       LOADING DOCK EQUIPMENT  STEEL YARD RAMP OPTIONS model YR-HL   TOW BAR HITCH  TOW BAR POCKET  PICK-UP SLOTS  NON-REMOVABLE  GALVANIZED GUARD RAIL
            Options for Yard Ramps
                                                                                                        CA Residents see






                                                                          FORK LIFT
             27" PNEUMATIC TIRES
                           HYDRAULIC HAND PUMP
                                                           model YR-TB-P
                                            model YR-TB-H
                                                                                                       series YR-GR
                                                                                       STEEL HANDRAIL
                                                                          model YR-FS
                                                                                       model YR-HDRL
                MODEL
                                                                                                          WEIGHT
                NUMBER
                                                            DESCRIPTION
                                                                                                          (POUND)
             YR-HL
             YR-HL-DC*
                                                                                                           288
                         PNEUMATIC TIRE & 12V DC HYDRAULIC LIFT (5 MPH MAX. TOW SPEED) (NOT AVAILABLE ON YRD MODELS)
             YR-FS
                         FORK LIFT PICKUP SLOTS (7½"W X 2½"H USABLE ON 24" CENTERS)
                                                                                                           460
             YR-TB-H
                                                                                                           145
                         TOW BAR HITCH
             YR-TB-P     PNEUMATIC TIRE & HAND PUMP HYDRAULIC LIFT (5 MPH MAX. TOW SPEED) (NOT AVAILABLE ON YRD MODELS)  230
                                                                                                           35
                         TOW BAR POCKET (REPLACEMENT)
             YR-GR-30    12" HIGH GUARD RAIL OPTION FOR 30 FEET RAMPS (BOTH SIDES)                         456
             YR-GR-36    12" HIGH GUARD RAIL OPTION FOR 36 FEET RAMPS (BOTH SIDES)                         550
             YR-HDRL     NON-REMOVABLE 42" HIGH STEEL HANDRAIL WITH 21" MIDRAIL (WELDED)                  9/FT.
             YR-RHDRL    REMOVABLE 42" HIGH STEEL HANDRAIL WITH 21" MIDRAIL                               9/FT.
             YR-RAHDRL   REMOVABLE 42" HIGH ALUMINUM HANDRAIL WITH 21" MIDRAIL                            3/FT.
             YR-DH       HOLES IN LIP TO LAG RAMP TO TOP OF DOCK                                            --
            *INCLUDES ON-BOARD CHARGER
             PNEUMATIC TIRES OPTION  TOW BAR POCKET      TOW BAR HITCH            HAND PUMP
            Service Range will be 40" to 66"  model AYR-TB-P  model AYR-TB-H  HYDRAULIC LIFT STANDARD
                model AY-PNTR
             ALUMINUM YARD RAMP OPTIONS
                MODEL                                                                                    WEIGHT
                NUMBER                                      DESCRIPTION                                  (POUND)
             AYR-HL-DC   12V DC HYDRAULIC LIFT (INCLUDES ON-BOARD CHARGER)                                 50
             AYR-TB-H    TOW BAR HITCH                                                                    145
             AYR-TB-P    TOW BAR POCKET (REPLACEMENT)                                                      35
             AYR-GR-30   12" HIGH GUARD RAIL OPTION FOR 30 FEET RAMPS                                     456
             AYR-GR-36   12" HIGH GUARD RAIL OPTION FOR 36 FEET RAMPS                                     550
             AY-AHDRL    NON-REMOVABLE 42" HIGH ALUMINUM HANDRAIL WITH 21" MIDRAIL (WELDED) (SOLD PER FOOT)  3/FT.
             AY-RHDRL    REMOVABLE 42" HIGH ALUMINUM HANDRAIL WITH 21" MIDRAIL (SOLD PER FOOT)           18/FT.
             AY-RAHDRL   REMOVABLE 42" HIGH STEEL HANDRAIL WITH 21" MIDRAIL (SOLD PER FOOT)              18/FT.
             AYR-CRB6    6" CURB HEIGHT                                                                    --
             AYR-YEL     YELLOW SAFETY CURBS                                                               --
             AY-PNTR     20½" x 8" PNEUMATIC TIRE OPTION                                                   --
             AYR-DH      HOLES IN LIP TO LAG RAMP TO TOP OF DOCK                                           --
             SY-CRB6     6" CURB HEIGHT                                                                    --
             SY-YEL      YELLOW SAFETY CURBS                                                               --
             SY-PNTR     20½" x 8" PNEUMATIC TIRE OPTION                                                   --


                                          Steel Railroad Dockboards

                                          •  Auto Drop Locks (add 13" to overall width)   •  Pop-up Fork Lift Loops
                                          •  Steel Rectangular Board   •  Overlap Style Plate (both ends)
                                          •  Safety Curbs are 4" High   •  Tread plate for Better Traction
                                          •  Structural Steel Support Beams
             DOCK
             EDGE                         Steel Railroad Dockboards have a rectangular-style with a deck that is made of high-strength
                                          raised diamond steel treadplate with structural steel support beams for high strength cross
                   C
                       B                  traffic. Treadplate provides increased traction; overlap-style lip on both dock and rail car ends
                                          gives maximum versatility. Fork truck pop-up loops are built into deck - automatically pop-up
                 A
                                          when board is set on floor. Automatic drop-locks on both sides of board are designed to keep
                                          the board in place between dock and rail car.  Non-returnable.  Contact factory for pricing.
