model: ABLT-H-LP-3-29


SERIES: ABLT-H
Low-Profile Air Bag Scissor Lift Tables

ab-sci27.jpgWith the lowest collapsed height air lift table on the market, you can achieve a 4" lowered height. This low height allows for more material to be placed on the lift and still be in reach of the operator. These units have Pressure relief valves to prevent over inflation of the air bag, as well as a captured scissor track to provide stability and safety while raising and lowering. Air requirements are 60-120 psi, with a minimum 3/4" pipe or rubber hose. Hand controller, joy stick style included.

ab-sci27.jpgWith the lowest collapsed height air lift table on the market, you can achieve a 4" lowered height. This low height allows for more material to be placed on the lift and still be in reach of the operator. These units have Pressure relief valves to prevent over inflation of the air bag, as well as a captured scissor track to provide stability and safety while raising and lowering. Air requirements are 60-120 psi, with a minimum 3/4" pipe or rubber hose. Hand controller, joy stick style included.

Other Lift & Tilt Tables

Electric Hydraulic Scissor Lift Tables

Electric Hydraulic Scissor Lift Tables

Rotary Air/Hydraulic Scissor Lift Tables

Rotary Air/Hydraulic Scissor Lift Tables

Heavy-Duty Air Bag Scissor Lift Tables

Heavy-Duty Air Bag Scissor Lift Tables

Low-Profile Air Bag Scissor Lift Tables

Low-Profile Air Bag Scissor Lift Tables

Air Bag Scissor Lift Tables

Air Bag Scissor Lift Tables

Share This Page




KEY: Approval Drawing = Approval Drawing -- Approval Drawing = Warranty -- Approval Drawing = Testing Certificate

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.

Low Profile Air Bag Lift Table

Model PDFs Capacity
(lbs)
Lowered
Height
Raised
Height
Platform
Size (WxL)
Wt.
(lbs)
ABLT-H-LP-1-29 icon_warranty.jpgCompliance Certificate 1,000 4" 29" 36"x47" 595
ABLT-H-LP-2-29 icon_approvaldrawings.jpgicon_warranty.jpgCompliance Certificate 2,000 4" 29" 36"x47" 605
ABLT-H-LP-3-29 icon_warranty.jpgCompliance Certificate 3,000 4" 29" 36"x47" 615
ABLT-H-LP-4-29 icon_approvaldrawings.jpgicon_warranty.jpgCompliance Certificate 4,000 4" 29" 36"x47" 625
ABLT-H-LP-6-23 icon_approvaldrawings.jpgicon_warranty.jpgCompliance Certificate 6,000 4" 23" 36"x47" 635

KEY: Approval Drawing = Approval Drawing -- Approval Drawing = Warranty -- Approval Drawing = Testing Certificate

If you did not find an expected Model or SKU # in the table, try the Options Section Below


Options For series ABLT-H-LP

Model Description Wt.
(lbs)
ABLT-H-RP-ND Manual Rotate Option, No Detents (to be used with ABLT-H-P-4848-4K) 120
ABLT-H-RP-SD Manual Rotate Option, Manual Brake (to be used with ABLT-H-P-4848-4K) *Must be purchased in conjunction with ABLT-H-DK180 or ABLT-H-DK90 120
ABLT-H-DK180 Detent Kit 180 degrees, customer to weld on, no plate included 2
ABLT-H-DK90 Detent Kit 90 degrees, customer to weld on, no plate included 2
ABLT-H-FP Fork Pockets, Bolt-On Style, Adds 4" to Height 120
ABLT-H-FC Optional Foot Pedal Control 20


Link Safety Accordion Skirt

KEY: Approval Drawing = Approval Drawing -- Approval Drawing = Warranty -- Approval Drawing = Testing Certificate

If you did not find an expected Model or SKU # in this table, try the Product Specifications Section Above



Click A SKU Below To Show Details

ABLT-H-LP-1-29

ABLT-H-LP-1-29

ABLT-H-LP-2-29

ABLT-H-LP-2-29

ABLT-H-LP-3-29

ABLT-H-LP-3-29

ABLT-H-LP-4-29

ABLT-H-LP-4-29

ABLT-H-LP-6-23

ABLT-H-LP-6-23
