          Medium Duty Powered Stretch Wrap Machines                                 115V 1-PHASE STANDARD / OPTIONS BELOW

          Our Medium Duty Powered Stretch Wrap Machines offer the same great features
          as our standard duty machines in a 5,000 pound capacity unit.  Complete with
          a powered turntable (RPM is variable from 3 to 12) and counter-balanced
          stretch film mast. To operate, depress the foot pedal and manually move the
          mast up and down. The film-wrap tension is controlled with an adjustable,                                PACKAGING EQUIPMENT
          friction-brake assembly. Film placement is controlled manually by moving the
          carriage assembly up and down on the vertical mast. A hand operated carriage-  model SWA-54
          brake allows the carriage to move freely making film application fast and easy.
          The system will accept 10 (in.) to 20 (in.) material. The unit ships with mast
          disconnected-simply raise mast and clamp into place.
          The standard manual film wrap delivery can be upgraded to 115V, 1-phase
          AC powered mast option (PMO). The hand held control is used to raise/lower
          the film, while the foot control is used to operate the turntable. Please contact
          factory for Approach Ramp options on these models.

                 MODEL          TURNTABLE      TURNTABLE      UNIFORM     MAXIMUM LOAD   MAXIMUM WRAP   WEIGHT
                 NUMBER          DIAMETER       HEIGHT        CAPACITY      DIAMETER       HEIGHT*     (POUND)
           SWA-54                  54"          11 /16"      5,000 lb.        90"           80"         1305
                                                  1
           SWA-60                  60"          11 /16"      5,000 lb.        90"           80"         1393
                                                  1
           ACCESSORIES & OPTIONS
           SWA-5460-PMO      POWERED MAST OPTION (54" & 60" DIAMETER) - FACTORY INSTALLED               144
           SWA-5460-PMO-RF   115V POWERED MAST OPTION (RETROFIT - FIELD INSTALLED)                      194
           SWA-54-SCALE      DIGITAL SCALE OPTION FOR SWA-54 (ADDS 3½" TO TURNTABLE HEIGHT - FACTORY INSTALLED)  838
           SWA-60-SCALE      DIGITAL SCALE OPTION FOR SWA-60 (ADDS 3½" TO TURNTABLE HEIGHT - FACTORY INSTALLED)  838
           SWA-COUNT         COUNTER OPTION, KEEP TRACK OF CAROUSEL ROTATIONS                            1
           SWA-NRTL-COMP     UL APPROVED COMPONENTS                                                      --
           SWA-INDEX         AUTO-INDEXING 90°, 120°, OR 180°                                            1
           SWA-NM            SWA WITH NO MAST                                                           100
          *BASED ON 20" HIGH ROLL OF STRETCH WRAP MATERIAL



          Powered Stretch Wrap Machines          115V 1-PHASE STANDARD / OPTIONS BELOW

          Increase productivity in the shipping department or at the end of a production line. These
          units come complete with a 48" diameter powered turntable and counter-balanced stretch
          film mast. Easy to operate, simply depress the foot pedal and manually move the mast
          up and down. Powered by a 115V, 1/2 HP motor with soft start/stop and variable speed
          control. Variable R.P.M. 3-12. Units come with one film rod with special spacers that can
          be used with any height roll of stretch wrap material between 10" and 20". Ships with   model SWA-48
          mast knock-down. Some assembly required.
          The Approach Ramp option allows the operator to load and unload the machine with a
          pallet truck (model SWA-48 only).
          SWA-48-PMO is the SWA-48 with a powered mast. Comes with a 24V hand control to
          work with those taller loads. The hand held control is used to raise/lower the film while
          the foot control is used to operate the turntable.



                 MODEL          TURNTABLE     TURNTABLE  UNIFORM CAPACITY  MAXIMUM LOAD DIAM-  MAXIMUM WRAP  WEIGHT
                 NUMBER          DIAMETER      HEIGHT       (POUNDS)         ETER          HEIGHT      (POUND)
           SWA-48                 48"           2 /8"        4,000           62"           83¾"         594
                                                 3
                                                 3
           SWA-48-PMO             48"           2 /8"        4,000           62"           83¾"         619
           ACCESSORIES & OPTIONS
           SWA-PMO-RF        115V POWERED MAST OPTION (RETROFIT - FIELD INSTALLED)                      194
           SWA-SCALE         DIGITALE SCALE OPTION (AVAILABLE ONLY ON SWA-48 & ADDS 3½" TO HEIGHT - FACTORY INSTALLED)  339
           SWA-VCC-208/230-1  VOLTAGE CHANGE TO 208/230 VOLT, SINGLE (1) PHASE                           --
           SWA-VCC-208/230-3  VOLTAGE CHANGE TO 208/230 VOLT, THREE (3) PHASE                            --
           SWA-VCC-460-3     VOLTAGE CHANGE TO 460 VOLT, THREE (3) PHASE                                 --
           SWA-R-4836        48"W x 36"L x 2"H APPROACH RAMP (FOR ELECTRIC PALLET TRUCKS)*              170
           SWA-R-4848        48"W x 48"L x 2"H APPROACH RAMP (FOR MANUAL PALLET TRUCKS)*                212
           SWA-R-48100-SCL   48"W x 100"L x 6"H APPROACH RAMP (FOR SWA-48 WITH SCALE) (ELECTRIC & MANUAL PALLET TRUCKS)   600
           SWA-COUNT         COUNTER OPTION, KEEP TRACK OF CAROUSEL ROTATION                             1
           SWA-NRTL-COMP     INCLUDES COMPONENTS APPROVED BY A NATIONALLY-RECOGNIZED TESTING LAB (NRTL)  --
           SWA-INDEX         AUTO-INDEXING 90°, 120°, OR 180°                                            1
           SWA-FILM          20"W x 80 ga. x 6,000' x 3" CORE (ONE ROLL)                                 42
