High-Temp Phenolic Casters

- - - -

Description
Model Chart
PDF's
Image Gallery
Click Image to Enlarge

model: no-ima



Featured Casters & Wheels


TPR - Thermoplastic Rubber (DK) Casters
Foam Filled Wheel
Upgraded Glass Filled Nylon, Light Duty (RX) Casters
High Capacity Non-Marking Glass Filled Nylon Casters
Foam Filled Wheel
Polypropylene Wheel
Rubber (DK - Conductive) Casters
High Quality Non-Marking Polyurethane-Elastomer (blue)
Hard Rubber Wheel
model chart

Product Family Overview

Print Friendly
High-Temp Phenolic Casters
SERIES: CST-VE-HI-PH

High-temperature phenolic casters are great for high temperature applications that most casters cannot handle. Our high temp casters can handle up to 475 degree F during continuous use and 525 degrees F with intermittent use. Also available in stainless steel. Please contact the factory for more options.

  • High temperature rating - up to 525 degrees intermittent use
  • Resistant to most chemicals, salts, and steam
  • Anti-corrosive & rust resistant zinc plated finish
  • Roller bearing

High-temperature phenolic casters are great for high temperature applications that most casters cannot handle. Our high temp casters can handle up to 475 degree F during continuous use and 525 degrees F with intermittent use. Also available in stainless steel. Please contact the factory for more options.

  • High temperature rating - up to 525 degrees intermittent use
  • Resistant to most chemicals, salts, and steam
  • Anti-corrosive & rust resistant zinc plated finish
  • Roller bearing

Other "Go-To" Casters

 Polyurethane Casters Flat-Free (Foam-Filled) Casters Polyurethane (SI - Electrostatic Dissipating) Casters Polyurethane (SI) Casters

How To Order
Share:

Model Specific Details



All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
The Search Box below is for Casters within the Model Chart on this page. Not an entire site search.
Model Image PDFs Caster
Size		 Type Capacity
(lbs.)		 Overall
Height		 Top Plate
Size		 Net Wt.
(lbs)
CST-VE-3X1HI-PH-R 1 YEAR Limited Warranty3 x 1-1/4RIGID2004 4 x 4-1/20.99
CST-VE-4X1HI-PH-R 1 YEAR Limited Warranty4 x 1-1/4RIGID2005-1/2 4 x 4-1/23.37
CST-VE-5X2HI-PH-R 1 YEAR Limited Warranty5 x 2RIGID7506.5 4 x 4-1/23.98
CST-VE-6X2HI-PH-R 1 YEAR Limited Warranty6 x 2RIGID9007-1/2 4 x 4-1/24.74
CST-VE-8X2HI-PH-R 1 YEAR Limited Warranty8 x 2RIGID11009-1/2 4 x 4-1/26.26
CST-VE-3X1HI-PH-S 1 YEAR Limited Warranty3 x 1-1/4SWIVEL2004 4 x 4-1/21.58
CST-VE-4X1HI-PH-S 1 YEAR Limited Warranty4 x 1-1/4SWIVEL2005-1/2 4 x 4-1/24.15
CST-VE-5X2HI-PH-S 1 YEAR Limited Warranty5 x 2SWIVEL7506-1/2 4 x 4-1/24.7
CST-VE-6X2HI-PH-S 1 YEAR Limited Warranty6 x 2SWIVEL9007-1/2 4 x 4-1/25.59
CST-VE-8X2HI-PH-S 1 YEAR Limited Warranty8 x 2SWIVEL11009-1/2 4 x 4-1/27.1
CST-VE-3X1HI-PH-SWB 1 YEAR Limited Warranty3 x 1-1/4SWIVEL W/BRAKE2004 4 x 4-1/21.92
CST-VE-4X1HI-PH-SWB 1 YEAR Limited Warranty4 x 1-1/4SWIVEL W/BRAKE2005-1/2 4 x 4-1/24.47
CST-VE-5X2HI-PH-SWB 1 YEAR Limited Warranty5 x 2SWIVEL W/BRAKE7506-1/2 4 x 4-1/25.07
CST-VE-6X2HI-PH-SWB 1 YEAR Limited Warranty6 x 2SWIVEL W/BRAKE9007-1/2 4 x 4-1/25.94
CST-VE-8X2HI-PH-SWB 1 YEAR Limited Warranty8 x 2SWIVEL W/BRAKE11009-1/2 4 x 4-1/27.52

KEY: = Click For Expanded Model Details -- = Approval Drawing -- = Testing Certificate -- Warranty

High-Temp Phenolic Casters PDF's will open in a new window when clicked.
