model CST-B29-6X2PUA-SWTB
SERIES: CST-B29-PUA


Polyurethane Casters (butterscotch)

Polyurethane casters are the perfect asset for an assortment of commercial and non-commercial settings. The large capacity diminishes the number of trips needed, while reducing the amount of physical labor needed to transport products. The polyurethane construction lessens the amount of noise caused through travel across rough surfaces. These casters are resistant to a variety of chemicals. An assortment of wheel core materials are available. 90 +/-5 Shore A. Made in China.

* Aluminum Core for Better Corrosion Resistance

* Bearing Dust Cover Seals

* Double Welds on Inside & Outside of Fork Mounts

* Precision Ball Bearing

* Anti-Corrosive & Rust Resistant Zinc Plated Finish

* Hardened Bearing Raceway


CST-B29-6X2PUA-S

model CST-B29-6X2PUA-S

CST-B29-6X2PUA-R

model CST-B29-6X2PUA-R




KEY: Approval Drawing = Approval Drawing -- Approval Drawing = Warranty -- Approval Drawing = Testing Certificate

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
Polyurethane (Orange Tread) On Aluminum Wheel Core
Model PDFs Caster
Size
Capacity
(lbs)
Overall
Height
Top Plate
Size
Raceway Type Wt.
(lbs)
Swivel Casters
CST-B29-6X2PUA-S - 6"x2" 1,212 7-1/2" 4"x4-1/2" Double 8.0
CST-B29-8X2PUA-S - 8"x2" 1,543 9-7/16" 4"x4-1/2" Double 10.66
Rigid Casters
CST-B29-6X2PUA-R - 6"x2" 1,212 7-1/2" 4"x4-1/2" - 7.06
CST-B29-8X2PUA-R - 8"x2" 1,543 9-7/16" 4"x4-1/2" - 9.9
Swivel Caster With Brake
CST-B29-6X2PUA-SWTB - 6"x2" 1,212 7-1/2" 4"x4-1/2" Double 8.6
CST-B29-8X2PUA-SWTB - 8"x2" 1,543 9-7/16" 4"x4-1/2" Double 11.4
Swivel & Swivel With Total Brake have a swivel rig zerk fitting

KEY: Approval Drawing = Approval Drawing -- Approval Drawing = Warranty -- Approval Drawing = Testing Certificate




Click A SKU Below To Show Details

CST-B29-6X2PUA-R

CST-B29-6X2PUA-R

CST-B29-6X2PUA-S

CST-B29-6X2PUA-S

CST-B29-6X2PUA-SWTB

CST-B29-6X2PUA-SWTB

CST-B29-8X2PUA-R

CST-B29-8X2PUA-R

CST-B29-8X2PUA-S

CST-B29-8X2PUA-S

CST-C44-B29-8X2PUA-SWTB

CST-C44-B29-8X2PUA-SWTB






PDF's will open in a new window when clicked.
No Owners Manuals For This Product.


Survey Sheets

* No Survey Sheets For This Product.


Approval Drawings

* No Approval Drawings For This Product

Testing Certificates

CST-B29-6X2PUA-R
CST-B29-6X2PUA-S
CST-B29-6X2PUA-SWTB
CST-B29-8X2PUA-R
CST-B29-8X2PUA-S

Other PDF's

* No "Other PDFs" For This Product...
