Page 9 - Packaging Equipment
P. 9

161
          Bench Scales - Legal for Trade (NTEP)                                               model
                                                                                      BS-915BT-2424-100
          Designed for speed, accuracy, and high usage. Ideal for busy shipping docks, outdoor markets, and
          food processing. Mild steel platform, interlocking 304 stainless steel tray for easy cleaning. Adjustable
          tilt display for convenient viewing angles. Rechargeable battery and AC adapter. Aluminum   New
          environmentally sealed single point load cell. Adjustable feet provides exceptional traction. Removable
          column for indicator to work up to 4ft from the base. International protection IP65. Weight and          PACKAGING EQUIPMENT
          count. Connection port RS-232 rating. LCD display (lbs, kgs, ounces, and grams).

                  MODEL        PLATFORM SIZE                 OVERALL SIZE  WEIGHT
                 NUMBER           (W x L)  CAPACITY x READABILITY  (W x L x H)  (POUND)
           BS-915-1212-100      12" x 12"   100 lb. x 0.2 lb  12" x 16" x 17"  25          model
           BS-915-1214-150      12" x 14"   150 lb. x 0.2 lb  14" x 18" x 17"  26          BS-915RT-2424-100
           BS-915-1616-300      16" x 16"   300 lb. x 0.5 lb  16" x 20" x 26"  34
           BS-915-1620-400      16" x 20"   400 lb. x 0.5 lb  16" x 24" x 26"  40
           BS-915-1818-400      18" x 18"   400 lb. x 0.5 lb  18" x 22" x 26"  42
           BS-915-1824-500      18" x 24"   500 lb. x 0.1 lb  18" x 28" x 33"  66
           BS-915-2020-500      20" x 20"   500 lb. x 0.1 lb  20" x 24" x 33"  64
           BS-915-2424-500      24" x 24"   500 lb. x 0.1 lb  24" x 28" x 33"  72
           BS-915-2424-1000     24" x 24"   1000 lb. x 0.2 lb  24" x 28" x 33"  72
           BS-915BT-2424-1000*  24" x 24"   1000 lb. x 0.2 lb  24" x 28" x 33"  74
           BS-915RT-2424-1000**  24" x 24"  1000 lb. x 0.2 lb  24" x 28" x 33"  76             model
          *BT (BALL TRANSFER TOP)                                                        BS-915-1212-100
          **RT (ROLLER TOP)


          Portable Bench Scale - Legal for Trade (NTEP)
          Convenient portable weighing platform. Easily move in and out of work areas. Swivel wheels &   New
          backrest for portability. High accuracy single point strain gauge aluminum load cell. Weight and
          count.  LCD display (lbs, kgs, ounces, and grams).
          BS-915BW-1824-500 - Carbon steel platform and stainless steel cover. International protection IP65.
          BS-915SSBW-2424-500 - All 304 stainless steel construction. Nema 4x/IP68 rated.


                  MODEL         PLATFORM SIZE                 OVERALL SIZE  WEIGHT
                  NUMBER          (W x L x H)  CAPACITY x READABILITY  (W x L x H)  (POUND)
                                 18" x 24" x                  18" x 28" x
           BS-915BW-1824-500       8½"        500 lb. x 0.1 lb   33"        94
                                 24" x 24" x                  24" x 28" x                                  model
           BS-915SSBW-2424-500*               500 lb. x 0.1 lb              97                    BS-915SSBW-2424-500
                                   8½"                           33"
          *ALL STAINLESS STEEL WASH-DOWN IP67 RATED WITH STAINLESS STEEL WHEELS & BACKRAIL

          Stainless Steel Bench Scales - Legal for Trade (NTEP)                    New
          Designed for hostile environments and washdown applications. 200% overload protection.
          Heavy duty tough panel. Rechargeable battery and AC adapter. All 304 stainless steel   model
          construction. Nema 4x/IP68 rated. Features include weighing, accumulation, tare, pre-tare,   BS-915SS-1818-400
          counting, peak and hold, and data output to PC.

                  MODEL        PLATFORM SIZE                 OVERALL SIZE  WEIGHT
                 NUMBER           (W x L)  CAPACITY x READABILITY  (W x L x H)  (POUND)
           BS-915SS-1212-100     12" x 12"   100 lb. x 0.2 lb  12" x 16" x 17"  31
           BS-915SS-1214-150     12" x 14"   150 lb. x 0.2 lb  14" x 18" x 17"  33
           BS-915SS-1616-300     16" x 16"   300 lb. x 0.5 lb  16" x 20" x 26"  42
           BS-915SS-1620-400     16" x 20"   400 lb. x 0.5 lb  16" x 24" x 26"  49
           BS-915SS-1818-400     18" x 18"   400 lb. x 0.5 lb  18" x 22" x 26"  49
           BS-915SS-1824-500     18" x 24"   500 lb. x 0.1 lb  18" x 28" x 33"  68
           BS-915SS-2020-500     20" x 20"   500 lb. x 0.1 lb  20" x 24" x 33"  68
           BS-915SS-2424-500     24" x 24"   500 lb. x 0.1 lb  24" x 28" x 33"  88
           BS-915SS-2424-1000    24" x 24"   1000 lb. x 0.2 lb  24" x 28" x 33"  89
           BS-915SS-EPD                 EXPLOSION PROOF DISPLAY             6
   4   5   6   7   8   9   10   11   12   13   14
