KEY:
= Approval Drawing --
= Warranty --
= Testing Certificate
All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
| Rubber | |||||||
| Model | PDFs | Caster Size |
Capacity (lbs) |
Overall Height |
Top Plate Size |
Raceway Type | Wt. (lbs) |
| Swivel Casters | |||||||
| CST-B23-2X1RU-S** | - | 2"x13/16" | 75 | 2-5/8" | 1-9/10"x2-7/25" | Double | 0.40 |
| CST-AP2-2X1R-S | - | 2"x13/16" | 125 | 2-1/2" | 1-7/8"x2-9/16" | Single | 0.40 |
| CST-B28-3X1RU-S** | - | 3"x1-1/4" | 198 | 4" | 2-16/25"x3-3/4" | Double | 1.58 |
| Rigid Casters | |||||||
| CST-B23-2X1RU-R** | - | 2"x13/16" | 75 | 2-5/8" | 1-9/10"x2-7/25" | - | 0.29 |
| CST-AP2-2X1R-R | - | 2"x13/16" | 125 | 2-1/2" | 1-7/8"x2-9/16" | - | 0.29 |
| CST-B28-3X1RU-R** | - | 3"x1-1/4" | 198 | 4" | 2-16/25"x3-3/4" | - | .99 |
| Swivel Caster With Brake | |||||||
| CST-B23-2X1RU-SWB** | - | 2"x13/16" | 75 | 2-5/8" | 1-9/10"x2-7/25" | Double | 0.43 |
| CST-AP2-2X1R-SWB | - | 2"x13/16" | 125 | 2-1/2" | 1-7/8"x2-9/16" | Single | 0.45 |
| CST-B28-3X1RU-SWTB*/** | - | 3"x1-1/4" | 198 | 4" | 2-16/25"x3-3/4" | Double | 1.92 |
| * Swivel Caster with Total Brake/ ** Delrin Bearing CST-B28 Models have a bearing dust cover seal |
|||||||
KEY: = Approval Drawing -- = Warranty -- = Testing Certificate
