          Wall-Mounted Strapping Dispenser

          This unique Wall-Mounted Strapping Dispenser is for use with steel and poly strapping.  The
          mounting bracket pivots to allow for use in any direction.  The unit also pivots up to 180° to allow
          for easier loading of new strapping coils.  Works with strapping core sizes of 16" x 3", 16" x 6" and
          8" x 8".available on page 168.
                MODEL             OVERALL SIZE           ACCEPTABLE      WEIGHT                                    PACKAGING EQUIPMENT
               NUMBER              (W x D x H)           STRAPPING       (POUND)                   model STRAP-WALL
           STRAP-WALL          29½" x 10¾" x 30 /8"    STEEL & POLY       125
          Semi-Automatic Pallet Probe Strapping Machine             115V 1-PHASE STANDARD

          • User Friendly          • 40" Foldable Pallet Probe
          • Tension up to 175 pound   • Uses 3/8", 1/2", and 5/8" Poly Strapping
          The Semi-Automatic Pallet Probe Strapping Machine eliminates hand strapping and speeds up
          the process of pallet strapping. This Strapping Machine is user friendly and automatically feeds
          the desired polypropylene strap through the pallet, tightens, and seals the strap around the pallet.   model DBA-130
          The pallet strapping process is as follows: (1) unfold pallet probe, (2) push pallet probe into pallet,
          (3) feed polypropylene strap, (4) insert tip of strap into strap way, (5) adjust tension by pulling
          automatically into heat seal, (6) strip is then cut off to feed the strap out, (7) one-cycle automatically
          complete, (8) remove machine and insert into next pallet. Polypropylene strapping available
          separately on page 168.
              MODEL          OVERALL SIZE     FEED STRAP     TENSION     WEIGHT
              NUMBER          (W x D x H)       HEIGHT       (POUND)     (POUND)
           DBA-130�        31½" x 23" x 55"     53½"         175 lb.      393

          Semi-Automatic Strapping Machine           115V 1-PHASE STANDARD
          • Minimize Packaging Time    • Secure Contents Effectively
          • User Friendly Controls     • Stainless Steel Strapping Surface
          • Portable for Convenience   • Easy Access for Reloading Strapping
          The fully portable strapping machine dispenses, tightens, and seals economical
          polypropylene strapping around packages or bundles. This Strapping Machine
          automatically tensions strap and joins the ends with a secure heat weld for content security. The
          unit features a stainless steel strapping surface and easy access for reloading strapping. The motor
          automatically switches off when not in use. As the strap is inserted, the motor automatically restarts.
          Strap tension is adjustable 11 to 140 pounds.  Strapping core size is diameter/width (in.) 8" x 8" or
          9" x 8".  Polypropylene strapping available separately on page 168.

             MODEL          OVERALL       STRAPPING   POWER     CASTER    WEIGHT
            NUMBER         DIMENSIONS       WIDTH     SUPPLY     SIZE     (POUND)                model S-2001
           S-2001�     23"W x 35½"L x 30"H  3 /8" & ½"  115V    3" x 1¼"   268

          High Speed Strapping Machine            115V 1-PHASE STANDARD

          • Dispenses 3/8" or 1/2" polypropylene strapping   • Automatic strapping operation
          • Heat welds polypropylene strapping    • Up to 30 cycles per minute
          • Strap tension is adjustable 15 to 150 pounds   • User friendly controls
          • Strapping core size is 6" to 8"       • Easy access for reloading strapping
          The High Speed Strapping Machine is a productive solution to most polypropylene
          strapping tasks. The automatic Arch Strapping Machine features the "Auto-Feeding"
          function that automatically feeds polypropylene strapping to arch and is ready for each
          application. The "Auto-Positioning" system automatically positions and secures the   model ASM-3123
          polypropylene strapping efficiently for each cycle.
          The "Jam-Free" feature ejects missed strap cycles and resets the unit. The user friendly controls allow
          the operator to choose between panel mounted controls, foot pedal, or table top ball switch. Actual
          production will vary depending on package size, chute size, and operator dexterity. The unit has heat
          welded polypropylene strapping, easy access for reloading strapping, and portability for convenience.
          Polypropylene strapping available separately on page 168.

              NUMBER         SIZE (W x H)    HEIGHT       (W x D x H)    (POUND)
           ASM-3123         29¼" x 22½"      31½"      48 /8" x 23 /8" x 58"  531
