CST-MR-4-2-SWB
model CST-MR-4-2-SWB
CST-MR-4-2-SWB
model CST-MR-4-2-SWB
SERIES: CST-MR


Mold-On-Rubber Casters

Transport loads from place to place with these quiet, shock-absorbing casters. Ideal for industrial applications such as platform trucks, wire shelving, and other warehouse carts and trucks. Black tread color. Wheel core is steel. Made in China.

* ANTI-CORROSIVE & RUST RESISTANT ZINC PLATED FINISH

* ROLLS SMOOTHLY ACROSS MANY SURFACES

* ROLLER BEARING


CST-MR-8-2-S

model CST-MR-8-2-S

CST-MR-8-2-R

model CST-MR-8-2-R

CST-MR-6-2-S

model CST-MR-6-2-S

CST-MR-6-2-R

model CST-MR-6-2-R

CST-MR-4-2-S

model CST-MR-4-2-S

CST-MR-4-2-R

model CST-MR-4-2-R




KEY: Approval Drawing = Approval Drawing -- Approval Drawing = Warranty -- Approval Drawing = Testing Certificate

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
Mold-On Rubber
Model PDFs Caster
Size
Capacity
(lbs)
Overall
Height
Top Plate
Size
Raceway Type Wt.
(lbs)
Swivel Casters
CST-MR-4/2-S - 4"x2" 350 5-1/2" 4"x4-1/2" Double 7
CST-MR-6/2-S - 6"x2" 450 7-1/2" 4"x4-1/2" Double 10
CST-MR-8/2-S - 8"x2" 500 9-1/2" 4"x4-1/2" Double 12
Rigid Casters
CST-MR-4/2-R - 4"x2" 350 5-1/2" 4"x4-1/2" - 6
CST-MR-6/2-R - 6"x2" 450 7-1/2" 4"x4-1/2" - 8
CST-MR-8/2-R - 8"x2" 500 9-1/2" 4"x4-1/2" - 10
Swivel Caster With Brake
CST-MR-4/2-S-SWB - 4"x2" 350 5-1/2" 4"x4-1/2" Double 6
CST-MR-6/2-S-SWB - 6"x2" 450 7-1/2" 4"x4-1/2" Double 9
