Cargo Bars

• Keep trailer contents in place - eliminate damaged goods
• Simple mechanical lock - will not vibrate loose
During transport, keep trailer contents securely in place with these easy to use Cargo Bars. Constructed
of 1½" square tubing, unless specified. 14 gauge wall construction is lightweight, yet extremely strong.
Square articulating steel end plates feature rubber pads for positive gripping action. End plates measure
4" x 4" on models CL-15, CL-16, CL-17 & CL-20. End plates measure 4" x 2⅜" on model CB-5, LOADING DOCK EQUIPMENT
Easy to use ratchet mechanism allows one CB-7 & CB-7-S and 3¾" x 3¾" on model CL-18 and CBH-32. End plates measure 2⅜" x 3" on
person to adjust and ratchet into place.
model CB-PU-3. Bars fit between trailer walls.
A) CB-5 & CB-7 C) EB-96 & EB-102 works in conjunction with E-TRACK M) E-TRACK N) CB-HLDR
(E-TRACK sold separately).
Uniform decking/vertical and shoring/
horizontal rating 2,000 pounds.

D) CB-7-S E) CL-15 & CL-16 F) CL-17 G) CL-18 H) CL-20 I) CB-PU-3

MODEL SERVICE WEIGHT
TYPE NUMBER DESCRIPTION RANGE (POUND)
A CB-5� ONE PIECE ALUMINUM (ROUND TUBE) 88" to 103" 8
A CB-7� ONE PIECE ALUMINUM Heavy-Duty (ROUND TUBE) 89" to 104" 9
C EB-96� ONE PIECE ALUMINUM (E-TRACK) 85" to 96" 19
C EB-102� ONE PIECE ALUMINUM (E-TRACK) 92" to 102" 21
D CB-7-S� ONE PIECE STEEL (ROUND TUBE) 89" to 104" 12 J) CBH-32
E CL-15� ONE PIECE STEEL 87" to 119" 15 Top Hoop 70"W x 9"H
Bottom Hoop 78"W x 9"H
E CL-16� ONE PIECE STEEL GALVANIZED 87" to 119" 15
F CL-17� TWO PIECE STEEL GALVANIZED (FOLDING) 88" to 116" 17
9
3
G CL-18� TWO PIECE STEEL GALVANIZED (TELESCOPIC) 90 /8" to 139 /16" 24
H CL-20� TWO PIECE STEEL E & A TRACK (FOLDING) 87" to 116" 18
I CB-PU-3� ONE PIECE STEEL TRUCKS/VANS (ROUND TUBE) 40" to 70" 5
J CBH-32� ONE PIECE STEEL WITH FULL HOOPS 87" to 116" 28
1
K CH-7� GALVANIZED HOOPS (FOR CB SERIES ONLY) 30½"W x 23 /8"H 16
L CH-3� GALVANIZED HOOPS (FOR CL SERIES ONLY) 31"W x 24½"H 15
M E-TRACK� STEEL SECTION OF E-TRACK FOR TRAILERS 10 FOOT 16
N CB-HLDR� CARGO BAR HOLDER -- 7
K & L) Cargo Bar Hoops
CA Residents see model CH-7 for CB series Cargo Bars
WARNING A, Pg. 459 model CH-3 for CL series Cargo Bars
(cargo bars sold separately, hoops sold in pairs)

Truck Mounted Strap Winches

Tighten down loads to eliminate shifting. Choose from either weld or bolt on design. Strap and
winch bar sold separately. Low profile design available. Accommodates 4" straps up to 30' long.

MODEL OVERALL SIZE WEIGHT
NUMBER DESCRIPTION (W x L x H) (POUND)
SW-4-PSW*� WELD ON WINCH 3½" x 7¾" x 6¼" 10
SW-4-PSB*� BOLT ON WINCH 3½" x 7¾" x 6¼" 11
SW-BAR� MULTI-TASK CHROME PLATED WINCH BAR 1½" DIA. x 38"L 7
SW-BAR-PT� PAINTED WINCH BAR 1½" DIA. x 38"L 8
STRAP-30� 30 FOOT STRAP 4" W x 30'L 7
*ACCOMMODATES 4" WIDE BY 30 FOOT LONG STRAP
30 FOOT STRAP
model STRAP-30
