          Fabric Hoppers

          These hoppers provide an economical and convenient means for storing and moving dry
          bulk commodities. The coated polypropylene has a polyester webbing for extra strength. The
          8 oz. white fabric is UV tested. Fold for easy storage when not in use. The four corner straps
          provide convenient forklift handling, while the bottom of the unit can be opened for simple
          release of products.

             MODEL       VOLUME      UNIFORM     BASE SIZE    OVERALL    WEIGHT                                    FORK TRUCK ATTACHMENTS
             NUMBER     CUBIC FEET   CAPACITY     (W x L)      HEIGHT   (POUND)
           FAB-H-45�      40         3,300 lb.   36" x 36"      45"       8
           FAB-H-55�      50         3,300 lb.   36" x 36"      55"       7
           FAB-H-63�      78         3,300 lb.   36" x 36"      63"       8




          Bulk Containers
          This rugged container maximizes shipping, handling, and storage efficiencies.  These units stack
          three high and safely accommodate up to 700-800 LB. of uniform solid, pourable, granular, and
          non-regulated material.  Molded nesting "lugs" or "ribs" prevent units from jamming together.  All
          are available in a wide variety of colors and with optional permanent, molded-in or raised graphics
          and logos.  Caster and custom options available, contact factory. Lid standard.
                 MODEL        VOLUME   UNIFORM   OVERALL SIZE            WEIGHT
                 NUMBER      CUBIC FEET  CAPACITY  (W x L x H)  COLOR    (POUND)
           MHBC-3244-CB        27.5    700 lb.  45" x 45" x 33"  BLUE     95          SHOWN WITH
           MHBC-3244-JG        27.5    700 lb.  45" x 45" x 33"  GREEN    95          OPTIONAL CASTERS
           MHBC-3244-O         27.5    700 lb.  45" x 45" x 33"  ORANGE   95
           MHBC-3244-R         27.5    700 lb.  45" x 45" x 33"  RED      95
           MHBC-4444-CB         35     800 lb.  45" x 45" x 45½"  BLUE    120
           MHBC-4444-JG         35     800 lb.  45" x 45" x 45½"  GREEN   120
           MHBC-4444-O          35     800 lb.  45" x 45" x 45½"  ORANGE  120
           MHBC-4444-R          35     800 lb.  45" x 45" x 45½"  RED     120
           MHBC-3244-5C-CB*    27.5    700 lb.  45" x 45" x 39"  BLUE     105
           MHBC-3244-5C-JG*    27.5    700 lb.  45" x 45" x 39"  GREEN    105
           MHBC-3244-5C-O*     27.5    700 lb.  45" x 45" x 39"  ORANGE   105
           MHBC-3244-5C-R*     27.5    700 lb.  45" x 45" x 39"  RED      105
           MHBC-4444-5C-CB*     35     800 lb.  45" x 45" x 51½"  BLUE    120
           MHBC-4444-5C-JG*     35     800 lb.  45" x 45" x 51½"  GREEN   120
           MHBC-4444-5C-O*      35     800 lb.  45" x 45" x 51½"  ORANGE  120
           MHBC-4444-5C-R*      35     800 lb.  45" x 45" x 51½"  RED     120
          * 5" ALL SWIVEL CASTERS INCLUDED




          Battery Powered Trash Can Dumper and Container

           (1) ONE 12V DC POWER STANDARD
          One person with a fork truck can safely and easily dump drums into a hopper. DC
          powered operation with on-board battery charger. Raise time is 10 seconds and
          lowered time is 8 seconds.  Dump height is 55¾". A 2 cubic yard Vestil “D” style
          hopper is available separately to collect trash.  Custom configurations can be made for
          most trash containers.
                                                                                                 model T-HOP
             MODEL                     OVERALL SIZE    UNIFORM    WEIGHT                         shown with D-200-LD
             NUMBER    DESCRIPTION      (W x L x H)    CAPACITY  (POUND)
           T-HOP        DUMPER     38 /16" x 103½" x 60 /16"  400 lb.  732
                                                 7
                                     5
                                                 13
                                    11
                                           5
           D-200-LD�    HOPPER     56 /16" x 68 /16" x 51 /16"  2,000 lb.  613
