Page 10 - Packaging Equipment
P. 10

162                           Electronic Digital Floor Scales      115V 1-PHASE STANDARD
       PACKAGING EQUIPMENT   SCALE HEAD   rugged design has a tread plate top surface. Customer is responsible for contacting the local Weights


                                          These scales have a low profile, allowing easy loading and unloading of heavy equipment. The
                                          and Measures Department or a state certified scale dealer before putting Legal for Trade (NTEP)
                                          scale into service for certification and is responsible for re-certification as required by local codes by
                                          certified personnel.  Indexing accuracy is +/- 0.1% of applied load or 1 division.  The digital display
                                          stand is adjustable to 42" high and powered by four (4) C cell batteries (included) or 115V, 1-phase
                                          AC power, cord included.  Optional Approach Ramp for pallet truck accessibility - order two (2) for
                                          drive-on, drive-off convenience. Color may vary.
                                                                                              UNIFORM
                                                                                                          WEIGHT
                                                  MODEL
                                                                               OVERALL SIZE
                                                                                (W x L x H)
                                                  NUMBER
                                                                                              CAPACITY
                                                                   SCALE
                                                                                                           323
                         model             LEGAL FOR TRADE (NTEP)  DESCRIPTION  48" x 48" x 4"  5,000 lb.  (POUND)
                                           SCALE-S-CFT-44-5K�
                     SCALE-S-CFT-44-5K                             SCALE      60" x 60" x 4"  5,000 lb.    492
                                           SCALE-S-CFT-55-5K�
                                           SCALE-S-CFT-44-10K�     SCALE      48" x 48" x 4"  10,000 lb.   373
                                           SCALE-S-CFT-55-10K�     SCALE      60" x 60" x 4"  10,000 lb.   471
                                           SCALE OPTIONS
                                           SCALE-R-CS-44�          RAMP       48" x 48" x 3½"  10,000 lb.  272
                                           SCALE-R-CS-54�          RAMP       60" x 48" x 3½"  10,000 lb.  272
                                           SCALE-S-CFT-PRINTER               DIGITAL PRINTER                3
                                           SCALE-S-PAPER�          THERMAL ROLL PRINTER PAPER (10 ROLLS)    5
             STORAGE COMPARTMENT
                                          "U" Shaped Platform Scales         115V 1-PHASE STANDARD
                                          Constructed of heavy-duty steel to withstand the most demanding industrial environments, this
                                          scale is designed to handle pallets and is easy to move and store.  Ideal for moving around the work
                                          place where there is not enough room for a fixed scale.  Scale is suitable for weighing in a warehouse,
                                          storehouse, or general use.  The scale is light weight and can be easily moved by one person with
                                          its two (2) wheels and handle. The scale comes equipped with four (4) heavy duty load cells and a
                                          deluxe indicator head.  The mobile digital display stand is adjustable to 42" high and powered by six
                                          (6) AA batteries or 115V, 1-phase AC power, cord included.  Individual sides are 5" wide. Accuracy
                                          is +/- 0.1% of the applied load.
                                             MODEL       UNIFORM        OVERALL SIZE     ACCURACY OF     WEIGHT
                                             NUMBER      CAPACITY        (W x L x H)     APPLIED LOAD   (POUND)
                                           VPU-1�       1,000 lb.     48" x 56" x 4¾"    +/- 0.1%         176
                                           VPU-2�       2,000 lb.     48" x 56" x 4¾"    +/- 0.1%         176
                                           VPU-4�       4,000 lb.     48" x 56" x 4¾"    +/- 0.1%         176
                                           VPU-6�       6,000 lb.     48" x 56" x 4¾"    +/- 0.1%         176

                                          Portable Floor Scales     115V 1-PHASE STANDARD
                                          Portable Floor Scales are ideal for easy transportation and weighing of goods at multiple locations.
                                          The scale has a non-slip diamond plate surface. Fold Down low gradual ramps are fixed to the
                                          platform. Ramps make the scale ideal for wheeling pallet trucks, dollies, carts, and containers on and
                                          off the platform. Four (4) alloy steel load cells and deluxe scale indicator head.  Display powered by
                                          six (6) AA batteries or 115V, 1-phase AC power, cord included.  Indexing accuracy is 1.1 pound.

                                                                                          OVERALL SIZE
                                             MODEL        UNIFORM       PLATFORM SIZE     WITH SLOPES     WEIGHT
                                             NUMBER      CAPACITY         (W x L)          (W x L x H)   (POUND)
                                                                                                  3
                                           VPFS-3B�      3,000 lb.      47¾" x 39½"    60" x 78¾" x 2 /8"  460
                                                                                                  3
                                           VPFS-3C�      3,000 lb.       59" x 59"     71" x 98½" x 2 /8"  716
                                          Low Profile Scales & Ramps        115V 1-PHASE STANDARD
                                          Low Profile air freight (pancake) scales come standard with wrap-around ramps. Units feature ½" deck
                                          plate, grid core, and a ⅜" bottom skin with three (3) center supports to prevent sagging. Suspension
                                          consists of fully electronic load cells on shock absorbing spherical washers. Ramps are constructed of
                                          heavy duty diamond plate with a 10° or 20% slope. Indexing accuracy is +/- 0.1% of applied load or 1
                                          division.  The digital display stands 42" high and is 115V, 1-phase AC power, cord included.
                                                 MODEL              UNIFORM            PLATFORM SIZE     WEIGHT
                                                 NUMBER             CAPACITY            (W x L x H)     (POUND)
                                           SCALE-LP-44-5K          5,000 lb.          48" x 48" x 3"      185
                                           SCALE-LP-44-10K         10,000 lb.         48" x 48" x 3"      242
                                           SCALE-LP-44-20K         20,000 lb.         48" x 48" x 3"      430
   5   6   7   8   9   10   11   12   13   14   15
