272                          Building Protective Column Pads
       PROTECTIVE BARRIERS  I-BEAM TYPE  SQUARE BEAM  Protect personnel from workplace injury.  Building Protective Column Pads are crafted to maximize



                                         protection with three (3) inches of high density foam to compress before any impact.  The outside
                                         wrap is superior nylon reinforced vinyl.  Square beam pads, series V-PAD-S, feature a nylon rope laced
                                         through brass grommets to secure the protector to a round or square column.  A pleat is folded over
                                         and sewn to increase the brass grommet strength.  Custom sizes available.
                                                                                       BLACK VINYL
                                                                                                     YELLOW VINYL
                                                                                                       MODEL
                                          OVERALL
                                                                COLUMN
                                                                             WEIGHT
                                                    COLUMN
                                                                                         MODEL
                                                                                                       NUMBER
                                                                                        NUMBER
                                           HEIGHT
                                                                 TYPE
                                                                              11
                                                     4"
                                            72"
                                                                                     V-PAD-I-65
                                                                                                   V-PAD-I-65-Y
                                                     5"
                                                                              14
                                            72"
                                                                I-BEAM
                                                                                                   V-PAD-I-66-Y
                                                                                     V-PAD-I-66
                                            72"      SIZE       I-BEAM      (POUND)  V-PAD-I-64    V-PAD-I-64-Y
                                                                I-BEAM
                                                                              17
                                                     6"
                                            72"      7"         I-BEAM        20     V-PAD-I-67    V-PAD-I-67-Y
                                            72"      8"         I-BEAM        23     V-PAD-I-68    V-PAD-I-68-Y
                                            72"      9"         I-BEAM        26     V-PAD-I-69    V-PAD-I-69-Y
                                            72"      10"        I-BEAM        29     V-PAD-I-610   V-PAD-I-610-Y
                                            72"      11"        I-BEAM        32     V-PAD-I-611   V-PAD-I-611-Y
                                            72"      12"        I-BEAM        35     V-PAD-I-612   V-PAD-I-612-Y
                                            72"     4" x 4"  ROUND/SQUARE     16     V-PAD-S-64    V-PAD-S-64-Y
                                            72"     5" x 5"  ROUND/SQUARE     19     V-PAD-S-65    V-PAD-S-65-Y
                                            72"     6" x 6"  ROUND/SQUARE     22     V-PAD-S-66    V-PAD-S-66-Y
                                            72"     7" x 7"  ROUND/SQUARE     25     V-PAD-S-67    V-PAD-S-67-Y
                                            72"     8" x 8"  ROUND/SQUARE     28     V-PAD-S-68    V-PAD-S-68-Y
                                            72"     9" x 9"  ROUND/SQUARE     31     V-PAD-S-69    V-PAD-S-69-Y
                                            72"    10" x 10"  ROUND/SQUARE    34     V-PAD-S-610   V-PAD-S-610-Y
                                            72"    11" x 11"  ROUND/SQUARE    37     V-PAD-S-611   V-PAD-S-611-Y
                                            72"    12" x 12"  ROUND/SQUARE    40     V-PAD-S-612   V-PAD-S-612-Y
                                            36"      4"         I-BEAM        6      V-PAD-I-34    V-PAD-I-34-Y
                                            36"      5"         I-BEAM        7      V-PAD-I-35    V-PAD-I-35-Y
                                            36"      6"         I-BEAM        9      V-PAD-I-36    V-PAD-I-36-Y
                                            36"      7"         I-BEAM        10     V-PAD-I-37    V-PAD-I-37-Y
                                            36"      8"         I-BEAM        12     V-PAD-I-38    V-PAD-I-38-Y
                                            36"      9"         I-BEAM        13     V-PAD-I-39    V-PAD-I-39-Y
                                            36"      10"        I-BEAM        15     V-PAD-I-310   V-PAD-I-310-Y
                                            36"      11"        I-BEAM        16     V-PAD-I-311   V-PAD-I-311-Y
            model                           36"      12"        I-BEAM        18     V-PAD-I-312   V-PAD-I-312-Y
            V-PAD-I-66-Y                    36"     4" x 4"  ROUND/SQUARE     8      V-PAD-S-34    V-PAD-S-34-Y
                                            36"     5" x 5"  ROUND/SQUARE     10     V-PAD-S-35    V-PAD-S-35-Y
                                            36"     6" x 6"  ROUND/SQUARE     11     V-PAD-S-36    V-PAD-S-36-Y
                                CA Residents see  36"  7" x 7"  ROUND/SQUARE  13     V-PAD-S-37    V-PAD-S-37-Y
                              WARNING A, Pg. 459
                                            36"     8" x 8"  ROUND/SQUARE     14     V-PAD-S-38    V-PAD-S-38-Y
                                            36"     9" x 9"  ROUND/SQUARE     16     V-PAD-S-39    V-PAD-S-39-Y
                                            36"    10" x 10"  ROUND/SQUARE    17     V-PAD-S-310   V-PAD-S-310-Y
                                            36"    11" x 11"  ROUND/SQUARE    19     V-PAD-S-311   V-PAD-S-311-Y
                                            36"    12" x 12"  ROUND/SQUARE    20     V-PAD-S-312   V-PAD-S-312-Y
                                         Building Column Protectors
                                         Provide wrap around protection to columns, pipes, and tubing to prevent damage. Constructed of UV
                                         protected polyethylene. Units can be stacked two (2) high. Easy to assemble with nylon fasteners included.
                                            MODEL        INSIDE      OUTSIDE   OVERALL      UNIFORM      WEIGHT
                                           NUMBER       OPENING       WIDTH    HEIGHT     CAPACITY (LBS)  (POUND)
                                          VB-6        6" SQUARE       24"       42"      7000 @ 6 MPH      48
                                          VB-8        8 /8" SQUARE    24"       42"      7000 @ 6 MPH      90
                                                       3
                                          VB-10      10 /8" SQUARE    24"       42"      7000 @ 6 MPH      92
                                                       3
                                          VB-12      12 /8" SQUARE    24"       42"      7000 @ 6 MPH      95
                                                       3
                                          VB-8-10     8" x 10" RECT.  24"       42"      7000 @ 6 MPH      48
                            model VB-8
                                          VB-9R        9" ROUND       24"       42"      7000 @ 6 MPH      95
                                         Polyethylene Ultra I-Beam Protector
                                         I-Beam Protector allows for installation on beams obstructed by walls or other structures.  Four (4)
                                         guard units completely cover I-Beam (units sold as each).  Install multiple units in a "stacked" mode
                                         for higher protection from scissor lifts, raised forklifts, and other high-reaching equipment.  Specially
                                         designed groove allows for quick and easy installation, no straps or fasteners required.
                                              MODEL             OVERALL SIZE                             WEIGHT
                                              NUMBER             (L x W x H)             COLOR           (POUND)
                                          IBEAM-GRD            7½" x 8½ x 42            YELLOW             8
                       model IBEAM-GRD
