167
                                                                               1
                                                                                     11
                                                                                           7
