258                           Heavy Duty Guard Rails
       PROTECTIVE BARRIERS                Heavy Duty Guard Rails are one of the strongest on the market withstanding multiple hits from a forklift.



                                          Stops a 12,000 lb. forklift traveling at 8 mph. Upon impact, guard rail distributes the shock throughout
                                          the entire section, resulting in zero deflection.  Heavy duty pipe sleeved in durable HDPE plastic, where
                                          pipe post is 4" schedule 80 pipe, and pipe rail is 6" schedule 40 pipe.  Standard color is safety yellow. The
                                          maintenance-free, never paint again system will keep your facility looking clean and new.  Units arrive fully
                                          assembled.  Other configurations and sizes available, contact factory.

                                                                                                         WEIGHT
                                                                            OVERALL
                                                                                           BASE PLATE
                                                             OVERALL
                                               MODEL
                                               NUMBER
                                                                                            (W x L)
                                          HDGR-4-27
                                                                                                          299
                                                               48"
                                                                              27"
                                                                              36"
                                                                                           10" x 10"
                                                               48"
                                          HDGR-4-36
                                                                                                          321
                                                                              42"
                                                               48"
                                                                                                          336
                                                                                           10" x 10"
                                          HDGR-4-42          LENGTH          HEIGHT        10" x 10"     (POUND)
                                          HDGR-6-27            72"            27"          10" x 10"      387
                                          HDGR-6-36            72"            36"          10" x 10"      409
                                          HDGR-6-42            72"            42"          10" x 10"      424
                                          HDGR-8-27            96"            27"          10" x 10"      475
                                          HDGR-8-36            96"            36"          10" x 10"      497
                                          HDGR-8-42            96"            42"          10" x 10"      512
                                          HDGR-10-27          120"            27"          10" x 10"      563
                                          HDGR-10-36          120"            36"          10" x 10"      585
                                          HDGR-10-42          120"            42"          10" x 10"      600
                                          HDGR-12-27          144"            27"          10" x 10"      651
                                          HDGR-12-36          144"            36"          10" x 10"      673
                                          HDGR-12-42          144"            42"          10" x 10"      688
                                          AS-346�             ANCHOR BOLTS FOR CONCRETE (1) 3/4" x 6"      1
                                          AS-346-4PK�         ANCHOR BOLTS FOR CONCRETE (4) 3/4" x 6"      4
                                          Steel Pipe Safety Bollards
                             New
                                          Bollards can be used both indoors and outdoors to protect work areas, racking and personnel.  Plastic
                                          top caps are removable on the 1¾", 4½", and 5½" diameter units and bollard may be filled with
                                          concrete.  Steel caps are welded on the 6⅝" and 8⅝" diameter units.  Base plate includes four (4)
                                          pre-drilled mounting holes. Mounting kits and replacement caps available.  Baked-in powder-coated
                                          toughness.
                                              MODEL                                     OUTSIDE  BASE PLATE  WEIGHT
                                              NUMBER            FINISH          HEIGHT  DIAMETER  (W x L)  (POUND)
                                          BOL-24-2�     YELLOW POWDER COAT       24"      1¾"     4" x 4"   6
                                          BOL-36-2�     YELLOW POWDER COAT       36"      1¾"     4" x 4"   9
                                          BOL-42-2�     YELLOW POWDER COAT       42"      1¾"     4" x 4"   10
                                          BOL-48-2�     YELLOW POWDER COAT       48"      1¾"     4" x 4"   11
                                          BOL-24-4.5�   YELLOW POWDER COAT       24"      4½"     8" x 8"   17
                           model BOL-42-2
                                          BOL-36-4.5�   YELLOW POWDER COAT       36"      4½"     8" x 8"   22
                                          BOL-42-4.5�   YELLOW POWDER COAT       42"      4½"     8" x 8"   26
                                          BOL-48-4.5�   YELLOW POWDER COAT       48"      4½"     8" x 8"   29
                                          BOL-62-4.5    YELLOW POWDER COAT       62"      4½"     8" x 8"   39
                                          BOL-72-4.5    YELLOW POWDER COAT       72"      4½"     8" x 8"   49
                                          BOL-24-5.5�   YELLOW POWDER COAT       24"      5½"     8" x 8"   20
                                          BOL-36-5.5�   YELLOW POWDER COAT       36"      5½"     8" x 8"   26
                                          BOL-42-5.5�   YELLOW POWDER COAT       42"      5½"     8" x 8"   30
                                          BOL-48-5.5�   YELLOW POWDER COAT       48"      5½"     8" x 8"   35
                                          BOL-62-5.5    YELLOW POWDER COAT       62"      5½"     8" x 8"   45
                                          BOL-72-5.5    YELLOW POWDER COAT       72"      5½"     8" x 8"   55
                                                                                          5
                                          BOL-36-6.5    YELLOW POWDER COAT       36"      6 /8"   8" x 8"   30
                                          BOL-42-6.5    YELLOW POWDER COAT       42"      6 /8"   8" x 8"   49
                                                                                          5
                                                                                          5
                                          BOL-48-6.5    YELLOW POWDER COAT       48"      6 /8"   8" x 8"   51
                                          BOL-62-6.5    YELLOW POWDER COAT       62"      6 /8"   8" x 8"   61
                                                                                          5
                                          BOL-72-6.5    YELLOW POWDER COAT       72"      6 /8"   8" x 8"   71
                                                                                          5
                                          BOL-36-8.5    YELLOW POWDER COAT       36"      8 /8"  10" x 10"  53
                                                                                          5
                                          BOL-42-8.5    YELLOW POWDER COAT       42"      8 /8"  10" x 10"  62
                                                                                          5
                                          BOL-48-8.5    YELLOW POWDER COAT       48"      8 /8"  10" x 10"  126
                                                                                          5
                                          AS-383�       ANCHOR BOLTS FOR CONCRETE (1) 3/8" x 3" (1 3 /4" UNITS)  1
                                          AS-383-4PK�   ANCHOR BOLTS FOR CONCRETE (4) 3/8" x 3" (1 3 /4" UNITS)  4
                          model BOL-42-4.5  AS-344�     ANCHOR BOLTS FOR CONCRETE (1) 3/4" x 4" (OTHER UNITS)  1
                                          AS-344-4PK�   ANCHOR BOLTS FOR CONCRETE (4) 3/4" x 4" (OTHER UNITS)  4
