Page 16 - Protective Barriers
P. 16

264                             Fixed Height Bollards
       PROTECTIVE BARRIERS                  Surface mounted unit is easy to install.  Top mounted eyelets can be used with chains or  (POUND)



                                            rope to create a barrier.  UV resistant high visibility bright yellow baked-in powder-coated
                                            toughness.  Can be used in conjunction with our Fold Down Bollards, series PARK-P-FD.
                                            Reflective bands included.
                                                 MODEL
                                                                                                          WEIGHT
                                                                                             BOLLARD
                                                              DESCRIPTION
                                                 NUMBER
                                                                                             DIAMETER
                                                                               HEIGHT
                                                                                               2½"
                                                                                                            7
                                                              YELLOW
                                                                               35½"
                                             PARK-P-60�
                                                                                               3"
                                             PARK-P-76�
                                                                               35½"
                                                              YELLOW
                                             PARK-P-108�
                                             AS-383�
                                                               ANCHOR BOLTS FOR CONCRETE (1) 3/8" x 3"
                                                               ANCHOR BOLTS FOR CONCRETE (4) 3/8" x 3"
                                             AS-383-4PK�      YELLOW           35½"            4¼"          7 8 1 4
               model     model
             PARK-P-60  PARK-P-108
                                            Fold Down Bollards
                                            Ideal for vehicle access control.  These heavy duty bollards feature integrated locking and an easy
                                            to operate cam-lock.  Unit secures in both open and closed position via internal lock.  Two (2)
                                            keys included.  Anchors included for securing bollard to concrete.
                         model
                      PARK-P-108-FD         Two (2) wrap around reflectors adhere to the baked-in powder-coated toughness or stainless steel
                                            finish.  The anti-tamper design and cast steel covering foot is made in a mold, therefore there are
                                            no welds.  Can be used in conjunction with our Fixed Height Bollards shown above.
                                                   MODEL                        RAISED  COLLAPSED  BOLLARD  WEIGHT
                                                   NUMBER         DESCRIPTION   HEIGHT   HEIGHT  DIAMETER  (POUND)
                                             PARK-P-60-FD�         YELLOW        35½"     5"      2½"       7
                                             PARK-P-76-FD�         YELLOW        35½"     5"       3"      15
                                             PARK-P-108-FD�        YELLOW        35½"     5"      4¼"      25
                                             PARK-P-108-FD-SS�  STAINLESS STEEL  33½"     5"      4¼"      20
                          model              PARK-P-108-FD-KEY�         EXTRA SET OF TWO (2) KEYS           1
                      PARK-P-108-FD-SS
                                             AS-383�              ANCHOR BOLTS FOR CONCRETE (1) 3/8" x 3"   1
                                             AS-383-4PK�          ANCHOR BOLTS FOR CONCRETE (4) 3/8" x 3"   4
                                            Folding Bollards
                                            Folding steel barrier post for parking control and security. Bollard is locked in the raised position
                                            with a padlock (padlock not included). When padlock is removed, bollard may be lowered to
                                            ground to allow for access. Padlock hole diameter is 3/8". Base plate must be lagged to ground for
                                            proper installation (hardware not included). Steel construction. Baked-in yellow powder-coated
                                            toughness or galvanized finish.
                                                 MODEL                    RAISED    COLLAPSED  BOLLARD    WEIGHT
                              model BOL-FD-36-Y  NUMBER      DESCRIPTION  HEIGHT     HEIGHT    DIAMETER  (POUND)
                                                                                                 11
                                             BOL-FD-36-Y�    YELLOW        42"        4¼"       1 /16"     15
                                    CA Residents see  BOL-FD-36-G�  GALVANIZED  42"   4¼"       1 /16"     15
                                                                                                 11
                                  WARNING A, Pg. 459
                    model                    AS-383�           ANCHOR BOLTS FOR CONCRETE (1) 3/8" x 3"     1
                    BOL-FD-36-G              AS-383-4PK        ANCHOR BOLTS FOR CONCRETE (4) 3/8" x 3"     4
                                            Heavy Duty Parking Hoops

                                            Secure an individual parking place from unwanted trespassing.  Hinged parking hoop is
                                            constructed of cast steel with a UV resistant safety yellow baked-in powder-coated toughness on
                                            model PARK-P-38-S.  Model PARK-P-38-ZN is made of steel construction with zinc plating.
                                            In the horizontal position the parking hoop allows free passage for cars and pedestrians.  When
                                            engaged, the parking hoop is both a visual and safety barrier.  Stands on three (3) hinged legs
                                            for better stability and resistance.  Easy to operate.  Secures in both open and closed position via
                                            internal lock, two (2) keys included.  Reflective bands included.

                                                  MODEL                                         RAISED    WEIGHT
                                                  NUMBER                 MATERIAL               HEIGHT    (POUND)
                                             PARK-P-38-S�     STEEL POWDER COAT, 34" wide        18"       12
                                             PARK-P-38-ZN�    STEEL WITH ZINC PLATING, 34" wide  18"       12
                                             AS-383�          ANCHOR BOLTS FOR CONCRETE (1) 3/8" x 3"         1
                                             AS-383-4PK�      ANCHOR BOLTS FOR CONCRETE (4) 3/8" x 3"       4
                                     CA Residents see
            model PARK-P-38-S       WARNING A, Pg. 459
   11   12   13   14   15   16   17   18   19   20   21
