          Stainless Steel Manual Carousels

          The Manual Carousels rotate materials with the assistance of an operator. Now loading and
          unloading operations can be done more efficiently; minimizing fatigue and risk of back injury. The
          carousel may be added to an existing work bench, scissor table, or placed on the floor. Constructed
                                        3
          of two (2) pieces of rolled structural angle ( /16"" thick). A series of sealed ball bearings transfer the
          load smoothly and evenly to the supporting surface. Guide rollers keep the rings aligned.                PACKAGING EQUIPMENT
              MODEL       OUTER     UNIFORM     OVERALL      SHIPS      WEIGHT
             NUMBER     DIAMETER   CAPACITY (LB.)  HEIGHT     VIA      (POUND)
           CA-40-2-SS     40"        2,000        2"         UPS         47
           CA-40-4-SS     40"        4,000        2"         UPS         49
           CA-40-6-SS     40"        6,000        2"         UPS         51


          Heavy-Duty Manual Turntables
          Heavy-Duty Manual Turntables maximize workspace and minimize wasteful motion.
          Bench top turntables allow workers to stay in one position and rotate items for access
          from all sides. No need to walk around the table to access areas out of view. Easy and
          smooth bearing motion. Used in hundreds of applications: displays, paint spraying,
          assembly units, repairs, etc. Easy, smooth rotation won't jostle delicate parts. Rugged   TYPE A  TYPE B
          5 /16" steel plate construction. The double tier units feature a stationary shelf for storing
          parts and tools.













                 TYPE C          TYPE D             TYPE E             TYPE F                TYPE G
                      MODEL                        HEIGHT       DOUBLE        HEIGHT       UNIFORM     WEIGHT
            TYPE      NUMBER        DIAMETER       RANGE         TIER       ADJUSTMENT     CAPACITY    (POUND)
             A   TT-8-7/8�             8"           ¾"            NO          N/A           500 lb.      10
             A   TT-12-7/8�           12"           13 /16"       NO          N/A           500 lb.      20
             A   TT-18-7/8�           18"           13 /16"       NO          N/A         1,000 lb.      41
             A   TT-24-7/8�           24"           13 /16"       NO          N/A         1,000 lb.      70
             A   TT-30-7/8�           30"           13 /16"       NO          N/A         1,000 lb.     134
             B   TT-8-4�               8"          3 /16"         NO          N/A           500 lb.      12
                                                    15
             B   TT-12-4�             12"           3⅞"           NO          N/A           500 lb.      22
             B   TT-18-4              18"          3 /16"         NO          N/A           500 lb.      70
                                                    7
             B   TT-N-24-4            24"          3 /16"         NO          N/A           500 lb.     150
                                                    11
             B   TT-N-30-4            30"          3 /16"         NO          N/A           500 lb.     191
                                                    11
                                                   15
             C   TT-18-PED�           18"        20 /16" TO       NO       TURN KNOB        300 lb.      55
                                                   31 /16"
                                                     15
                                                 20 /16" TO
                                                   15
             C   TT-N-24-PED          24"          31 /16"        NO       TURN KNOB        300 lb.     113
                                                     15
                                                   15
             D   TT-18-DPED           18"        23 /16" TO      YES       TURN KNOB        300 lb.     114
                                                   34 /16"
                                                     15
             D   TT-N-24-DPED         24"        24" TO 35"      YES       TURN KNOB        300 lb.     164
                                                 22 /16" TO
                                                   15
             D   TT-N-30-DPED         30"                        YES       TURN KNOB        300 lb.     206
                                                   33 /16"
                                                     15
             E   TT-18-CPED           18"      21 /16" TO 31 /16"  NO     GAS CYLINDER      300 lb.      91
                                                         1
                                                 1
             E   TT-N-24-CPED         24"      21 /16" TO 31 /16"  NO     GAS CYLINDER      300 lb.     148
                                                         5
                                                 5
             F   TT-18-CDPED          18"      23 /16" TO 33 /16"  YES    GAS CYLINDER      300 lb.     112
                                                         7
                                                 7
                                                 23 /16" TO
                                                   11
             F   TT-N-24-CDPED        24"          33 /16"       YES      GAS CYLINDER      300 lb.     169
                                                     11
                                                   11
             G   TT-N-30-PED�         30"        20 /16" TO       NO       TURN KNOB        300 lb.     185
                                                   31 /16"
                                                     11
